Autoscript WP-IPX-S Hardware and Studio Software Upgrade from PCI Card or XBOX/XBOX Ultra to Intelligent Prompting

SKU: ASWPIPXS MFR: WP-IPX-S
Earn VIP Reward Points

Key Features

  • Upgrade your teleprompter setup with Autoscript's WinPlus-IP studio software.
  • Enjoy real-time script editing during live prompting with this software upgrade.
  • Customize your prompting experience with user-friendly text customization options.
  • Achieve smooth scrolling with graphical scroll control for professional results.
  • Manage devices remotely, ensuring your teleprompter system is always up-to-date.
  • Benefit from enhanced compatibility with Autoscript's intelligent prompting devices.
See More Product Details
Special Order Item?Estimated to Ship: 08/10/2025
Free Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

Autoscript WP-IPX-S Specifications

Software Application

Software Application

Jump to...
  • Minimum System Requirements

    Operating System: Windows 7 or later
    32 Bit and 64 Bit OS supported
    Hard Drive: 1GB of free disk space
    RAM: 4GB
    Processor: i3
    Graphics: Graphics card supporting OpenGL 3 for smooth preview/VGA prompting

  • Application

    Connects automatically to all Intelligent Prompting devices on the connected IP network
    In-screen real time scroll preview
    Simple customizable user interface: resizable windows, color selection, content tile position, content tile pin to sidebar, tabbed windows
    Script edits during live prompting
    Multi language support
    Word & RTF Import and Export
    Graphical scroll control

  • Run Order

    Options: Add story, remove story, cloak story, drop story, scroll to prompter, track live story, print run order
    Available run order preview
    Drag and drop story

  • Story Editor

    Options: Font type, font size, font format, font color, background color, spell check, cut & paste
    Script matches prompt mode to indicate prompt output
    Follow prompter
    Font resize slider

  • Prompter Preview

    Super smooth scroll
    Options: Timer, on-screen message, invert colors, blank screen
    Timer options: Background clock, background timer
    Presenter preferences

  • Device Management

    Status: Add manual, add discovered, monitoring
    Device grouping for firmware updates
    Remote program of scroll control function buttons
    Assign colors to function buttons
    Remote software and firmware updates

  • Compatibility

    HC-IP desktop scroll control (not included)
    EVO-IP monitors, including EPIC-IP systems (not included, no XBox-IP required)
    XBox-IP scroll engine (not included, produces dual HD-SDI output)

Desktop Hand Control

Jump to...
  • Standard Function Buttons

    Next (page/bookmark/ snapshot)
    Previous (page/bookmark/ snapshot)
    Top of script

  • Programmable Function Buttons

    2x Illuminated function buttons programmed within WinPlus-IP
    Color options: RGB, White standard (User definable)

  • Status Display

    Illuminated multi-color window shows device network status and operational mode

  • Power

    3W Max power consumption
    Powered over Ethernet (PoE)
    Requires 3rd party PoE injector or XBox-IP (not included)

  • Connector

    1x RJ45

Prompter Device

Jump to...
  • Input Connection

    1x 12V DC auxiliary input
    1x RJ45 Ethernet

  • Power Consumption

    Max 8W
    With PoE Controller 11W

  • Output

    2x HD-SDI
    1x RJ45 Power over Ethernet

  • Selectable Video Formats

    1080i 50
    1080i 59.94
    1080i 60
    1080p 29.97
    1080p 50
    1080p 60
    720p 50
    720p 60

General

Jump to...
  • Dimensions (HxWxL)

    Desktop Hand Control: 42 x 134 x 230mm (1.65 x 5.28 x 9.06")
    Prompter Device: 37 x 162 x 182mm (1.46 x 6.38 x 7.17")

  • Weight

    Desktop Hand Control: 500g (17.64 oz)
    Prompter Device: 600g (21.16 oz)

  • UPC Code

    5060520684949

Models
Autoscript WP-IPX-S Hardware and Studio Software Upgrade
$6,336.50

Special Order Item

This item typically ships within 2-5 Days. Delivery is subject to availability.

Autoscript WinPlus-IP Studio Prompting Software Application, Electronic Download
$6,583.50

$6,930.00

Save:$346.50 (5%)

Autoscript WinPlus-IPS License with Hand Control & XBox-IP Prompter Generator
$5,515.00

Special Order Item

This item typically ships within 2-5 Days. Delivery is subject to availability.

