Aten VS1912 12-Port DisplayPort Video Wall Media Player

SKU: ANVS1912 MFR: VS1912
Earn VIP Reward Points

Key Features

  • Create stunning video walls with the Aten media player's 12 DisplayPort outputs.
  • Experience high-quality image clarity with up to 340 MHz pixel clock support.
  • Enjoy versatile connectivity with HDMI, DisplayPort, USB 3.0, and Ethernet ports.
  • Easily manage your display setup via RS-232 with flexible baud rate control.
  • Ensure reliable performance with a durable metal housing and efficient fan cooling.
  • Expand your display capabilities with 64GB mSATA storage and 8GB DDR3 memory.
See More Product Details
Special Order?Estimated to Ship: 08/11/2025
Free Shipping

See Options

Qty
1

Protect your gear with Adorama Protect.* Learn more

2 Year

$499.99

3 Year

$649.99

5 Year

$949.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Aten VS1912 Specifications

  • Video Input: Interfaces

    1 x HDMI Type A Female

  • Video Output: Interfaces

    12 x DisplayPort 1.1 Female

  • Max. Data Rate

    8.64 Gbps (2.7 Gbps per lane)

  • Max. Pixel Clock

    340 MHz (with DP to DVI active adapter)

  • Compliance

    HDMI (3D, Deep Color)
    DisplayPort 1.1

  • Audio: Output

    1 x 3.5 mm Stereo Jack Female

  • RS-232

    Connector: 2 x DB-9 Female (Black)
    Baud Rate and Protocol:
    Baud Rate: 38400 to 19200, Hardware & Software Flow Control

  • Ethernet

    2 x RJ-45 Female

  • USB

    2 x USB 3.0 Female

  • Connectors

    1 x 3-prong AC Socket

  • Maximum Input Power Rating

    100-240 VAC; 50-60 Hz; 3A

  • Consumption

    120 VAC, 400W; 230 VAC, 400W

  • Fan

    Airflow: 28.8 cfm (max. in free air)
    Operating voltage: 6.0 to 12.0 VDC
    Operating temp: -10 to 65 deg. C

  • Storage Capacity

    64GB mSATA

  • System Memory

    8GB DDR3

  • Operating Temperature

    0 to 40 deg. C / 32 to 104 deg. F

  • Storage Temperature

    -20 to 60 deg. C / -4 to 140 deg. F

  • Humidity

    0 - 80% RH, Non-Condensing

  • Housing

    Metal

  • Dimensions (L x W x H)

    43.00 x 27.00 x 4.40cm / 16.93 x 10.63 x 1.73"

  • Weight

    4.22kg / 9.30lbs

About Aten VS1912

Where sophistication meets functionality, the VS1912 12-Port DisplayPort Video Wall Media Player stands as a testament to modern technology. This PC-based media player is not just a device, but a comprehensive solution for multi-display applications. It's an ideal choice for digital signage, video walls, projection screens, and digital board installations, making it a versatile tool for businesses.

With the capacity to support video wall configurations of up to 12 displays, the VS1912 is a powerhouse of connectivity. It empowers users to design innovative video walls in various asymmetric layouts, transforming the way you present visual content. The custom widgets feature allows the addition of dynamic elements like banners, video playback, flash media, images, and real-time clock displays over the screens, enhancing the viewer's experience.

The VS1912 is equipped with Advanced Video Wall features that offer the ability to resize, layer, span across multiple screens, and even rotate pictures and videos at 90-degree intervals. This flexibility allows for a more engaging and interactive display, perfect for grabbing attention in commercial settings.

Setting up the system and uploading multimedia files is a breeze with the VS1912. It comes with a built-in web interface and an intuitive Graphical User Interface (GUI), ensuring easy access and configuration without the need for additional software.

The VS1912 goes beyond just display capabilities. It features a scheduling function that allows you to create detailed playlists days, weeks, or even months in advance, ensuring your displays are always up-to-date and relevant.

For high-end system control, the VS1912 is equipped with two bi-directional RS-232 serial ports. It also includes an HDMI input port for routing an additional HDMI source, and USB 3.0 & USB 2.0 ports for importing profile settings and schedules.

In essence, the VS1912 12-Port DisplayPort Video Wall Media Player is a high-tech, advanced solution that caters to the needs of various environments. Whether it's for trade shows, lobbies, conference halls, shopping malls, or any other public space requiring video displays, the VS1912 is the ultimate choice for a sleek and stylish display solution.

Aten VS1912 Features

  • PC-based player for digital signage and video wall applications
  • Allows a video wall with up to 12 displays
  • Supports creative, asymmetric layouts
  • Advanced Video Wall: Pictures and videos can be resized, layered (including Picture in Picture), spanned across multiple screens and rotated at 90 deg. Intervals
  • Upload system configuration and playback files easily through an intuitive web GUI, no additional software needed
  • Widgets display video, image, flash media, webpage, text, banner, clock, RSS or RTSP (Real Time Streaming Protocol) over the screens
  • Flexible scheduling and profiles for easy management of connections
  • Two bi-directional RS-232 serial ports for high-end system control
  • 64 GB storage capacity and 8GB DDR3 system memory
  • One HDMI input port for more flexible media sourcing
  • USB 3.0 & USB 2.0 ports for importing profile settings and schedules
  • Locking mechanism included in DisplayPort cables and DVI adapter
  • ESD protection for Display Ports
  • Firmware upgradeable
  • Slim 1U design
  • Rack mountable

Warranty Information

This product has a limited warranty of 24 months.

Key Features

  • Create stunning video walls with the Aten media player's 12 DisplayPort outputs.
  • Experience high-quality image clarity with up to 340 MHz pixel clock support.
  • Enjoy versatile connectivity with HDMI, DisplayPort, USB 3.0, and Ethernet ports.
  • Easily manage your display setup via RS-232 with flexible baud rate control.
  • Ensure reliable performance with a durable metal housing and efficient fan cooling.
  • Expand your display capabilities with 64GB mSATA storage and 8GB DDR3 memory.

What's in the box:

  • Aten VS1912 12-Port DisplayPort Video Wall Media Player
  • 12x DisplayPort to DVI Adapters
  • Power Cord
  • Mounting Kit
  • User Instructions
  • Aten 2 Year Limited Warranty
