Atomos Sumo19 SE 19" HDR Pro/Cinema Monitor-Recorder-Switcher

SKU: ATATOMSUMSE1 MFR: ATOMSUMSE1
Earn VIP Reward Points

Key Features

  • Capture stunning 6K ProRes RAW video with this Atomos monitor-recorder for exceptional quality.
  • Enjoy a bright 19" HDR display with 1200nit brightness, perfect for on-set monitoring and recording.
  • Record and switch up to 4 x ISO feeds to 1080p60, streamlining multicamera workflows with ease.
  • Seamlessly switch between multiple SDI inputs with auto or manual XML transitions for live events.
  • Utilize advanced on-screen tools like waveform, vectorscope, and focus peaking for precise control.
  • Power your Atomos Sumo19 SE with optional V-Lock or Anton Bauer batteries for extended recording.
See More Product Details
FREE 2-Day Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$99.99

3 Year

$159.99

4 Year

$191.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Learn
Specs
Protection
Q&A

Questions & Answers

Shopper : Why Did You Choose This?GREGORY G : Features I like for acceptable price.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Atomos Sumo19 SE Specifications

Environmental

Environmental

Jump to...
  • Ambient operating temperature

    Up to 40 Degree C

Construction and Control

Jump to...
  • Body

    Aluminum alloy chassis with ABS Polycarbonate back plate

  • Cooling

    Actively controlled fan and Heat Sink

  • Tally light

    Rear and front

  • Multi-function button

    Power/lock Screen

  • Input voltage

    DC 12-16.8v, Battery 14.4V nominal

  • Operating power

    75W

  • Compatible batteries

    V-Lock/Anton Bauer via XLR terminal, (optional mounting plates available) , 95Wh or larger recommended.

  • Battery Run time (Record)

    Battery dependent

  • Continuous power

    Dual Battery input via dedicated 4 pin XLR

  • DC in connector

    4 pin XLR

Display

Jump to...
  • Touchscreen

    SuperAtom IPS panel (capacitive touch)

  • Size

    19" (48.26cm)

  • Resolution

    1920 x 1080

  • PPI

    120

  • Bit depth

    10Bit (8+2 FRC)

  • Backlight Type

    Edge lit

  • Brightness (cdm2/nits)

    1200nit (+/- 10% @ center)

  • Aspect ratio

    16:9

  • De-interlace mode

    Yes, Graphic burning protection

  • Color Gamut

    Rec.709

  • Calibration support

    Atomos Calibrator with Xrite i1 Display Pro/Plus (Retail)

Color Pipeline

Jump to...
  • Gamma

    Sony SLog/SLog2/SLog3, Canon CLog/CLog2/Clog3, Arri Log CEI160/LogCEI200/LogCEI250/LogCEI320/LogCEI400/LogCEI500/LogCEI640/LogCEI800 /LogCEI1000/LogCEI1280/LogCEI1600, Panasonic Vlog, JVC JLog1, Red LogFilm/Log3G10/Log3G12, FujiFilm Flog, PQ (HDR10), HLG, Nikon N-Log

  • Gamut

    BT2020, DCI P3, DCI p3 65, Sony SGamut/SGamut3/SGamut3.cine, Canon Cinema/DCI P3/DCI P3+/BT2020, Panasonic V Gamut, Arri Alexa Wide Gamut, Rec709, JVC LS300, Red DragonColor/DragonColor2/RedColor2/RedColor3/RedColor4/RedWideGamut

  • Look Up Table (LUT) Support

    3D LUT (.cube format)

  • 3D LUT Output

    Loop out

  • 3DLUT 50/50

    Yes

  • Monitoring Modes

    Native/HLG/PQ/3D LUT

  • HDR output Conversion

    Log/HDR to HLG/PQ

Video Input

Jump to...
  • HDMI

    1x HDMI (2.0) 4k p60

  • HDMI RAW

    No - HDMI Video only

  • SDI

    2x 12G & 2x 3G

  • SDI RAW

    Apple ProRes RAW up to 6k

  • Bit Depth

    8/10Bit Video/RAW up to 12Bit

  • Video Chroma Subsampling

    4:2:2

  • HDCP copy protection

    Not supported

Metadata

Jump to...
  • SDI

    File Name from Arri, RED. RAW - white balance, Exposure index, Shutter speed/angle, Iris F stop, ISO, Gamma, gamut

Video Output

Jump to...
  • HDMI

    1x HDMI (2.0) 4k p60

  • SDI loop out

    1x 12G SDI Backwards compatible Autodetection level A and B selectable

  • SDI Play out

    1x 12G SDI Backwards compatible Autodetection level A and B selectable

  • Video Chroma Subsampling

    '4:2:2

  • Bit Depth

    10Bit Video/12Bit RAW

Web Streaming

Jump to...
  • USB UVC

    Optional via Connect 4k

Video Signal Conversion

Jump to...
  • HDMI to SDI

    Yes - Video and RAW

  • SDI to HDMI

    Yes - Video and RAW

Audio In/Out

Jump to...
  • Audio Quality

    24/48kHz

  • Audio Codec

    PCM

  • HDMI

    8ch 24Bit, input dependent

  • SDI

    12ch 24Bit, input dependent

  • Analogue Audio in

    2x XLR

  • Analogue Audio Out

    2x XLR

  • Speakers

    2x 5w

  • Headphone out

    3.5mm 2ch.