Accessory TypeSoftwareSoftwareSoftware

About Autoscript WP-IPX-S

You'll find the power behind Intelligent Prompting in the WinPlus-IP. This software upgrade from PCI Card or XBOX/XBOX Ultra to Intelligent Prompting is a modern refresh of the industry standard prompting application, boasting a recognizable interface refined over years of use. It features familiar shortcut keys and enhanced functionality, making it a user-friendly solution for your production needs.

The default user interface is designed with dark production environments in mind, offering customizable colors and content location to suit the operator's preferences. With the super smooth scroll preview, you'll have a clear overview of the prompted script at all times. The improved features, such as the font resize slider and prompt output indicator in the edit window, make operation fast and intuitive.

WinPlus-IP connects directly to all Intelligent Prompting devices, including controllers, monitors, and the XBox-IP. The device status tool allows for efficient monitoring and management of all Intelligent Prompting devices on the network. Group updates can be used to manage individual productions, depending on user access rights.

This latest upgrade builds on the reliability that Autoscript is known for worldwide. For critical live productions, a full redundancy fail-safe is facilitated by the IP-enabled workflow. This allows a mirror PC to immediately take over from a failed PC without manual intervention.

The HC-IP Desktop Hand Control is a smart and comfortable control option. Ergonomically designed for maximum performance and comfort, it provides a neutral hand position with adequate wrist support and can be operated with either hand. The HC-IP requires just one Ethernet cable for both power and network connectivity, simplifying your setup.

The XBox-IP, the inner drive of Intelligent Prompting, is an extremely compact scroll engine. It networks via Ethernet to the WinPlus-IP prompting software application, allowing users to monitor status, manage group updates, and perform remote upgrades. With dual HD-SDI outputs, it supports the distribution of the teleprompter video to traditional prompt monitors.

Upgrade your production setup with the WP-IPX-S Hardware and Studio Software Upgrade from PCI Card or XBOX/XBOX Ultra to Intelligent Prompting. It's a powerful, user-friendly, and reliable solution for your prompting needs.

Autoscript WP-IPX-S Features

  • WinPlus-IP Software Application:
  • Powerful, modern refresh of WinPlus brings the industry standard up-to-date and supports a fully IP-enabled workflow
  • Intuitive and fast operation with simple menus and familiar processes, avoids the downtime and errors associated with learning a new system
  • Customizable user interface allows operators to define the layout and color of the application, and pin content tiles to sidebar when not required
  • Super smooth scroll real time preview ensures a clear overview of what the talent is reading
  • Intelligent Prompting device manager enables users to add, monitor, group and update networked prompting devices remotely
  • Grouping of devices for production settings reduces system setup time
  • Support for multi-language operation
  • Minimal data transfer required vs baseband video/video over IP
  • At a glance device status
  • Instant connectivity globally
  • Immediate redundancy
  • HC-IP Desktop Hand Control:
  • Wrist support and neutral hand position ensures comfortable, safe operation
  • Central button positioning supports left and right-handed operation
  • Two illuminated function buttons programmable in WinPlus-IP to suit the operator's desired configuration
  • Powered over Ethernet to simplify integration and reduce cabling
  • XBox-IP Prompter Device:
  • Compact, portable unit
  • Dual HD-SDI output distributes script video to traditional prompt monitors
  • Power over Ethernet output for scroll control avoids the need for 3rd party equipment in single controller setups
  • At a glance network and status indicator
  • Managed remotely in WinPlus-IP and auto detected for simple installation
  • Not required for EVO-IP and EPIC-IP prompt monitors

Warranty Information

This product has a limited warranty of 12 months.

Key Features

  • Upgrade your teleprompter setup with Autoscript's WinPlus-IP studio software.
  • Enjoy real-time script editing during live prompting with this software upgrade.
  • Customize your prompting experience with user-friendly text customization options.
  • Achieve smooth scrolling with graphical scroll control for professional results.
  • Manage devices remotely, ensuring your teleprompter system is always up-to-date.
  • Benefit from enhanced compatibility with Autoscript's intelligent prompting devices.

What's in the box:

  • Autoscript WinPlus-IP Studio Prompting Software Application
  • HC-IP Desktop Hand Control
  • XBox-IP Prompter Device
  • 12V DC Power Supply Unit with Locking Connector for XBox
  • Autoscript 1 Year Warranty for Prompter Device
