Aurora Multimedia DXW-3 Decora 3 Input HDBaseT Wall Plate Transmitter, White
See all Aurora Multimedia items

Aurora Multimedia DXW-3 3-Gang Decora 3 Input HDBaseT Wall Plate Transmitter, Display Port/HDMI/VGA/YPbPr, 330'/500'/600' CAT Extender, White

SKU: AMDXW3W
(1)

This item is no longer available.

Recommended Alternatives

Aurora Multimedia DXW-2: Picture 1 regular
Aurora Multimedia DXW-2 VGA to HDMI Converter with Audio, Black
$898.00
See More Recommendations
Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

2018-01-03T11:02:05

Rated 5 out of 5

DXW-3 Simple Install...it just works!

We are a leading AV integration company in Michigan. As with any install we look for the best and most simplistic ease of use products for our customers and this unit definitely fit the requirement!

JEFF B.

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Aurora Multimedia DXW-3 Specifications

  • Video Distance

    328' (99.97m): 1080p 60 Hz 24 & 36-bit CAT 5e/6/6a/7
    328' (99.97m): 1080p 60 Hz 48-bit CAT 6a/7
    328' (99.97m): 4k x 2k 30 Hz CAT 6a/7
    230' (70.10m): 1080p 60 Hz 48-bit CAT 5e/6/6a/7
    230' (70.10m): 4k x 2k 30 Hz CAT 5e/6/6a/7
    500' (152.4m): 1080p 60 Hz 24-bit (Long Reach Mode) CAT 6
    600' (182.88m): 1080p 60 Hz 24-bit (Long Reach Mode) CAT 6A
    CAT 5e/6 will achieve 328' (99.97m) for pixel clock 225 MHz
    CAT 6a/7 will achieve 328' (99.97m) for pixel clock >225 MHz

  • Max Resolution

    1080p at 60 Hz
    1920 x 1200 at 60 Hz
    4K x 2K at 30 Hz

  • Color Depth

    5e/6/6a/7: 24-bit
    5e/6: 36-bit
    5e/6/6a/7: 48-bit

  • RS-232

    300 - 115 kbps

  • IR Window

    38 kHz, 40' (12.19m) range

  • Controls

    1 x Left source selection backlit button

  • Front Selections

    2 Backlit Buttons (Red, Green, Blue)

  • LAN Connectors

    8P8C with 2 LED indicators (Only yellow LED is active)

  • HDBaseT Connector

    RJ-45 WE/SS 8P8C Right Angle

  • RS-232 Connector

    4 pin 3.81mm Euro

  • HDMI Connector

    Type A 19 pin

  • Power Connector

    2 pin 3.81mm Euro

  • Housing

    Plastic front with aluminum rear enclosure

  • Mounting

    Wall-mounting Decora 3 Gang

  • Compliance

    HDMI 3D, HDCP

  • Operating Temperature

    32 to 104 deg. F / 0 to 40 deg. C

  • Storage Temperature

    -4 to 140 deg. F / -20 to 60 deg. C

  • Relative Humidity

    20-90% RH, no condensation

  • Power Supply

    24V DC

  • Max Power Consumption

    6 Watts (max.)

  • Dimensions

    5.54 x 2.83 x 1.4" / 14.07 x 7.18 x 3.55cm (L x W x D)
    Width with Tabs: 4.3" / 10.92cm
    Wall Box Portion Depth: 1.04" / 2.64cm

  • Weight

    0.5lbs / 0.2267962kg

About Aurora Multimedia DXW-3

FEATURED REVIEWS

DXW-3 Simple Install...it just works!

By JEFF B.

We are a leading AV integration company in Michigan. As with any install we look for the best and most simplistic ease of use products for our customers and this unit definitely fit the requirement!

The Aurora Multimedia DXW-3 3-Gang decora 3 Input HDBaseT White Wall Plate Transmitter is a multi-input decora style wall plate. It installs into a standard 3-gang outlet box and functions as a switcher, converter and extender. The DXW-3 is designed to convert VGA YPbPr, S-Video and Video signals with audio to HDMI locally and transmit the signal up to 600' away to a compatible receiver (sold separately).

The sources can be selected remotely via RS-232 commands sent through the matching receiver device, or locally via the front panel push-buttons. This unit can be remotely powered by the receiver device. A 40' range IR receiver sensor is built into the wall plate and supports IR control of the receiver end.

Aurora Multimedia DXW-3 Features

  • 1 DisplayPort Input with Audio
  • 1 HDMI Input with Audio for DVI
  • 1 VGA with Audio Converted to HDMI
  • Programmable Buttons for Control of Displays
  • VGA can Accept YPbPr, S-Video & Video
  • 1 LAN Connector
  • HDBaseT 600' (182.88m) Extension
  • 2 USB 2.0 Ports
  • USB Extends Independently (220' / 67.05m)
  • 1 IR Receiver (40' / 12.19m Range)
  • Auto Sense, Buttons, RS-232 for Source Select
  • Buttons Backlight (Red, Green, Blue)
  • HDCP Compliant
  • Remote or Local Power
  • Fits in Standard 3 Gang Outlet Box
  • Low Depth for Floor & Table Boxes

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • 1 DisplayPort Input with Audio
  • Programmable Buttons for Control of Displays
  • VGA can Accept YPbPr, S-Video & Video
  • 1 LAN Connector
  • HDBaseT 600' (182.88m) Extension
  • 2 USB 2.0 Ports

What's in the box:

  • Aurora Multimedia DXW-3 3-Gang Decora HDBaseT Wall Plate Transmitter
  • 3 Gang Decora Paintable White Wall Plate
  • User Manual
