Aqara HM1S-G01 Smart Hub M1S Wireless Smart Home Bridge for Alarm System, White

SKU: AQAG013USW01

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Aqara Hub M1S Specifications

  • Color

    White

  • Wireless Protocol

    Wi-Fi IEEE 802.11 b/g/n 2.4 GHz, Zigbee

  • Input

    100-240V-, 50/60Hz, 0.2A

  • Operating Temperature

    -10 Degree -+40 Degree C (14 Degree -104 Degree F)

  • Operating Humidity

    0% - 95% RH, no condensation

  • Wi-Fi Operation Frequency

    2412-2472 MHz

  • Wi-Fi Maximum Output Power

    <= 20 dBm

  • Zigbee Operation Frequency

    2405-2480 MHz

  • Zigbee Maximum Output Power

    <= 13 dBm

  • Built-in RAM / Flash

    64/128MB

  • Dimensions

    3.15 x 3.15 x 1.63" (80 x 80 x 41.5mm)

  • UPC Code

    192784000588

About Aqara Hub M1S

The Aqara Hub M1S
The updated version of the original Aqara Hub equipped with our latest hardware and software.

Zigbee 3.0 Support, up to 128 devices
Supports all the latest Aqara devices based on the fastest, most stable, and energy efficient technology.

Built-in Speaker
A powerful 2-watt speaker can be used as an alarm or doorbell as well as via configurable automations.

RGB Light and Illumination Sensor
A bright and colorful LED ring can serve as a night light or accent light as well as being controlled by the built-in illumination sensor.

M1S is a Zigbee 3.0 hub that has a built-in RGB light made of 18 powerful LEDs and a diffuser. It can be used as an alarm, doorbell, or night light, and has a configurable brightness and color. Compared to the previous version of the Aqara Hub, the M1S has a fully fledged illumination sensor that can be used in automations via the Aqara Home app.

All-Round Compatibility
Use your favorite voice assistant or smart home ecosystem together with Aqara Home app automations.

Enhanced Wi-Fi Connectivity
The Aqara M1S has a more powerful 2x2 MIMO Wi-Fi antenna, which makes the connection faster and more reliable.

Focus on Security
Apart from Aqara Alert System, the M1S supports all 4 HomeKit alarm modes.

The Aqara Hub M1S is equipped with a built-in 2-watt speaker that is powerful and versatile enough to be used in different occasions.
• Security Alerts
• Doorbell
• Alarm Clock
• Ringtones

The Zigbee 3.0 Control Center
Thanks to the latest Zigbee 3.0 protocol, the M1S supports all the newest Aqara devices as well as existing ones. The newer technology improves stability, compatibility, and responsiveness of the hub and its child devices and focuses on local automations.

• Extra Stability
• Low Response Time
• Low Power Consumption
• Local Automations

2x2 MIMO Wi-Fi Antenna
To ensure the best possible wireless connection of dozens of sensors and controllers, the Aqara Hub M1S is equipped with a more powerful 2x2 MIMO Wi-Fi antenna.

The Aqara Hub M1S makes your Aqara devices compatible with a wide range of smart home eco- systems and voice assistants.
Apple HomeKit, Google Assistant, Amazon Alexa, Mi Home, and more are supported.

The Aqara Hub M1S supports a wide range of Aqara sensors, which make it a comprehensive, subscription-free security solution.
Each Aqara sensor has a 2+ year battery life and can be also used in automations.

• Window Sensor
• Motion Sensor
• Vibration Sensor
• Water Leak Sensor

Forget about turning your devices on and off manually. Now, it can be done automatically with the Aqara Hub M1S, Aqara sensors and controllers, and the Aqara Home app. And, even if the internet connection goes down, local automations will keep functioning.

IF:
• Motion Sensor
• Vibration Sensor
• Door & Window Sensor
• Cube Controller
• Wireless Mini Switch

THEN:
• Lights
• Exhaust Fans
• Humidifiers
• Fans
• Curtains

High-quality components and design are not only a subtle addition to any room interior but also make the M1S more re- liable by achieving constant airflow through its large perforated base.

Aqara Hub M1S Features

  • Zigbee 3.0 Support, up to 128 devices
  • Built-in Speaker
  • RGB Light and Illumination Sensor
  • All-Round Compatibility
  • Enhanced Wi-Fi Connectivity
  • Focus on Security

Key Features

  • Zigbee 3.0 Support, up to 128 devices
  • Built-in Speaker
  • RGB Light and Illumination Sensor
  • All-Round Compatibility
  • Enhanced Wi-Fi Connectivity
  • Focus on Security

What's in the box:

  • Aqara HM1S-G01 Smart Hub M1S Wireless Smart Home Bridge (White)
  • User Manual
  • Aqara 1 Year Limited Warranty
