Art Pro Audio TubeOpto 8 8-Ch Tube Microphone Preamplifier Optical Interface
See all Art Pro Audio items

Art Pro Audio TubeOpto 8 8-Channel Tube Microphone Preamplifier Optical Interface with ADAT

SKU: APATUBEOPTO8

This item is no longer available.

Recommended Alternatives

Art Pro Audio AV Direct: Picture 1 regular
Art Pro Audio AV Direct Audio Video Direct Box
$149.99$104.99
Art Pro Audio dADB: Picture 1 regular
Art Pro Audio dADB Dual Active Direct Box
$135.99$94.99
Art Pro Audio Digital MPA-II: Picture 1 regular
Art Pro Audio Digital MPA-II Professional 2-Channel Microphone Preamplifier
$856.99$599.99
Art Pro Audio DUALXDirect: Picture 1 regular
Art Pro Audio DUALXDirect Professional Dual Channel Active Direct Box
$128.99$89.99
See More Recommendations
Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

Art Pro Audio TubeOpto 8 Specifications

  • Input Impedance

    Mic: 6.4K Ohm
    Line: 20K Ohm
    Instrument: 2.5M Ohm

  • Output Impedance

    Balanced outputs: 200 Ohm balanced

  • Frequency Response

    Analog in to Digital out: 12Hz - 20KHz +0, -1dB @ 44.1 KHz sample rate

  • THD

    1KHz: < .015% @ -30dB ref clipping
    20-20KHz: < .033%

  • HPF

    80Hz, 1-pole

  • Equivalent Input Noise

    Mic/Line: -130dBu, input shorted, max gain, "A" wtd.
    Instrument: -105dBu, input shorted, max gain, "A" wtd.

  • Maximum Input Level

    Mic/line: +18dBu balanced w/pad
    Instrument: +15dBu
    Meter clip light: -2dB ref. A/D clip (0dB FS)

  • Maximum Gain

    Mic: 64dB
    Instrument: 36dB

  • Maximum Output level

    Balanced: +20dBu (+4dBu setting)
    Unbalanced: +14dBu (+4dBu setting)
    Output level switch: Lowers output by 10dB @ -10dBV setting

  • Wordclock Range

    40KHz - 52KHz

  • Sample Rate Settings

    44.1KHz, 48KHz, ADAT, Wordclock

  • A/D Dynamic Range

    105dB ("A" wtd.)

  • D/A Dynamic Range

    105dB ("A" wtd.)

  • A/D Latency

    0.667ms(48KHz), 0.725ms(44.1KHz), 32 samples

  • D/A Latency

    0.458ms(48KHz), 0.500ms(44.1KHz), 22 samples

  • Power Requirements

    USA - 105-125VAC, AC 60Hz, 29Watts typical, Export units configured for country of destination.

  • Minimum System Requirements

    ADAT interface port

  • Dimensions (H x W x D)

    1.75 x 19 x 14.4" (44.5 x 482.6 x 365.8mm)

  • Weight

    13.2 lbs (6kg)

  • UPC Code

    840402018582

About Art Pro Audio TubeOpto 8

The ART TubeOpto 8 is the ideal Eight Channel input / output expander for any ADAT lightpipe equipped audio interface, direct-to-disc recorder or DAW. Eight high quality second generation discrete Class-A vacuum tube microphone preamps are packaged in a single rack space unit with eight channel 24-bit digital I/O.

Every input on the TubeOpto8 offers full control of the signal path with pad, phase and low frequency roll-off switches. Input gain and variable output level control of each channel allows up to 70dB of clean gain with incredible sonic transparency or for the tube stage to be dialed in for warming effects and soft clipping. Each channel has wide range LED meters monitor the preamp output levels while clip indicators monitor mic-preamp peak levels. ADAT lightpipe I/O handles eight channels of 24-bit audio input and output at either 44.1 or 48 kHz sample rates. Wordclock in and thru-puts allow multiple Tubeopto8's to be synced in complex system configurations.

Art Pro Audio TubeOpto 8 Features

  • Eight Fully Featured Class-A Tube Mic Preamps
  • Eight Channels of ADAT lightpipe Digital 24 Bit Audio I/O at 44.1 or 48kHz
  • Input Gain and Output Level Controls on Every Channel
  • Input Pad, Phase flip and Low Frequency Roll Off Switches on Every Channel
  • Two Additional Front Mounted High Impedance Instrument Line Inputs
  • Eight 1/4-inch TRS Balanced Outputs

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Eight Fully Featured Class-A Tube Mic Preamps
  • Eight Channels of ADAT lightpipe Digital 24 Bit Audio I/O at 44.1 or 48kHz
  • Input Gain and Output Level Controls on Every Channel
  • Input Pad, Phase flip and Low Frequency Roll Off Switches on Every Channel
  • Two Additional Front Mounted High Impedance Instrument Line Inputs
  • Eight 1/4-inch TRS Balanced Outputs

What's in the box:

  • TubeOpto 8 8-Channel Tube Microphone Preamplifier Optical Interface with ADAT
  • Art Pro Audio 3 Year Limited Warranty
