Aputure INFINIMAT Specifications

Light Fixture

Light Fixture

Jump to...
  • Number of Heads/Lights

    1

  • Fixture Type

    LED Light Panel

  • Photometrics

    Photometrics (2,000k)
    Softbox:
    5589 lux/519 fc (3m)
    2012 lux/187 fc (5m)

    Photometrics (3,200k)
    Softbox:
    8781 lux/816 fc (3m)
    3161 lux/294 fc (5m)

    Photometrics (4,300k)
    Softbox:
    11453 lux/1064 fc (3m)
    4123 lux/383 fc (5m)

    Photometrics (5,600k)
    Softbox:
    14794 lux/1374 fc (3m)
    5326 lux/495 fc (5m)

    Photometrics (10,000k)
    Softbox:
    25531 lux/2372 fc (3m)
    9191 lux/854 fc (5m)

  • Color Accuracy Standard

    CRI 96
    TLCI 97
    CQS 95

  • Color Temperature

    RGB

  • Color Temperature Range

    2000 to 10,000K (in CCT Mode)

  • Display

    No

  • Dimming

    App-Controlled / Controller Included / DMX / RDM

  • Water Resistance/IP Rating

    IP65

Connectivity

Jump to...
  • Mobile App Compatible

    No

Battery

Jump to...
  • Battery Connection

    No Connection Included

  • Battery

    4x Lithium ion

  • Power Source

    AC/DC

  • Power Consumption

    6400W

  • AC Input Power

    100 to 264 VAC, 50 / 60 Hz

  • DC Input Power

    DC1 & DC2 12V-16.8V 22V-33.6V

Mounting

Jump to...
  • Umbrella Mount

    No

Physical Details

Jump to...
  • Panel Size

    20x20'

  • Dimensions

    Control Box: 10.75 x 10.31 x 21.65" (27.3 x 26.2 x 55cm)
    Inflatable Softbox 20x20: 19.03 x 19.03 x 1.21' (5.80 x 5.80 x 0.37m)

  • Weight

    Inflatable Softbox 20x20: 83.73 lbs (30kg)

About Aputure INFINIMAT

How the INFINIMAT 20x20' 6400W Modular Full Color RGBWW LED Mat Panel Kit Revolutionizes Lighting Solutions

The INFINIMAT 20x20' 6400W Modular Full Color RGBWW LED Mat Panel Kit is a groundbreaking lighting solution designed to meet the diverse needs of modern production environments. This innovative LED mat panel kit is part of the versatile INFINIMAT series, which offers a range of sizes including 1x2, 1x4, 2x4, 4x4, 8x8, and the expansive 20x20, with plans for additional sizes in the future. Whether used as a mat or an inflatable, the INFINIMAT provides unparalleled flexibility and adaptability.

For smaller units, the included airbag can be conveniently stored attached to the mat, allowing for rapid inflation or deflation with the provided air pump. This feature ensures a quick and effortless setup and breakdown, making it ideal for dynamic production settings. The airbags provide a sturdy, rigid shape for the mats, which can also be mounted on frames and brackets, draped, or suspended to suit various lighting needs. Furthermore, multiple INFINIMATs can be seamlessly configured together, offering the ability to create custom sizes and shapes, while the control boxes are capable of powering and operating multiple lights simultaneously.

The INFINIMAT series stands out with its superior wattage and brightness, delivering double the output compared to other mats and inflatables of similar sizes. This enhanced output makes the INFINIMAT an invaluable asset in a wide range of production scenarios, including those requiring daylight conditions, thus transforming it from a niche tool into a versatile workhorse.

Constructed with rental clients in mind, the INFINIMATs boast heavy-duty, durable construction and a modular design that supports a variety of uses and simplifies repairs. With an IP65 weather rating, these LED mats are built to withstand challenging conditions, ensuring reliable performance in any environment.

Equipped with RGBWW technology, all INFINIMATs feature pixel control at scale, configured with either 1x2 or 2x2 pixels. The sophisticated control boxes incorporate dual dimming control systems, enabling precise dimming to extremely low levels without sacrificing color accuracy. This precise dimming capability is consistent across all dimming curves, providing users with exceptional control over their lighting setup.

The INFINIMAT 20x20' 6400W Modular Full Color RGBWW LED Mat Panel Kit is not just a lighting tool; it is a comprehensive solution that enhances creativity and efficiency in any production setting.

Aputure INFINIMAT Features

  • Modular Full-Color RGBWW LED Mats with Inflatable Softboxes
  • 1600W Power Supply
  • Multiple Mounting/Rigging Methods (Carbon Fiber Bracket with K-Mount Ball Head for 1x2, 1x4, 2x4, & 4x4; Butterfly Frame for 4x4 & 8x8; Truss and Speed-Rail Frame for 8x8 & 20x20)
  • Lamp Heads Designed with 1x2 or 2x2 Modules to Allow for Easy Module Replacements
  • Power and Control Multiple INFINIMATS Using a Single Control Box
  • AC Power Passthrough Enables Multiple 400W Power Supplies to Be Daisy Chained Via Neutrik PowerCon Cables
  • INFINIMAT 1600W Control Box Supports Battery Operation via Dual 48V DC Inputs
  • Head-to-Toe IP65 Dust & Water-Resistant Rating for Lamp Head and Control Box
  • Inflatable Softbox Provides Structural Support for Lamp Head, Diffusion, Light Control Grid, and Light Control Skirt
  • Automatic Pressure Release Valves on Inflatable Softbox to Prevent Overfilling of Air
  • Included Air Bag Repair Patches to Ensure Continued Operation of Softbox Even When Punctured
  • Included Light Control Grid and Light Control Skirt
  • >90% of Colors Within Rec.2020 Color Space
  • Fully Tunable CCT from 2,000K to 10,000K
  • Fully-Tunable Green-Magenta Adjustment
  • 0.1-100% Stepless Brightness Control - with Improved Low-End Dimming
  • Advanced HSI with White Point CCT Control
  • Industry-standard xy (CIE 1931), RGB, Light Source, & 300+ Gel Presets
  • Multiple Control Methods: Sidus Link App Control, LumenRadio CRMX, Artnet & sACN via etherCON, 16-bit 5-Pin DMX512 In & Out
  • 2 Output Modes: Max & Constant

Warranty Information

This product has a limited warranty of 12 months.

Key Features

  • Modular RGBWW LED mat panel kit for versatile lighting solutions
  • Quick setup with inflatable airbag and included AiR pump
  • high wattage for superior brightness and daylight compatibility
  • Durable construction with IP65 weather rating for outdoor use
  • Dual dimming control Systems for precise color accuracy
  • seamless configuration for creating custom sizes and shapes

What's in the box:

  • 4x Aputure INFINIMAT 8x8' 1600W Modular Full Color RGBWW LED Mat Panel
  • 4x 15m Head Cable (1600W)
  • 4x Inflatable Softbox 8x8
  • 4x Light Control Skirt 8x8
  • 4x Patch Set
  • 4x Air Pump Max
  • 4x Cushion 8x8
  • 4x Control Box 1600W
  • 4x AC Cable (1600W)
  • 4x Control Box Trolley
  • 4x Safety Rope (1.3m)
  • 4x Light Control Grid 8x8
  • Inflatable Softbox 20x20
  • Light Control Skirt 20x20
  • Light Control Grid 20x20
  • 2x Flight Case
  • Carrying Case
  • Aputure 1 Year Limited Warranty
