Amcrest IP5M-1190W 5MP Ultra HD Mini Outdoor Wi-Fi IP Security Camera, 3.8mm Fixed Lens, White

SKU: AMIP5M1190W

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

2024-07-07T20:00:00

Rated 5 out of 5

Great Tech Support

Lisa D helped me get my cameras set up.

markmiller

2024-04-18T20:00:00

Rated 5 out of 5

Very good

This is the 7-camera that my family buy from Amcrest.

Reouth L.

2024-03-14T20:00:00

Rated 4 out of 5

Good 5MP IP cam

Overall a great camera. Image quality is clear, a per usual with Amcrest IP cameras, there are plenty of adjustments to adjust the image and video streams to the quality you require. Since I use this camera directly connected to ethernet, I max out the resolution and quality settings. Generally, it is relatively easy to setup (comparable to other Amcrest IP cams) I'm still trying to figure out the best night vision mode for my needs (for me the night vision settings are not obvious). The outer case is made of plastic, so if you live in an area that has cold winters with ice and snow, I would highly recommend installing this camera in a sheltered area. Even though there is a build-in heater to defrost it, I would expect the PTZ mechanism to jam if there was a good snow/ice storm.

Peter W.

2024-01-31T19:00:00

Rated 5 out of 5

Carolyn G....provided great tech support on issues....

excellent customer service...very good knowledge...

Brent

2023-11-28T19:00:00

Rated 5 out of 5

Great Support

Nelson is very helpful looking at my set up. I have been a customer for 6 years now and have 3 cameras. These are good cameras and very prompt service and support always. Thank you Amcrest!

tom

2023-11-19T19:00:00

Rated 5 out of 5

All hooked up!

I've had my system for years, and every time I get a new phone, I have to figure out how to hook it up. Dominic S helped me out this time. He hung in there with me, and got onto my laptop to reconfigure my network, so now everything works together again! Thank you!

Ravinder

2023-11-09T19:00:00

Rated 5 out of 5

Tech Support review

I've always had good luck with Amcrest cameras, but needed some help getting the night vision infrared settings adjusted the way I needed them. I called support and spoke to Nelson. He knew what settings needed to be adjusted and had my camera working exactly the way I had expected in no time. Thanks Nelson!

David T.

2023-10-26T20:00:00

Rated 5 out of 5

5MP WiFi

Works great, easy to control. Took a couple tries to get the NVR to add it; but, it works great.

Anthony F.

2023-10-14T20:00:00

Rated 5 out of 5

Great Customer Service

Needed help connecting cam Lisa D helped me she was great!

Virginia

2023-10-10T20:00:00

Rated 5 out of 5

tech support

Sheldon did a excellent job supporting me when trouble shooting connecting my camera to my surveillance Pro system

K S.

2023-09-25T20:00:00

Rated 5 out of 5

New IP5M-1190W Camera

Carolyn G gave me great screen sharing support for my two new IP5M-1190W camera. She helped with the night vision light intesity, how to record videos with motion detection, how to overwrite when SD card is full, and format of the SD card. I bought 4 other cameras in the past and these are two new additions.

Mark

2023-09-16T20:00:00

Rated 5 out of 5

issue with connecting exterior IP5M camera on AMCREST View Pro app

I have to thank Lisa for her very professional help it getting my camera installed and setup. Very satisfied with the support she provided!

Denny G.

2023-08-22T20:00:00

Rated 5 out of 5

Philip K

Very satisfied with the support.

Gustavo

2023-06-21T20:00:00

Rated 5 out of 5

Installing New Camera

Jessica was very patient and helped me install my new camera successfully and was very knowledgeable .

Ed F.

2023-06-20T20:00:00

Rated 5 out of 5

Ordering my 3rd surveillance camera

Justin was great at helping me get just what I wanted. in my experience, you have good products and just as good people. I ordered my 2nd outdoor IP5M-1190W. After I get this one installed and setup, I'll be ordering a third.

Bill

2023-05-30T20:00:00

Rated 5 out of 5

CUSTOMER SERVICE REVIEW

dominic was great, very knowledgeable and helpful!

cUSTOMER

2023-03-27T20:00:00

Rated 5 out of 5

Great Camera!

Great PTZ camera all around especially for the money! Excellent video quality, easily connected to WiFi.

Scott S.

