Ashdown C115-500 Specifications

  • Power Output (RMS)

    575W

  • Speaker Configuration

    1 x 15

  • Frequency Response

    -3dB at 17Hz and 30kHz

  • Speaker Outputs

    Minimum impedance 4 Ohms

  • High Instrument Input

    Impedance 3.9mOhms, input range 150mV - 20V p-p

  • Low Instrument Input

    Impedance 10kOhms, input range 300mV - 40V p-p

  • Line Input

    Impedance 22kOhms, input level 0dBu nominal

  • Line Output

    Impedance 10kOhms, level 0dBu nominal

  • DI Output

    600Ohms balanced, level -20dBu nominal

  • Tuner Output

    Impedance 1kOhms, level 0dBu nominal

  • EQ

    Bass +/-15dB at 45Hz
    Middle +/-15dB at 660Hz
    Treble +/-15dB at 7kHz shelving
    Slider 1 +/-15dB at 110Hz
    Slider 2 +/-15dB at 340Hz
    Slider 3 +/-15dB at 1.3kHz
    Slider 4 +/-15dB at 2.6kHz
    Shape (Push Flat) +8dB at 50Hz & 4kHz
    -8dB at 400Hz
    filter slope - 6dB/octave

  • Effects Send

    Impedance 22kOhms, level 0dBu nominal

  • Effects Return

    Impedance 22kOhms, input level 0dBu nominal

  • Dimensions (H x W x D)

    645 x 610 x 340mm / 25.39 x 24.01 x 13.38"

  • Weight

    36kg / 79.36lbs

  • UPC Code

    0094922759047

About Ashdown C115-500

The Ashdown Klystron C115-500 575W 15" Bass Combo Amplifier features a single input switchable for passive and active instruments. The Klystron C115-500 also has a blend of solid state and dual triode tube preamps stages. The 3 straightforward rotary tone controls provide 20dB of cut and boost at 60Hz, 660Hz and 5kHz. 2 pairs of additional sliders giving 15dB cut and boost at 180Hz, 340Hz, 1.3kHz and 2.6kHz. A built-in dual band compressor acts separately on the high and low frequency components of the signal to provide precise control, while the on-board sub-harmonic generator turns the Klystron into a bass tone powerhouses.

The inclusion of a 4-way footswitch as standard makes the Ashdown Klystron among the most versatile live performance bass amps in the business. You have control over the compressor, sub-harmonic generator, tube grind and EQ pre-shape. Central to this bass combo amp's performance is a custom developed Neodymium speaker which incorporates a number of advanced features including: a cast aluminum chassis with thin brackets to avoid sound wave reflections, a magnet circuit with heat sink rims to ensure rapid heat dissipation and decompression holes in the cone. The result is an ultra-lightweight bass driver that just keeps getting louder as the level is increased, delivering a powerful, consistent bass tone at all volume levels and with no power loss over long performances.

Ashdown C115-500 Features

  • Blend of solid state and dual triode tube preamps stages
  • 3 straightforward rotary tone controls
  • 2 pairs of additional sliders giving 15dB cut and boost at 180Hz, 340Hz, 1.3kHz and 2.6kHz
  • Built-in dual band compressor
  • Sub harmonic generator
  • Custom developed Neodymium speaker

Key Features

  • Blend of solid state and dual triode tube preamps stages
  • 3 straightforward rotary tone controls
  • Built-in dual band compressor
  • Sub harmonic generator
  • Custom developed Neodymium speaker
