Questions & Answers

FAQ

What type of processor does the ExpertCenter D500SD Desktop Computer have?

The ExpertCenter D500SD Desktop Computer is powered by a high-performance Intel Core i5-12400 2.5GHz processor.

Does the ExpertCenter D500SD Desktop Computer come with an operating system installed?

Yes, the ExpertCenter D500SD Desktop Computer comes pre-installed with Windows 11 Pro.

What is the storage capacity of the ExpertCenter D500SD Desktop Computer?

The ExpertCenter D500SD Desktop Computer comes with a 512GB SSD for ample storage.

What is the form factor of the ExpertCenter D500SD Desktop Computer?

The ExpertCenter D500SD Desktop Computer features a small form factor design, making it a space-saving solution for your workspace.

Does the ExpertCenter D500SD Desktop Computer support easy upgrades and maintenance?

Yes, the ExpertCenter D500SD Desktop Computer features a tool-free chassis design for easy upgrades and maintenance, and includes the MyASUS app for system management.

Reviews about this item

Review Summary

ASUS ExpertCenter D500SD Specifications

  • Color

    Black

  • Operating System

    Windows 11 Pro - ASUS recommends Windows 11 Pro for business

  • Processor

    Intel Core i5-12400 Processor 2.5GHz (18M Cache, up to 4.4GHz, 6 cores)

  • Chipset

    Intel B660 Chipset

  • Graphics Processor

    Intel UHD Graphics 730

  • Memory

    2x DDR4 U-DIMM slot, 8GB DDR4 U-DIMM, Memory max up to:64GB

  • SATA

    4x SATA 6.0Gb/s ports

  • Storage

    512GB M.2 NVMe PCIe 3.0 SSD

  • Optical Drive (Optional)

    DVD writer 8X

  • Front I/O Ports

    1x Headphone
    1x 3.5mm combo audio jack
    2x USB 3.2 Gen 1 Type-A
    2x USB 3.2 Gen 2 Type-A

  • Rear I/O Ports

    1x Headphone out
    1x MIC in
    1x Line-in
    1x RJ45 Gigabit Ethernet
    1x HDMI 1.4
    1x VGA Port
    2x PS2
    4x USB 2.0 Type-A

  • Expansion Slots

    2x PCIe 3.0 x 1
    1x PCIe 4.0 x 16
    1x M.2 connector for Wi-Fi
    2x M.2 connector for storage
    2x DDR4 U-DIMM slot

  • Audio

    High Definition 7.1 Channel Audio

  • Network and Communication

    Wi-Fi 6 (802.11ax) (Dual band) 2 x 2 + Bluetooth 5.3 Wireless Card

  • Power Supply

    180W power supply (80+ Bronze, peak 228W)

  • Microsoft Office

    1-month trial for new Microsoft 365 customers. Credit card required.

  • Ecolabels & Compliances

    EPEAT Silver
    Energy star 8.0
    RoHS
    REACH

  • Security

    HDD User Password Protection and Security
    Kensington Security Slot
    Trusted Platform Module (Firmware TPM)
    Padlock loop
    Trusted Platform Module (TPM) 2.0

  • Dimensions (W x D x H)

    3.72 x 11.52 x 13.37" (9.46 x 29.27 x 33.96cm)

  • Weight

    11.02 lbs (500g)

About ASUS ExpertCenter D500SD

Exceptional small-business value
ASUS ExpertCenter D5 SFF features powerful, dependable and expandable performance, created especially for the unique needs of small businesses. Its ultracompact, flexible and sleek small form factor allows business users to enjoy a flexible and neat workspace. Also, with help of our simplified small-business support services, you can enjoy reduced downtime and lower total cost of ownership.

Productivity - Exceptional performance, whatever the task
To make light work of all your business tasks, ExpertCenter D5 SFF is powered by a cutting-edge 12th Gen Intel Core processor with the latest DDR4 RAM. An NVIDIA discrete GPU is an option for those requiring advanced graphics performance for demanding visual tasks.

Design

Streamline your workspace with a compact device
Whether you want to save space, create a tidy workspace, fit more computers into offices or connect more business peripherals, slim and compact ExpertCenter D5 SFF is made for you. To ensure both consistent performance and minimum noise from a small package, we optimized ExpertCenter D5 SFF's thermal design by creating dedicated isolated air chambers for PC's main heat generators to prevent heat pooling inside - ensuring quiet operation even during its highest performance.

Compact and flexible
Designed to fit any workspace, ExpertCenter D5 SFF has a modern, compact and stylish small-form-factor chassis that can stand either vertically or horizontally. So for example, you can place a monitor beside it or on top of it - the choice is yours!

Easy to use and manage
As with all ExpertCenter desktops, clever business-focused design details abound to help you upgrade and manage your PCs effortlessly.

Hassle-free maintenance and upgrades
ExpertCenter D5 SFF has a tool-free chassis design so you can open it up with no tools required. The HDD and ODD can also be easily pulled out with just fingers. This saves time and effort, making component upgrades and routine servicing easy.