Timecode / Sync

Jump to...
  • Embedded

    HDMI and SDI

  • Time of day

    Yes, Time and Date

  • LTC

    LTC via BNC input in Record mode

  • Genlock

    GenLock in Playback mode

Resolution and Frame Rates

Jump to...
  • 6K

    RAW Only up to 30p via SDI Only

  • 4K DCI

    23.98/24/25/29.9/30/50/59.94/60p

  • 4K UHD

    23.98/24/25/29.9/30/50/59.94/60p

  • 2K DCI 2046 x 1080

    2K DCI: 23.98/24/25/29.9/30/50/59.94/60p

  • FHD 1920 x 1080 Progressive

    23.98/24/25/29.9/30/50/59.94/60/100/120p

  • FHD 1920 x 1080 PsF

    Converted to P and looped out PsF

  • FHD 1920 x 1080 Interlaced

    23.98/24/25/29.9/30/50/59.94/60i

  • 1280 x 720p

    50/59.94/60p

Recording CODEC

Jump to...
  • CDNG

    For SDI RAW inputs Only

  • Apple ProRes RAW

    ProRes RAW, HQ

  • Apple ProRes

    LT, 422, 422HQ

  • Avid DNxHD

    220x,220,145,36

  • Avid DNxHR

    LB, SQ, HQ, HQX

Playback

Jump to...
  • Playlist

    Yes, Create customer play lists from full or sub clips

  • Loop

    Yes, with user customizable in/out markers

  • Apple ProRes Raw

    Yes, recorded clips

  • Apple ProRes

    Yes, with Linear PCM audio

  • Avid DNx

    Yes, with Linear PCM audio

Recording functions

Jump to...
  • Pre-roll record

    Yes (HD 8s, 4K 2s) - Not available in RAW

  • ISO Record

    Up to 4 x ISO up to 1080p 60 (3G SDI Level A ONLY)

  • Switched Program Record

    Yes Up to 1080p 60

Multi Input / Switching

Jump to...
  • SDI A/B toggle

    Yes, Up support up to 12G SDI per input

  • Dual Input display

    Via Multi ISO input mode

  • Multiple SDI input

    Up to 4 x up to 1080p 60 (3G SDI Level A ONLY)

  • Input transitions

    Auto or manual XML transition

Supported media

Jump to...
  • Master Caddy I

    Not compatible

  • SSDmini

    Yes BUT ONLY with optional SSDmini handle

  • File Naming

    Unit Name - Scene/Shot/Take, Arri & RED via SDI

  • File System

    ExFAT

On screen tools

Jump to...
  • Waveform

    Yes, 3 size/Position

  • RGB parade

    Yes, 3 size/Position

  • Vector scope

    Yes, 2 size/Position

  • 1x Zoom

    Yes. 1:1 Pixel mapping for 4k

  • 2x Zoom

    Yes

  • Focus peaking

    Color selected/threshold setting/color/ Mono/edges only

  • False color

    Yes, with Scale

  • Zebra

    Yes, Adjustable

  • Isolate color channel

    Blue Only

  • Cine Frame Guides

    2.4:1, 2.35:1, 1.9:1, 1.85:1, 4:3

  • Safe areas

    Action and Graphic

  • Anamorphic desqueeze

    1.25x, 1.33x, 1.5x ,1.8x, 2x

  • Display Flip

    Vertical Only

Onboard Signal Processing

Jump to...
  • Pulldown Removal

    24/25/30pSF > 24/25/30p (2:2 pulldown)60i > 24p (3:2 pulldown)

  • 4K UHD Downscale for HD

    Loop out - 4K UHD to FHD

  • DCI Crop

    Loop out - 17:9 to 16:9 Crop

Remote control

Jump to...
  • HDMI

    Auto HDMI Trigger, Supported Protocols - Canon, Sony, Atomos Open Standard

  • SDI

    SDI trigger camera selectable

  • Serial 2.5mm Jack

    LANC control and calibration via optional USB to serial cable

Supported Applications

Jump to...
  • XML

    Cut tag EDL and Multicam with transitions in FCP XML

  • Apple ProRes RAW

    Apple FCP, Adobe Premiere, After Effects, Avid Media Edius, Assimilate Scratch, Baselight Film Light

  • Video Codecs

    All applications with support for Apple ProRes and Avid DNX in .MOV wrapper

Target use/User

Jump to...
  • Mirrorless Cameras

    On-set, In-Studio, Directors' Monitor

Battery

Jump to...
  • Battery Info

    Optional, not included

  • Battery Material

    Lithium ion

  • Battery Type

    Non-universal

  • Battery Quantity

    1

Physical

Jump to...
  • Mount points

    1/4-20 screw; 4 x top, 4 x bottom, 2 x side , 3/8-16 screw; 2 x top, 2 x bottom, 1 x side