2023-02-24T19:00:00

Rated 4 out of 5

Camera Setup

Justin Was the technician that answered the phone for the issue I was having with setup. He was extremely helpful and patient evenn with some difficulty on the phone connection . I was trying to setup a new IP5M-1190W and the setup instructions were not clear. The camera got to a point and there was no indicator light that it was ready for me. Once Justin started to step me through the setup it became clear to me that this phone required that it be connedted to the ethernet cable for the initial connection even if you were doing a WIFI Setup. everything went smoothly and quickly after that.

Tony

2023-02-16T19:00:00

Rated 5 out of 5

Review

Ashley was great, very knowledgeable and helpful!

Frank T.

2023-02-15T19:00:00

Rated 5 out of 5

NELSON, Feb 15, 2023 WiFi Connection to Camera

Nelson was very patient and willing to explain every step. It was a quick seamless process and I could understand him clearly. I am glad to hear that I have lifetime Amcrest Tech Support.

CCordova

2023-02-08T19:00:00

Rated 5 out of 5

Time setting on DVR

i Would to thank Lisa for her help. It was hard calling forfew days but when i got to Lisa she really took the time to using what i was asking her help for. The GMT is a big problem with amcrest needs to be fix and be more easier for customers to fix.

Virginia

2023-02-02T19:00:00

Rated 4 out of 5

Camera great, mount needs flexibility

I haven't had the camera long but so far the camera itsrlf has been great. I downgraded by 1 star is because the mount is not very flexible. The surface I have to mount the camera is not completely flat. I still don't have a satisfactory solution.

Brenda H.

2023-01-24T19:00:00

Rated 5 out of 5

Wifi Camera

Philip Helped me in setting the camera to the Amcrest Surveillance pro software. Very Helpful and patient. Thank You

shonson c.

2023-01-18T19:00:00

Rated 5 out of 5

Nice Little Camera

Philip was very helpful I truely appreciate Him Thank You Philip

Curtis W.

2023-01-08T19:00:00

Rated 4 out of 5

Upgrade

Upgraded from 4mp bullet cams. These are plastic but much more affordable, the daytime pics are great and the night shots take some getting used to. I have a hill above me and the street comes down it toward my house so I have street lights and car lights that come from above and complicate the night vision but after adjustments ,which are many on these cameras, all is working well.

Phil

2023-01-07T19:00:00

Rated 5 out of 5

Mr jon brandon

Shelly P: She was very helpful in fixing my camera. Good job. Thanks

jon b.

2022-12-20T19:00:00

Rated 5 out of 5

smart garage camera setting

very helpful ! Thank you!

tom

2022-12-10T19:00:00

Rated 5 out of 5

Good Support

Philip Very knowledgable and helpful. Save my day. Thanks for the help

jon b.

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Amcrest IP5M-1190W Specifications

Camera
  • Image Sensor

    1/2.8" 5MP CMOS

  • Effective Pixels

    5MP UltraHD (2560 x 1920)

  • Electronic Shutter Speed

    1/3s - 1/100000s

  • Minimum Illumination

    Color: 0.005lux/F1.6 W/B:0.0005lux/F1.6 0Lux(With illuminator)

  • IR Distance

    98.42' (29.99m) (White Light), 98.42' (29.99m) (IR LED)

  • IR On/Off Control

    ZoomPrio/Manual/SmartIR/OFF

  • Illuminator Numbers

    1 IR LED, 2 White Light LEDs

  • Illuminator Type

    IR + White Light

  • Compression

    H.265, H.264

  • Frame Rate

    Main Stream: 2560 x 1920@20fps, 2560 x 1440@25fps, 1920 x 1080 @25fps, 1280 x 960@25fps, 1280 x 720@25fps)
    Sub Stream: 704 x 576@25fps, 352 x 288@25fps

  • Bit Rate Control

    CBR/VBR

  • Bit Rate

    3072 Kbps (2560 x 1920) Default

  • Day/Night

    Auto (ICR)/Color/B/W

  • BLC

    Supported

  • WDR

    DWDR

  • HLC

    Supported

  • Interface

    1x Audio Input, 1x Audio Output (2-Way Audio Supported)

  • Compression

    G.711a; G.711Mu; G.726; AAC; MPEG2-Layer2; G722.1; G729; G723

Network

Jump to...
  • Ethernet

    RJ-45 (10/100 Base-T)

  • Wi-Fi

    802.11n;802.11g; IEEE802.11b

  • Wi-Fi Frequency Range

    2.4 GHz

  • Wi-Fi Transmission Rate

    150 Mbps

  • Protocol

    HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, IPv6, SSL, FTP, ARP, RTCP, RTP, IP Filter, RTMP, TCP

  • Interoperability

    ONVIF;GB/T28181;CGI

  • Max. User Access

    20 Users

  • Edge Storage

    MicroSD Card (Up to 256GB), Cloud, FTP, NAS

  • Management Software

    Amcrest Surveillance Pro, Amcrest View Pro (iOS/Android), AmcrestCloud, Amcrest Blue Iris, most mainstream web browsers including Google Chrome, Mozilla Firefox, Microsoft Edge, Safari, etc.

