Aten VM1600 16x16 Modular Matrix Switch

SKU: ANVM1600 MFR: VM1600
Earn VIP Reward Points

Key Features

  • Seamless video switching with the Aten VM1600, perfect for live events and control rooms.
  • Enjoy high-resolution video distribution across 16 inputs and 16 outputs with this matrix switch.
  • Modular design allows for easy customization and expansion of your video switching system.
  • Control your video matrix effortlessly using the intuitive front panel pushbuttons.
  • Ensure reliable connection and performance with redundant power supplies and pluggable modules.
  • This affordable video switcher offers wide compatibility, integrating easily into existing setups.
See More Product Details
Temporarily On Backorder?Request assistance or get notified
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$189.99

3 Year

$219.99

4 Year

$279.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Aten VM1600 Specifications

  • Connectors: Ethernet

    1x RJ-45 Female

  • Connectors: RS-232

    1x DB-9 Female (Black)

  • Connectors: RS-485 / RS-422

    1x captive screw connector, 5 pole

  • Connectors: Power

    1x 3-prong AC Socket

  • Connectors: LCD

    1x LCD Module

  • Switches: Input

    16x Pushbutton

  • Switches: Output

    16x Pushbutton

  • Switches: Video

    1x Pushbutton

  • Switches: Audio

    1x Pushbutton

  • Switches: Menu

    1x Pushbutton

  • Switches: Profile

    1x Pushbutton

  • Switches: Up

    1x Pushbutton

  • Switches: Down

    1x Pushbutton

  • Switches: Cancel

    1x Pushbutton

  • Switches: Power

    1x Rocker

  • LEDs: Alarm

    1x Red

  • LEDs: Redundant

    1x Green

  • LEDs: Power

    1x Green

  • I/P Rating

    100-240 VAC, 50-60Hz, 1.0A

  • Power Consumption

    120V,180W, 230V, 172W

  • Operating Temperature

    0 to 40 deg. C / 32 to 104 deg. F

  • Storage Temperature

    -20 to 60 deg. C / -4 to 140 deg. F

  • Humidity

    0-80% RH, Non-condensing

  • Housing

    Metal

  • Dimensions ( L x W x H )

    48.20 x 40.30 x 25.60cm / 18.98 x 15.87 x 10.08"

  • Weight

    17kg / 37.48lbs(chassis only)

  • UPC Code

    672792005343

About Aten VM1600

After extensive research and development, the VM1600 16x16 Modular Matrix Switch emerges as a sophisticated, high-tech solution for advanced access and real-time control of multiple local and remote A/V input devices. This state-of-the-art switch allows users to independently route video and audio content directly to various monitors, displays, projectors, and speakers with the simple press of a front panel button.

The VM1600 is equipped with a built-in Scaler that seamlessly encodes the video format for real-time switching. The front panel LCD provides a quick view of active port connections, with an EDID Mode option that optimizes resolution across different monitors.

Designed for scalability, the VM1600 accommodates a lineup of hot-swappable ATEN I/O boards. Its automatic signal conversion feature supports any combination of digital video formats, such as DVI and HDMI, making it an ideal choice for large-scale A/V applications including broadcasting stations, traffic control rooms, and emergency service centers.

The VM1600 supports superior video quality with HDTV resolutions of 480p, 720p, 1080i, and 1080p, and VGA, SVGA, XGA, SXGA, and WUXGA. It is also HDCP 1.4 compatible, ensuring seamless switch for continuous video streams, real-time switching, and stable signal transmission.

The VM1600 offers easy integration of I/O boards and a video wall feature that provides up to 32 customizable connection profiles. It also supports Consumer Electronics Control (CEC) and is audio-enabled, allowing HDMI audio extraction and stereo audio embedding.

With its hot-pluggable modular fan design and optional redundant power supply, the VM1600 ensures continuous operation and optimal performance. The VM1600 16x16 Modular Matrix Switch is not just a product, but a comprehensive solution for all your video switching needs.

Aten VM1600 Features

  • Advanced 16x16 Modular Matrix Switch for seamless control of multiple A/V devices
  • Built-in Scaler and automatic signal conversion for diverse digital video formats
  • Front panel LCD for quick view of active connections and optimal resolution settings
  • Hot-swappable ATEN I/O boards for easy integration and customization
  • Superior video quality support with HDTV resolutions and HDCP 1.4 compatibility
  • Redundant power supply and modular fan design for continuous, optimal performance

Warranty Information

This product has a limited warranty of 36 months.

Key Features

  • Seamless video switching with the Aten VM1600, perfect for live events and control rooms.
  • Enjoy high-resolution video distribution across 16 inputs and 16 outputs with this matrix switch.
  • Modular design allows for easy customization and expansion of your video switching system.
  • Control your video matrix effortlessly using the intuitive front panel pushbuttons.
  • Ensure reliable connection and performance with redundant power supplies and pluggable modules.
  • This affordable video switcher offers wide compatibility, integrating easily into existing setups.

What's in the box:

  • Aten VM1600 16x16 Modular Matrix Switch
  • Power Cord
  • Terminal Block Connector
  • Fan Module (Pluggable)
  • Power Module (Pluggable)
  • User Instructions
  • Aten 3 Year Limited Warranty
