ASUS D500SA Specifications

OS
  • Operating System

    Windows 10 Pro

Performance

Jump to...
  • CPU Socket

    LGA 1200

  • CPU

    2.9 GHz Intel Core i5-10400 6-Core (10th Gen)

  • Maximum Boost Speed

    4.3 GHz

  • L3 Cache

    12 MB

  • Memory Type

    2933 MHz DDR4

  • Total Installed Memory

    8 GB

  • Memory Configuration

    8 GB (User-Replaceable)

  • Maximum Memory Capacity

    64 GB

  • Memory Slot Type

    288-Pin DIMM

  • Memory Slots

    2 (1 Available)

  • Graphics Type

    Integrated

  • GPU

    Intel UHD Graphics 630

Storage and Expansion

Jump to...
  • Total Drive Bays

    1x 3.5" (Internal)
    1x 2.5" (Internal)

  • SSD Slots

    1x M.2 PCIe (In Use)
    1x M.2 PCIe (Available)

  • Total Installed Capacity

    256 GB

  • Solid State Storage

    1x 256 GB M.2 NVMe PCIe

  • PCI Expansion

    1x PCIe 3.0 x16 (Available)
    2x PCIe 3.0 x1 (Available)
    1x PCI (Available)

  • Optical Drive

    8x-Speed Tray-Load SuperMulti DVD Burner with Dual Layer Support

  • Ports

    4x USB Type-A (USB 3.1 / USB 3.2 Gen 1)
    4x USB Type-A (USB 2.0)
    2x PS/2

  • Display

    1x HDMI Output
    1x DisplayPort Output
    1x VGA Output

  • Audio

    1x 1/8" / 3.5 mm Headphone/Microphone Input/Output
    1x 1/8" / 3.5 mm Headphone Output
    1x 1/8" / 3.5 mm Microphone Input
    1x 1/8" / 3.5 mm Line Input
    1x 1/8" / 3.5 mm Line Output

  • Built-In Speakers

    None

  • Built-In Microphones

    None

  • Media/Memory Card Slot

    Single Slot: SD/SDHC/SDXC

Communications

Jump to...
  • Ethernet

    1x RJ45 (Gigabit)

  • Wi-Fi

    Wi-Fi 6 (802.11ax); Dual-Band (2.4 & 5 GHz)

  • MU-MIMO Support

    2 x 2

  • Bluetooth

    5.0

  • NFC

    No

Keyboard & Mouse

Jump to...
  • Keyboard

    Full-Size Keyboard

  • Pointing Device

    USB Mouse

General

Jump to...
  • Security

    Kensington Lock Slot, Dedicated TPM Security Chip

  • Power Supply

    150 W

  • Dimensions

    13.4 x 11.5 x 3.7" (340.4 x 292.1 x 94mm)

  • Weight

    11 lbs (5kg)

About ASUS D500SA

Exceptional small-business value
ASUS ExpertCenter D5 SFF features powerful, dependable and expandable performance, created especially for the unique needs of small business. Its ultracompact, flexible and sleek small form factor allows business users to enjoy flexible and neat workspace. Also, with help of our simplified small-business support services, you can enjoy reduced downtime and lower total cost of ownership.

Productivity

Exceptional performance, whatever the task
To make light work of all your business tasks, ExpertCenter D5 SFF is powered by a cutting-edge 10th Gen Intel Core processor with the latest DDR4 RAM.

• Windows 10 Pro
• 10th Gen Intel CPU
• 8 GB DDR4 RAM
• 256 GB SSD

Design

Streamline your workspace with a compact device
Whether you want to save space, create a tidy workspace, fit more computers into offices or connect more business peripherals, slim and compact ExpertCenter D5 SFF is made for you. To ensure both consistent performance and minimum noise from a small package, we optimized D5 SFF's thermal design by creating dedicated isolated air chambers for PC's main heat generators to prevent heat pooling inside - ensuring quiet operation even during its highest performance.

Compact and flexible
Designed to fit any workspace, ExpertCenter D5 SFF has a modern, compact and stylish small-form-factor chassis that can stand either vertically or horizontally. So for example, you can place a monitor beside it or on top of it - the choice is yours!

Connectivity

Ready for the business world
A full array of I/O ports is ready to connect to a wide range of business peripherals. Flexible serial and parallel ports on chassis leave more PCI slots available for additional upgrades. A smart-card reader and an SD card reader are optional for an easy transaction, data transfer, or other business-related tasks.

Easy

Easy to use and manage
As with all ExpertCenter desktops, clever business-focused design details abound to help you upgrade and manage your PCs effortlessly.

Hassle-free maintenance and upgrades
ExpertCenter D5 SFF has a tool-free chassis design so you can open it up with no tools required. The HDD and ODD can also be easily pulled out with just fingers. This saves time and effort, making component upgrades and routine servicing easy.

Power to do more
A clever internal layout gives maximum space for expansion in a compact form factor. The internal steel case allows ExpertCenter D5 SFF to accommodate up to four storage devices, while PCIe slots enable the easy addition of graphics cards, WiFi connectivity and extra I/O ports. ExpertCenter D5 SFF is easy to configure today, and ready for whatever you might need tomorrow.

