Atlas Sound Sound Masking Generator

SKU: ASTSDGPN1200 MFR: TSD-GPN1200
Earn VIP Reward Points

Key Features

  • Enhance speech privacy with this Atlas Sound masking generator for secure conversations.
  • Achieve optimal sound masking with selectable pink or white noise for tailored audio.
  • Easily adjust levels using removable knobs with security covers, preventing tampering.
  • Enjoy versatile connectivity with balanced line and 70V speaker outputs for systems.
  • Mount securely with included brackets or optional rack panel for flexible placement.
  • Reduce distractions with a frequency response of 20Hz - 20kHz pre-EQ line output.
See More Product Details
Special Order?Estimated to Ship: 10/19/2025
Free Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Atlas Sound Sound Masking Generator Specifications

Chassis

Chassis

Jump to...
  • Color

    Black

  • Material

    Aluminum

  • Noise Generator

    Internal Pink & White Selectable

Outputs

Jump to...
  • Type

    Qty 1, Balanced Line
    Qty 1, Speaker Out 70V Masking Systems

  • Connection

    Removable 3 Position Captive Screw
    3.5mm Spacing

  • Impedance

    300Ohm Balanced, 150Ohm Unbalanced

  • Line Output Level

    Maximum Output 500mV
    Maximum Output 4W

Controls

Jump to...
  • Level Control

    Qty 1, Removable Knobs with Security Covers

  • Noise Generator

    Select Pink or White

  • Line Out Select

    Pre or Post EQ

  • EQ Adjust

    Recessed Screw DriverPowerBlue

Indicators

Jump to...
  • Power

    Blue

Electrical

Jump to...
  • Toplogy

    Random Analog

  • Frequency Response

    20Hz - 20kHz Line Out Pre EQ Only

  • EQ Filter

    High Cut, Variable, 1kHz - 7kHz/6dB

Mounting

Jump to...
  • Self-Securing Closure

    Industrial Grade

  • Brackets

    Qty 2, Included

  • TSD-RMK

    Optional 1 RU Rack Mount Panel

  • Cable Retainer

    Qty 1

Power Requirements

Jump to...
  • 24VDC

    250mA

  • Average Power Consumption

    Current 100mA
    VA Watts 2.4W

Dimensions & Weight

Jump to...
  • Dimensions (H x W x D)

    1.5 x 4 x 2.5" (39 x 101 x 70mm)

  • Weight

    6 oz (170g)

  • UPC Code

    612079187935

About Atlas Sound Sound Masking Generator

How the AtlasIED TSD-GPN1200 Sound Masking Generator stands out in the realm of audio equipment is its superior design and advanced functionality. This high-quality sound masking generator is expertly engineered for optimal performance in basic sound masking systems. Its innovative analog topology design effectively eliminates the repeating cycles often found in lower-cost digital designs from other manufacturers.

The TSD-GPN1200 offers the flexibility to choose between pink or white noise sources, catering to a variety of sound masking needs. It also incorporates a variable balanced output, meticulously designed to match the input requirements of AtlasIED equalizers and amplifiers, ensuring seamless integration and superior audio performance.

This professional-grade sound masking generator also features a 4W, 70V output, capable of powering up to six masking speakers tapped at .5W each. This makes it an ideal choice for environments requiring effective sound masking, such as conference rooms or public spaces.

The TSD-GPN1200 is equipped with a variable hi-cut filter with an operating range between 1kHz and 8kHz at a slope of 6dB per octave. This supports equalization requirements for most basic sound masking systems, offering a tailored audio experience.

One of the standout features of this sound masking generator is its dual output capability. Both outputs can be used simultaneously, allowing large zones to be addressed with external equalization and amplification, while a smaller zone is powered by the internal 70.7V amplifier. Spectrum control is provided by the onboard hi-cut filter, ensuring a balanced and controlled audio output.

The unit requires a separate power supply for proper function, and multiple TSDs can be powered with one power supply based on current requirements. This unit has a power requirement of 250mA, making it compatible with any of the available TDS power supplies. For multiple TSD applications, the TSD Power Calculator can be used to determine the appropriate power supply needed, ensuring efficient and effective operation.

Atlas Sound Sound Masking Generator Features

  • Balanced Line Output Plus 4W, 70.7V Output
  • Adjustable Gain and Hi-Cut Filter
  • EQ & Gain Bypass for Line Output
  • Selectable Pink or White Noise Source
  • Stand Alone or Rack Mountable
  • Security Covers Included for All Rear Panel Controls
  • Power Supply Sold Separately

Warranty Information

This product has a limited warranty of 36 months for parts and 12 months for labor.

Key Features

  • Enhance speech privacy with this Atlas Sound masking generator for secure conversations.
  • Achieve optimal sound masking with selectable pink or white noise for tailored audio.
  • Easily adjust levels using removable knobs with security covers, preventing tampering.
  • Enjoy versatile connectivity with balanced line and 70V speaker outputs for systems.
  • Mount securely with included brackets or optional rack panel for flexible placement.
  • Reduce distractions with a frequency response of 20Hz - 20kHz pre-EQ line output.

What's in the box:

  • Sound Masking Generator
  • Security Covers
  • 2x Mounting Brackets
  • Atlas Sound 3 Year Limited Warranty
