American Power Conversion (APC) Smart-UPS 4-Outlet 620VA/390W UPS System, DB-9 RS-232 Interface Port

SKU: APCSC620 MFR: SC620
Earn VIP Reward Points

Key Features

  • Get reliable power with this APC Smart-UPS, delivering 620VA/390W of battery backup.
  • Trust the 80+ certified APC Smart-UPS to safeguard your valuable electronics from surges.
  • This APC UPS system features four outlets, perfect for protecting your PC, router, and more.
  • Enjoy peace of mind with the DB-9 RS-232 interface for advanced power management control.
  • APC's Smart-UPS offers stepped approximation to a sinewave, ensuring compatibility.
  • The compact design of this APC 620VA UPS fits seamlessly into your home or office setup.
See More Product Details
Temporarily On Backorder?Expected Availability: 12/2025Request assistance or get notified
Calculate Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

2020-01-26T19:00:00

Rated 5 out of 5

Great little 620VS UPS

Table/Desktop style 620VA UPS for small business or home office users. Basic in features but smaller footprint and very reliable. Definitely recommended!

Splattered23

2018-10-29T20:00:00

Rated 5 out of 5

Great desktop protection

Easy to deploy and was perfect for our home office environment. I like that it has hot swap batteries.

reviewAPC

2018-10-29T20:00:00

Rated 5 out of 5

Great desktop protection

Easy to deploy and was perfect for our home office environment. I like that it has hot swap batteries.

APC4U

2017-08-20T20:00:00

Rated 5 out of 5

Great Product

Excellent Quality

0

2017-06-18T20:00:00

Rated 5 out of 5

Great Product

Excelent Quality

0

2017-06-18T20:00:00

Rated 5 out of 5

Affordable price

0

0

2017-05-28T20:00:00

Rated 5 out of 5

Great Product

Excellent Quality

0

2017-04-12T20:00:00

Rated 5 out of 5

Best Product

Best product ever purchased.

0

2017-04-10T20:00:00

Rated 4 out of 5

great buy

great buy item is everything I hoped for

0

2017-03-20T20:00:00

Rated 5 out of 5

Great Product

Excellent Quality

0

2011-06-26T20:00:00

Rated 4 out of 5

Good for Desktop Systems

An excellent size for our desktop systems. We used the "Trade-UPS" program to replace our older 400's and 420's with the 620's. Would like to have a USB port in addition to or as a replacement for the serial port interface.

MG

2011-06-26T20:00:00

Rated 4 out of 5

Good for Desktop Systems

An excellent size for our desktop systems. We used the "Trade-UPS" program to replace our older 400's and 420's with the 620's. Would like to have a USB port in addition to or as a replacement for the serial port interface.

0

2010-10-19T20:00:00

Rated 5 out of 5

Happily Protected

Very easy to set up, instructions fairly easy to understand.

bk

2010-10-19T20:00:00

Rated 5 out of 5

Happily Protected

Very easy to set up, instructions fairly easy to understand.

0

2010-07-01T20:00:00

Rated 4 out of 5

Average

For the most part this UPS works very well. The built in intelligent switching is a must for the type of commercial power we receive. However, I really wish that this model came with a USB connection instead of serial.

LANMAN

2010-07-01T20:00:00

Rated 4 out of 5

Average

For the most part this UPS works very well. The built in intelligent switching is a must for the type of commercial power we receive. However, I really wish that this model came with a USB connection instead of serial.

0

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

American Power Conversion (APC) APC Smart-UPS 4-Outlet 620VA/390W UPS System Specifications

  • Output Power Capacity

    390Watts/620VA

  • Max Configurable Power

    390Watts/620VA

  • Nominal Output Voltage

    120V

  • Output Voltage Distortion

    Less than 5% at full load

  • Output Frequency (sync to mains)

    47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal

  • Topology

    Line Interactive

  • Waveform Type

    Stepped approximation to a sinewave

  • Output Connections

    (4) NEMA 5-15R

  • Nominal Input Voltage

    120V

  • Input Frequency

    50/60 Hz +/- 3 Hz (auto sensing)

  • Input Connections

    NEMA 5-15P

  • Cord Length

    6' (1.83m)

  • Input Voltage Range for Main Operations

    82 - 144V

  • Input Voltage

    75 - 154V

  • Battery Type

    Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof

  • Typical Recharge Time

    5 hour(s)