Reliability

Built to last
To minimize the Total Cost of Ownership (TCO) to your business, ExpertCenter D5 SFF is designed to offer our users 100% reassurance for long-term usage. To achieve this goal, we choose world-leading components - delivering dependable quality and exceptional endurance.

Industry-leading motherboards

World's #1 motherboards
ExpertCenter desktops use ASUS motherboards - the world's #1 motherboards - which are renowned for offering comprehensive system protection to safeguard hardware, 24/7 stability through extensive testing, and consistent performance.

100% solid capacitors

Industry-leading MTBF
ExpertCenter desktops offer 100% solid capacitors, which are important for storing charge and regulating voltage. This increases system stability, thermal capacity and longevity, resulting in a top-tier Mean Time Between Failures (MTBF) rating.

Military Grade

Ready for action
Expert series PCs are solidly-built and tested to the most demanding industry requirements, including MIL-STD-810G US military standards and stringent ASUS in-house testing. The inevitable minor shocks and everyday workplace accidents won't jeopardize your precious data.

• Vibration test Withstand 5-500 Hz vibration for one hour in all directions
• Shock test Withstand six harsh shocks at a speed of 150G/2.5ms
• Operation humidity test Survive 85% humidity, 40 Degree C for 24 hours
• Non-operation humidity test Survive 95% humidity, 60 Degree C for 24 hours
• High temperature test Endure 50 Degree C with power on for 20 hours
• Low temperature test Endure 0 Degree C with power on for 20 hours
• Thermal-shock test Endure a sharp change of temperature from -10 Degree C to 50 Degree C
• Package-drop test Endure drops from 76cm height, 10 times in each direction
• Cold-storage test Endure -40 Degree C for 48 hours in an enclosure
• Damp-heat storage test Survive 95% humidity, 60 Degree C for 72 hours
• Package-vibration test Withstand 5-200 Hz vibration for 30 minutes

Security

Secure and safe solutions
ASUS understands that IT security must evolve to effectively serve as the first line of defense against business disruptions. ExpertCenter desktops feature sophisticated security features to keep your business, and its future, safe.

• Trusted Platform Module (TPM) Stores passwords and encryption keys for added security
• Kensington Security Slot and Padlock Slot Prevent physical theft of the PC from unsupervised locations
• USB ports read / write control Enable / disable the use of USB devices or optical drives

Management

Simplifying business processes
Management is made easier with ExpertCenter desktops. ASUS management solutions help streamline routine tasks, allowing IT staff to remotely control and manage company assets, saving your organization time and money.

ASUS Control Center
ASUS Control Center is a centralized IT management suite that's capable of remote management, hardware and software monitoring, and task scheduling via a user-friendly web-based interface, allowing system administrators to conveniently manage company assets through a single portal.

ASUS Business Manager
ASUS Business Manager is a PC-based platform that facilitates the management of individual PCs. It includes USB Blocker data-movement controls, system back-track to restore the system to its optimal status, and an encrypted virtual partition to store important data.

Service

Maximum support, minimum effort
The ASUS Service Package offers a wider range of solutions that go beyond the standard warranty to meet the needs of business-critical IT environments. The extended offerings protect both the hardware and your business, giving you the freedom to customize a service solution that best meets your needs.

Eco-friendly

Preserve the environment
Committed to creating a sustainable future, Expert series PCs adopt stringent environmental requirements at all stages of the product lifecycle and optimize energy use to lower your operating cost in the long term.

Efficient power consumption
To ensure a high-efficiency power supply, ExpertCenter D5 SFF utilizes top-end capacitors. The power supply features 80 PLUS Platinum certification indicating minimum wasted energy, which results in less heat generation and long-term cost savings.

ASUS D500SA Features

  • 10th Gen Intel Core i5-10400 Six-Core Processor (12M Cache, up to 4.3 GHz)
  • Windows 10 Professional and 1 month trial of Microsoft 365 for new customers
  • 256GB PCIe NVMe M.2 SSD and 8GB 2933 MHz DDR4 RAM (expandable up to 64GB)
  • TPM 2.0 Security for secure data encryption
  • Small Form Factor - weighs 11 lbs
  • Seamless connectivity with Gig+ Dual-Band Wi-Fi 6 (802.11ax) and Bluetooth 5.0
  • Keyboard and mouse included

Key Features

  • 10th Gen Intel Core i5-10400 Six-Core Processor (12M Cache, up to 4.3 GHz)
  • Windows 10 Professional and 1 month trial of Microsoft 365 for new customers
  • 256GB PCIe NVMe M.2 SSD and 8GB 2933 MHz DDR4 RAM (expandable up to 64GB)
  • TPM 2.0 Security for secure data encryption
  • Small Form Factor - weighs 11 lbs
  • Seamless connectivity with Gig+ Dual-Band Wi-Fi 6 (802.11ax) and Bluetooth 5.0

What's in the box:

  • ASUS ExpertCenter D500SA Small Form Factor Desktop Computer
  • Power Cord
  • Vertical Stand
  • USB Keyboard and Mouse
  • ASUS 1 Year Limited Warranty