Camera Features

Jump to...
  • White Balance

    Auto/Indoor/Outdoor/Track/Manual/Sodium lamp/Natural light/Street lamp

  • Gain Control

    Auto/Manual

  • Noise Reduction

    Ultra DNR (2D/3D)

  • WDR

    120dB

  • Motion Detection

    Supported

  • Perimeter Protection

    Tripwire, Intrusion

  • Preset Precision

    V: +/-1, H: +/-1

  • Region of Interest

    Supported

  • Defog

    Supported

  • Privacy Masking

    Up to 12 areas, and up to 4 areas in the same view

  • S/N Ratio

    >=55dB

  • Pan/Tilt

    Pan: 345 Degree , Tilt: 80 Degree

  • Manual Control Speed

    H:0.1 Degree /s - 80 Degree /s V:0.1 Degree /s - 56 Degree /s

  • Preset Speed

    H:81 Degree /s, V:43 Degree /s

  • Lens Type

    Fixed

  • Focal Length

    3.87mm

  • Max. Aperture

    F1.6

  • Angle of View

    H: 81.2 Degree , V: 59 Degree , D: 106.6 Degree

  • Close Focus Distance

    0.98' (0.3m)

General

Jump to...
  • Power Supply

    DC12V/1A +/-10%

  • Power Consumption

    3.5W, 9.5 (Illuminators On)

  • Operating Conditions

    -22 Degree F - 131 Degree F (-30 Degree C-+55 Degree C)

  • Ingress Protection

    IP54, TVS 2000V lightning proof; Surge protection

  • Storage Conditions

    -22 Degree F - 131 Degree F (-30 Degree C-+55 Degree C)

Physical

Jump to...
  • Color

    White

  • Dimensions

    5.76 x 4.64" (14.63 x 11.78cm)

  • Weight

    1.10 lbs (31.18g)

  • UPC Code

    850024042353

About Amcrest IP5M-1190W

FEATURED REVIEWS

Great Tech Support

By markmiller

Lisa D helped me get my cameras set up.

Very good

By Reouth L.

This is the 7-camera that my family buy from Amcrest.

Simple Wi-Fi Setup
Save your time with a simple setup process that can get you up and running on the Amcrest View mobile app in no time at all. You don't have to be tech savvy to get setup quickly and painlessly. Simply power it on, download the app, scan the QR code, and within just a few taps you're ready to go. Day to day operations are a breeze thanks to the simple interface which allows you to take advantage of the camera's powerful features. The Amcrest UltraHD camera has been meticulously designed to make plug and play setup a reality not just in theory, but in practice.

Full HD 5-Megapixel at 20FPS
Featuring the latest Ambarella processor, the Amcrest UltraHD soaks in the entire scene, dynamically painting all the vivid colors and rich imagery, pixel by pixel, onto your computer screen or smartphone in full 2560x1920 resolution at 20 frames per second (FPS). No need to strain your eyes, lean in close, or play the guessing game when you have this level of detail.

Cloud Video Storage
High definition recordings and snapshots are only as good as how quickly and easily they can be accessed. Amcrest Cloud was created to ensure that you don't miss anything, no matter where you are. Regardless of how far you are from home, you can login from a computer (PC or Mac) or through the Amcrest Cloud smartphone app to instantly pinpoint your footage through an intelligent timeline on an intuitive interface and play it back in seamless and brilliant 1080p quality. The Amcrest Cloud app also can be configured to send you on-the-go alerts. Live viewing is included free.

MicroSD, FTP, NAS & NVR Storage
In addition to Amcrest Cloud, the Amcrest UltraHD camera can also record locally to a MicroSD card (256GB, FAT32) (Not Included), an FTP server, a NAS, onto your local computer, or to any Amcrest NVR (Not Included). You'll have full control over your recordings and can manage them however you'd like.

Two-Way Talk
When it's not enough to just see what's going on, the Amcrest UltraHD camera allows you to be there with built-in two-way audio. The camera contains an embedded speaker and mic and utilizes a state-of-the-art noise-canceling algorithm. Whether on your computer or smartphone, everything you say or hear will come through clearly and instantly so that you can be part of every story, every time.

