Aten VE600A Specifications

  • Video Input

    Interface: 1x DVI-D Female (White)
    Impedance: 100Ohms
    Max Distance: 1.8m / 5.91'

  • Video Output

    Interface: 1x DVI-D Female (White)
    Impedance: 100Ohms

  • Video

    Max. Data Rate: 6.75Gbps (2.25Gbps Per Lane)
    Max. Pixel Clock: 225MHz
    Compliance: HDCP Compatible Max. Resolutions / Distance: Up to 1080p at 40m / 131.23'; 1080i at 60m / 196.85'; VGA, SVGA, SXGA, UXGA, WUXGA (1920x1200)

  • Audio Input

    1x Mini Stereo Jack Female (Green)

  • Audio Output

    1x Mini Stereo Jack Female (Green)

  • Power Connector

    1x DC Jack

  • Power Consumption

    Local Unit: 5.3VDC, 2.05W; Remote Unit: 5.3VDC, 1.45W

  • Unit to Unit Connector

    2x RJ-45 Female (Silver)

  • Switch: EQ

    1x 8-position switch

  • LEDS

    Power: 1 (Green)
    Link: 1 (Green)

  • Housing

    Metal

  • Operating Temperature

    0 to 50 deg. C / 32 to 122 deg. F

  • Storage Temperature

    -20 to 60 deg. C / -4 to 140 deg. F

  • Humidity

    0-80% RH, Non-Condensing

  • Dimensions (L x W x H)

    9.13 x 5.76 x 2.40cm / 3.59 x 2.27 x 0.94"

  • Weight

    0.35kg / 0.77lbs

  • UPC Code

    672792003004

About Aten VE600A

The VE600A DVI Extender with Audio extends your DVI display up to 60 m away from your DVI source using Cat 5e cables. The use of Cat 5e cables provides a simple and reliable connection method that takes advantage of the wiring system in most modern office buildings. The VE600A incorporates Aten's technology that allows the A/V signal to be transmitted over one Cat 5e cable. If the real EDID is required, simply use a second Cat 5e cable. With stereo audio support and support for popular widescreen formats, the VE600A provides crystal-clear image and sound quality in all installations where remote DVI video displays are required.

Aten VE600A Features

  • Extends the distance between DVI source and DVI display device
  • Long distance transmission - up to 60 m
  • Uses Cat 5e cable to connect the local and remote units
  • Features Aten EDID technology that allows transmission over one Cat 5e cable
  • Superior video quality - up to 1920x1200 (40 m); 1080p (40 m); 1080i (60 m)
  • Audio enabled
  • Adjustable EQ compensation control
  • Supports widescreen formats
  • Rack mountable
  • HDCP Compatible

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Extends the distance between DVI source and DVI display device
  • Long distance transmission - up to 60 m
  • Uses Cat 5e cable to connect the local and remote units
  • Superior video quality - up to 1920x1200 (40 m); 1080p (40 m); 1080i (60 m)
  • Adjustable EQ compensation control
  • Supports widescreen formats

What's in the box:

  • Aten VE600A DVI Extender with Audio Local Unit
  • VE600A DVI Extender with Audio Remote Unit
  • 2x Power Adapters
  • Mounting Kit
  • User Instructions
  • Aten 3 Year Warranty
