Ashly NXP Series 2-Channel 75W Networkable Multi-Mode Power Amplifier with Protea DSP Software Suite

Take your live sound and fixed installation sound systems to the next level with the NXP Series 2-Channel 75W Networkable Multi-Mode Power Amplifier with Protea DSP Software Suite. Engineered to meet the rigorous demands of stadiums, arenas, performance venues, worship spaces, and convention centers, this power amplifier offers unparalleled sound quality and versatility.

Equipped with a selectable 80Hz 2nd-order Hi-pass filter, limiter, and input gain per channel, this amplifier ensures optimal sound performance. Its remote DC level control per channel and extensive protection circuitry further enhance its functionality. The amplifier also features a continuously variable cooling fan for efficient thermal management.

Stay connected with the amplifier's Ethernet port, designed for software control and monitoring of amplifier functions. It also includes a front panel COM activity LED for easy status monitoring. The amplifier is compatible with Ashly WR-5 and RD-8C programmable remote controls, with an optional RS-232 converter INA-1 available for third-party controllers.

The NXP Series Amplifier boasts an Instant Standby Mode, reducing idle power consumption by 40%. This can be triggered by contact closure, software control, or event scheduler. The amplifier also offers preset recall via various control methods, a programmable power-on delay, and aux preamp line outputs for driving other amplifiers.

Experience comprehensive software-controlled DSP including dynamics, gain, equalization, matrix mixer, crossover, delay, and metering. Enjoy additional iPad control of select DSP functions including gain, matrix, A/B source select, PEQ filter level, and meters. The amplifier also features a precision swept load impedance monitoring of individual amplifier channels for remote diagnosis of speaker problems.

The NXP Series Amplifier utilizes Class-D Switching Amplifier Technology and features a universal switch-mode power supply with Power Factor Correction (PFC) that operates from 70VAC to 270VAC. Its Multi-Mode Operation Selectable Outputs allow you to choose the desired output mode on each channel. Set the DIP-switch configuration for Low Impedance (2, 4, and 8 Ohm) or 25V, 70V, or 100V Constant Voltage.

The amplifier is energy-efficient, featuring Ashly EMS (Energy Management System) which provides an automatic sleep-mode drawing less than 1 Watt. It also offers Ethernet Control using Protea NE software, serial data control by Ashly programmable remotes or third-party controllers, instant standby mode, preset recall, fault condition logic outputs, and optional Dante, CobraNet, or AES3 digital audio capability.

With the NXP Series Amplifier, you can assign automatic execution of selected functions and tasks with its Real-Time Clock with Event Scheduler. Use the free Ashly Remote app for custom design of secure wireless control over the network. The amplifier also offers 32-bit SHARC DSP Processing at 48kHz or 96kHz Sample Rates and FIR Filter-Ready capabilities. Elevate your sound experience with the NXP Series 2-Channel 75W Networkable Multi-Mode Power Amplifier with Protea DSP Software Suite.