Smart Motion Alerts
The Amcrest View Pro app frees you from having to check in just to find out what's been happening lately. Instead, get immediate push notifications and alarm details sent to your smartphone while you're on the go. Launch straight into the app, choose an event from the Event List, and jump right to the relevant recording or snapshot. Life doesn't wait around, and neither should you.

Advanced Zone Detection
Create distinct motion detection zones to completely customize control over what you're monitoring. This is an effective way to ensure that you only record what you need when its important. Each zone includes its own sensitivity and threshold meters so you can fine-tune it exactly to your liking. Let the Amcrest UltraHD camera hold its focus so you don't have to lose yours.

Intelligent Timeline Playback
Your stored recordings and pictures are precious, and having that data at hand is the whole point of using a security camera. Whether sharing with friends and family, or presenting evidence in a court case, it is important to be able to immediately identify, track down, playback, and export what you want, when you want it. The Amcrest UltraHD camera's intuitive searchable timeline will make your life easier, save you time, and act as a sophisticated built-in video player.

Full Color Night Vision
Cutting-edge night vision technology allows you to get a crystal clear picture even when it's dark. This camera features a CMOS 1/2.8" 5MP low-light image sensor and built-in IR LEDs to achieve superior low lux performance and full-color night vision up to 98.4 feet.

Manual Pan & Tilt with Enhanced Zoom
Get a visual of the entire scene with fluid 360 Degree manual pan/tilt visibility and a digital zoom function that constantly enhances and sharpens when you zoom in. With the ability to easily pan and tilt from wherever you are, on a computer or smartphone, you will always be a few seconds away from a change of scenery.

Wide 106 Degree Diagonal Viewing Angle
A carefully crafted 3.8mm fixed lens with a max aperture of F1.6 generates striking visuals owing to the 106 Degree diagonal viewing angle. With a field of view larger than what is built into most fixed IP cameras, you will have no problem keeping what you care about in your sights.

Secure SSL & AES Encryption
The Amcrest UltraHD camera features secure SSL connections via HTTPS as well as uses AES encryption for wireless devices to comply with modern WiFi standards for encrypted connections. This way you can always be assured that, as you play your footage, you're also playing it safe.

Amcrest IP5M-1190W Features

  • Immaculate ProHD 5-Megapixel (2560x1920) @ 20fps
  • Supports 2.4ghz networks
  • Superior low light performance utilizing the CMOS progressive scanning image sensor and chipset
  • Super-Wide 106 Degree diagonal viewing angle
  • Playback and record professionally on a PC using Amcrest Surveillance Pro or Blue Iris Professional
  • Works using Amcrest Cloud remote video storage, MicroSD (256GB, FAT32), Amcrest NVRs, and QNAP NAS, & FTP
  • IP55 Outdoor Waterproof Camera
  • Works using Pale Moon (32bit) and SeaMonkey Browsers, IE, Safari 11, Firefox 49.0 and Chrome using Amcrest Web View Extension
  • H.265 video compression technology allows smoother video and reduces file sizes and bandwidth consumption
  • Amcrest Cloud remote video storage subscription service automatically stores footage off-site hosted and secured by Amazon AWS and accessible to you through a web-based interface for PC (Windows & MAC) (Chrome/Firefox/Safari 11/Edge) and Amcrest Cloud smartphone app
  • Features an CMOS 1/2.8" 5MP low-light image sensor and built-in IR LEDs to achieve superior low lux performance and full color night vision up to 98.4'
  • Two-Way Talk
  • Features a secure SSL/HTTPS connection, wireless AES/WPA2 encryption, FCC and CE camera certificate, UL rated power supply
  • This product may contain components which are not NDAA compliant

Key Features

  • Immaculate ProHD 5-Megapixel (2560x1920) @ 20fps
  • Supports 2.4ghz networks
  • Superior low light performance utilizing the CMOS progressive scanning image sensor and chipset
  • Super-Wide 106 Degree diagonal viewing angle
  • Playback and record professionally on PC using Amcrest Surveillance Pro or Blue Iris Professional
  • IP55 Outdoor Waterproof Camera

What's in the box:

  • Amcrest IP5M-1190W 5MP Ultra HD Mini Outdoor Wi-Fi IP Security Camera (White)
  • 12V Power Adapter
  • Network Cable
  • Quick Start Guide
  • Amcrest 1 Year Limited Warranty
