Aten KH1508A 8-Port Cat5 High-Density KVM Switch

SKU: ANKH1508A MFR: KH1508A
Earn VIP Reward Points

Key Features

  • Manage up to 8 computers with this Aten KVM switch, saving space and boosting productivity.
  • Enjoy high-resolution video up to 1600 x 1200 with this KVM, perfect for detailed work.
  • Easily switch between computers via hotkeys, OSD, or pushbuttons on this user-friendly KVM.
  • This KVM switch supports both PS/2 and USB keyboards/mice for broad compatibility.
  • Daisy-chain up to 31 additional KVM switches to control up to 256 computers total.
  • The Aten KVM ensures reliable performance with a durable metal housing and rack mount kit.
See More Product Details
Temporarily On Backorder?Request assistance or get notified
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$79.99

3 Year

$109.99

4 Year

$129.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Shopper : Hooking up kvm to a server and having trouble getting it to recognize it. Sure its something simple we are missing here. Using first port. Any suggestions?ANDREW R : For tech support or troubleshooting I'd recommend contacting the manufacturer.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Aten KH1508A Specifications

  • Computer Connections: Direct

    8

  • Computer Connections: Maximum

    256 (via Daisy Chain)

  • Port Selection

    OSD (On Screen Display), Hotkeys, Pushbuttons

  • Connectors: Console Ports

    Keyboard: 6-pin Mini-DIN Female (Purple), USB Type A Female (White)
    Video: HDB-15 Female (Blue)
    Mouse: 6-pin Mini-DIN Female (Green), USB Type A Female (White)

  • Connectors: KVM Ports

    8x RJ-45 Female

  • Connectors: Daisy Chain In

    DB-25 Female (Black)

  • Connectors: Daisy Chain Out

    DB-25 Male (Black)

  • Connectors: F/W Upgrade

    RJ-11 Female (Black)

  • Connectors: Power

    3-prong AC socket

  • Switches: Port Selection

    8x Pushbutton

  • Switches: KVM Reset

    Semi-recessed pushbutton

  • Switches: F/W Upgrade

    Slide

  • Switches: Power

    Rocker

  • LEDs: Port

    On Line: 8 Green
    Selected: 8 Orange

  • LEDs: Power

    Blue

  • LEDs: Station ID

    2 Digit 7-segment (Orange)

  • Emulation

    Keyboard: PS/2, USB
    Mouse: PS/2, USB

  • Scan Interval

    1-255 seconds

  • Video

    1600 x 1200 at 60 Hz (40m)
    1280 x 1024 at 75 Hz (50m)

  • I/P Rating

    100-240 V AC; 50/60 Hz; 1A

  • Power Consumption

    120V/5.8W; 230V/6W

  • Operating Temperature

    0 to 40 deg. C / 32 to 104 deg. F

  • Storage Temperature

    -20 to 60 deg. C / -4 to 140 deg. F

  • Humidity

    0-80% RH, Non-condensing

  • Housing

    Metal

  • Dimensions (L x W x H)

    43.30 x 16.00 x 4.40cm / 17.05 x 6.30 x 1.73"

  • Weight

    2.74kg / 6.04lbs

  • UPC Code

    672792400391

About Aten KH1508A

Enhance your IT administration with the KH1508A 8-Port Cat5 High-Density KVM Switch, a high-quality and efficient control unit designed to streamline your server room and data center management. This durable and reliable KVM switch allows you to access, control, and manage multiple computers from a single PS/2 or USB KVM console, including a keyboard, monitor, and mouse.

With the capacity to control up to 8 computers directly, this user-friendly device also offers the option to daisy chain up to 31 additional switches, enabling control of as many as 512 computers from the original KVM console. This feature makes the KH1508A KVM switch an optimal solution for businesses looking to save time, space, and resources.

The KH1508A KVM switch is equipped with unique and powerful features, including the advanced Adapter ID, which stores the Adapter Cable's configuration information. This feature simplifies server relocation, eliminating the need to reconfigure adapters when moving servers to different ports.

Experience superior video quality with this KVM switch, which supports video resolutions up to 1600 x 1200 at 60Hz for up to 40 meters, and 1280 x 1024 at 75Hz for up to 50 meters. This ensures clear, high-quality visuals even at extended distances.

The KH1508A KVM switch also offers multiplatform support, accommodating PC, Mac, Sun, and serial platforms. It also supports multiple user accounts, with capacity for up to 10 user and 1 administrator accounts, ensuring secure and efficient operation.

The device also features three port selection methods: Manual (via front panel pushbuttons), Hotkey, and multi-language OSD (On Screen Display), offering flexibility and ease of use.

The KH1508A KVM switch utilizes space-saving RJ-45 connectors and Cat5e/6 cabling, reducing cable clutter and ensuring a neat and tidy data center environment. With the new ATEN KVM Cable Adapter KA7000 series, device ID and attributes are stored in the adapter cables, allowing for hot-swap port connections without the need to reconfigure attributes.

In conclusion, the KH1508A 8-Port Cat5 High-Density KVM Switch is a robust and efficient solution for managing multiple devices, offering high-quality performance, superior video quality, and user-friendly features.

Aten KH1508A Features

  • High-density 8-port KVM switch for efficient multi-device control
  • Advanced Adapter ID feature for easy server relocation
  • Supports superior video resolutions up to 1600 x 1200 at 60Hz
  • Multiplatform compatibility with PC, Mac, Sun, and serial platforms
  • Supports up to 10 user and 1 administrator accounts for secure operation
  • Space-saving design with RJ-45 connectors and Cat5e/6 cabling

Warranty Information

This product has a limited warranty of 36 months.

Key Features

  • Manage up to 8 computers with this Aten KVM switch, saving space and boosting productivity.
  • Enjoy high-resolution video up to 1600 x 1200 with this KVM, perfect for detailed work.
  • Easily switch between computers via hotkeys, OSD, or pushbuttons on this user-friendly KVM.
  • This KVM switch supports both PS/2 and USB keyboards/mice for broad compatibility.
  • Daisy-chain up to 31 additional KVM switches to control up to 256 computers total.
  • The Aten KVM ensures reliable performance with a durable metal housing and rack mount kit.

What's in the box:

  • Aten KH1508A 8-Port Cat5 High-Density KVM Switch
  • Firmware Upgrade Cable
  • Power Cord
  • Grounding Wire
  • Rack Mount Kit
  • Foot Pad Set (4 pcs.)
  • User Manual
  • Quick Start Guide
  • Aten 3 Year Limited Warranty