Power to do more
A clever internal layout gives maximum space for expansion in a compact form factor. The internal steel case allows ExpertCenter D5 SFF to accommodate two storage devices, while PCIe slots enable the easy addition of graphics cards, Wi-Fi connectivity and extra I/O ports. ExpertCenter D5 SFF is easy to configure today, and ready for whatever you might need tomorrow.

Less heat, more productivity
To ensure stable performance in the compact chassis, ExpertCenter D5 SFF employs an innovative multi-channel cooling system. This comprises dedicated, isolated air chambers that allow independent heat-venting channels for the PC's main thermal generators - the CPU, GPU and power supply. ExpertCenter D5 SFF also includes the exclusive MyASUS app to optimize the operation of the CPU and system fans, automatically moderating the speeds and switching them off completely when possible, striking the perfect balance between maximum performance and minimum noise.

Noise Cancelation - AI noise-canceling audio technology for business
To level up professional conferencing, ExpertCenter D5 SFF has two-way AI noise-canceling technology that employs sophisticated machine-learning techniques. The technology includes both an upstream function to filter noise around the speaker, and a downstream function to eliminate noise from the person at the other end of the conversation. Try the demo to experience the amazing difference that ASUS two-way AI noise-canceling technology can make.

Turn on your device's audio and press play to experience AI noise-canceling technology.

Connectivity - Ready for the business world
A full array of I/O ports is ready to connect to a wide range of business peripherals. Flexible serial and parallel ports on chassis leave more PCI slots available for additional upgrades. An SD card reader is optional for an easy transaction, data transfer, or other business-related tasks.

Reliability

Built to last
To minimize your the total cost of ownership (TCO) to your business, ExpertCenter D5 SFF is designed to offer our users 100% reassurance for long-term usage. To achieve this goal, we choose world-leading components - delivering dependable quality and exceptional endurance.

Industry-leading motherboards - World's #1 motherboards
ExpertCenter desktops use ASUS motherboards - the world's #1 motherboards - which are renowned for offering comprehensive system protection to safeguard hardware, 24/7 stability through extensive testing, and consistent performance.

100% solid capacitors - Industry-leading MTBF
ExpertCenter desktops are engineered with 100% solid capacitors for better performance and longevity, with a lifespan that's up to 2x greater than traditional capacitors with the CPU under full load and 6x longer during everyday use. This maximizes your investment and minimizes the need for maintenance - all contributing to a lower total cost of ownership (TCO).

Military Grade - Ready for action
Expert series PCs are solidly-built and tested to the most demanding industry requirements, including MIL-STD-810H US military standards and stringent ASUS in-house testing. The inevitable minor shocks and everyday workplace accidents won't jeopardize your precious data.

Security - Secure and safe solutions
ASUS understands that IT security must evolve to effectively serve as the first line of defense against business disruptions. ExpertCenter desktops feature sophisticated security features to keep your business, and its future, safe.

• Trusted Platform Module (TPM) - Stores passwords and encryption keys for added security
• Kensington security slot and Padlock slot - Prevent physical theft of the PC from unsupervised locations
• USB ports read / write control - Enable / disable the use of USB devices or optical drives

Management

Simplifying business processes
Management is made easier with ExpertCenter desktops. ASUS management solutions help streamline routine tasks, allowing IT staff to remotely control and manage company assets, saving your organization time and money.

ASUS Control Center
ASUS Control Center is a centralized IT-management suite that's capable of remote management, hardware and software monitoring, and task scheduling via a user-friendly web-based interface, allowing system administrators to conveniently manage company assets through a single portal.

ASUS Business Manager
ASUS Business Manager is a PC-based platform that facilitates the management of individual PCs. It includes USB Blocker data-movement controls, system back-track to restore the system to its optimal status, and an encrypted virtual partition to store important data.

MyASUS
MyASUS is the easy way to access handy ASUS apps that help you get more out of your laptop or desktop PC. Manage fan profiles for different scenarios, pair your iOS or Android phone with your desktop, activate and adjust the AI noise-cancelation features or contact after-sales service and support - all with just a few clicks.

Eco-friendly

Preserve the environment
Committed to creating a sustainable future, ExpertCenter PCs adopt stringent environmental requirements at all stages of the product lifecycle and optimize energy use to lower your operating cost in the long term.

Efficient power consumption
To ensure a high-efficiency power supply, ExpertCenter D5 SFF utilizes top-end capacitors. The power supply features 80 PLUS Platinum certification indicating minimum wasted energy, which results in less heat generation and long-term cost savings.

ASUS ExpertCenter D500SD Features

  • 12th Gen Intel Core i5-12400 Six-Core Processor (18M Cache, up to 4.4GHz)

Key Features

  • 12th Gen Intel Core i5-12400 Six-Core Processor (18M Cache, up to 4.4GHz)

What's in the box:

  • ASUS ExpertCenter D500SD Small Form Factor Desktop Computer (Black)