  • Replacement Battery

    RBC4

  • RBC Quantity

    1

  • Interface Port(s)

    DB-9 RS-232

  • Control panel

    LED status display with On Line
    On Battery
    Replace Battery and Overload indicators

  • Audible Alarm

    Alarm when on battery
    Distinctive Low Battery Alarm
    Overload Continuous Tone Alarm

  • Emergency Power Off (EPO)

    Optional

  • Surge Energy Rating

    412 Joules

  • Filtering

    Full time multi-pole noise filtering: 0.3% IEEE surge let-through: zero clamping response time: meets UL 1449

  • Data Line Protection

    RJ-45 Modem/Fax/DSL/10-100 Base-T protection

  • Operating Environment

    32 - 104deg.F (0 - 40deg.C)

  • Operating Relative Humidity

    0 - 95%

  • Operating Elevation

    0-10000ft (0-3000m)

  • Storage Temperature

    5 - 113deg.F (-15 - 45deg.C)

  • Storage Relative Humidity

    0 - 95%

  • Storage Elevation

    0-50000ft (0-15000m)

  • Audible Noise at 1 Meter

    45.00 dBA (from surface of unit)

  • Online Thermal Dissipation

    70.00 BTU/hr

  • Regulatory Approvals

    CSA, FCC Part 15 Class A, UL 1778

  • Dimensions (HxWxD)

    7x5x15" / 17.78x12.7x38.1cm

  • Weight

    27.07lbs (12.28kg)

  • UPC Code

    731304222620

About American Power Conversion (APC) APC Smart-UPS 4-Outlet 620VA/390W UPS System

FEATURED REVIEWS

Great little 620VS UPS

By Splattered23

Table/Desktop style 620VA UPS for small business or home office users. Basic in features but smaller footprint and very reliable. Definitely recommended!

Great desktop protection

By APC4U

Easy to deploy and was perfect for our home office environment. I like that it has hot swap batteries.

Bring unparalleled protection to your data with the APC 120V Smart-UPS SC 620VA, equipped with a DB-9 RS-232 Interface Port. This robust UPS system ensures a reliable, network-grade power supply, making it an ideal choice for space-constrained, business-critical applications. Whether you prefer the traditional tower form or require a rack-optimized design, this Smart-UPS adapts to your needs.

As an award-winning product from APC, this Smart-UPS is designed to safeguard your business-critical file servers, whether they're Intel or UNIX based. It's also an excellent choice for protecting network switches and hubs, ensuring your connectivity remains uninterrupted.

Moreover, this UPS system is a trusted ally for Point of Sale systems, retail or bank back office operations, and ATMs, providing consistent power and preventing data loss during power fluctuations. Despite its advanced features, it's easy to set up and comes with user-friendly instructions, as noted by many users.

While some users wish for a USB connection, the DB-9 RS-232 Interface Port offers a reliable and traditional connection method. This Smart-UPS 4-Outlet 620VA/390W UPS System is a reliable and compact solution for small businesses and home offices, offering a smaller footprint without compromising on its features or reliability.

American Power Conversion (APC) APC Smart-UPS 4-Outlet 620VA/390W UPS System Features

  • Boost and Trim Automatic Voltage Regulation (AVR)
  • Adjustable voltage sensitivity
  • Adjustable voltage transfer points
  • Automatic self test
  • Cold start capable
  • Serial Connectivity

Warranty Information

This product has a limited warranty of 24 months.

Key Features

  • Get reliable power with this APC Smart-UPS, delivering 620VA/390W of battery backup.
  • Trust the 80+ certified APC Smart-UPS to safeguard your valuable electronics from surges.
  • This APC UPS system features four outlets, perfect for protecting your PC, router, and more.
  • Enjoy peace of mind with the DB-9 RS-232 interface for advanced power management control.
  • APC's Smart-UPS offers stepped approximation to a sinewave, ensuring compatibility.
  • The compact design of this APC 620VA UPS fits seamlessly into your home or office setup.

What's in the box:

  • APC Smart-UPS 4-Outlet 620VA/390W UPS System
  • CD with Software
  • Smart UPS Signaling RS-232 Cable
  • User Manual
  • American Power Conversion (APC) 2 Year Limited Warranty