  • VESA mount

    100 x 100mm

  • Dimensions (W x H x D)

    Without Feet: 19.8 x 12.2 x 2.5" (504 x 310 x 63mm), With Feet: 19.8 x 13 x 7.1" (504 x 330 x 180mm)

  • Weight

    12 lbs (5.45kg)

  • UPC Code

    814164022644

Related Articles & Videos

The Best On-Camera Monitors & External Camera Screens

The Best On-Camera Monitors & External Camera Screens

Do you need a bigger monitor for upcoming video shoots? Check out our top picks for the best on-camera monitor and external camera screen.
Read more

About Atomos Sumo19 SE

Proven. Reliable
More than just a monitor - Sumo 19 is the perfect tool to bridge your 4K HDR workflow across multiple cameras, audio and Atomos devices. Sumo 19 is a Monitor-Record-Switcher, and highly adaptable to suit multiple applications.

Unlock the true potential of your RAW cinema cameras with the Sumo 19. Preserve your sensor's pristine pixels in ProRes RAW at up to 5.7kp30, 4kp120 DCI/UHD and 2kp240 DCI/HD. CDNG supports up to 4kp30 DCI. Sumo 19 is compatible with Sony FS series, Canon C300MKII/C500 or Panasonic EVA-1/Varicam LT and more.

Switching - Live Quad-channel HD Switching and Recording
Take full advantage of 4 x SDI inputs and let Sumo 19 step into the role of a large-format quadview live switcher and recorder on your multi-camera shoots. Record up to four 1080p60 streams simultaneously as separate ISOs while cueing and switching in real-time with a simple touch of the screen. Sumo 19 allows user to record a fifth 'program' channel of your switched feed. Display the resulting mixed output (via HDMI or SDI) live on set.

Switching is completely asynchronous, eliminating the need for expensive locked sources and allowing the use of more affordable cameras. You can easily output the switched feed for live streaming with a solution as simple as the Atomos Connect 4K.

For professional productions large and small you save significant space - replacing several boxes in your rack, or decks and monitors on your desk with a single Sumo 19.

HDR/SDR - HDR in the field and in the studio
HDR really comes to life on the Sumo 19. It's 19" 1920 x 1080 LCD panel with 10-bit processing takes the RAW/Log/PQ/HLG output from cameras or gaming consoles and precisely maps to display 10+ stops of dynamic range in real time. Use as a director or client monitor in the field, or an affordable HDR studio monitor.

10-bit ProRes and DNx up to 4Kp60
Video from any camera or digital video source can be captured via SDI or HDMI. Record up to 10-bit 4:2:2 in ProRes or DNxHR codecs at 4Kp60 or 2Kp240, depending on the camera's capability. The depth and quality of the image is preserved with data rates of up to 1.8Gbs, 220MB/s.

Audio - Two stereo balanced XLR inputs with 48V
Use full size XLR connections with 48V Phantom power to connect two external microphones with balanced analogue audio recording and monitoring. The Sumo19 has dedicated meters, gain controls and adjustments for frame delay on each channel. Mic or line level audio can be seamlessly synchronized with embedded audio from HDMI and SDI sources.

Sumo 19
The perfect on-set monitor-recorder and switcher. Sumo's 19" screen allows you to really see what's going on in your image.

Atomos Sumo19 SE Features

  • Upgraded 19" IPS touchscreen display with 1200 cd/sq. m brightness ( +/-10%)
  • Live quad-channel HD switching and recording capabilities
  • Support for recording in ProRes RAW and 10-bit 422 ProRes/DNxHR
  • HDMI 2.0 and quad-SDI connections with support for genlock and LTC timecode
  • Compatibility with HLG and PQ formats of HDR
  • Capability to record four streams simultaneously as separate ISOs with real-time cueing and switching
  • Ability to record a fifth channel of the switched feed, resulting in live mixed output on set (via HDMI or SDI)
  • Asynchronous switching capability with output via Atomos Connect 4K
  • Two full-size XLR inputs with +48 phantom power for balanced analog audio recording and monitoring
  • Dedicated meters, gain controls, and adjustments for frame delay on each audio channel
  • Synchronization capability for mic or line-level audio with embedded HDMI and SDI audio
  • Dual 4-pin XLR inputs for continuous dual-battery power
  • Included BattWing mounting bracket for integration of V-mount or Gold mount battery 95Wh or larger
  • Included AC power supply with 12-16.8 VDC input

Warranty Information

This product has a limited warranty of 12 months for parts and 12 months for labor.

Key Features

  • Capture stunning 6K ProRes RAW video with this Atomos monitor-recorder for exceptional quality.
  • Enjoy a bright 19" HDR display with 1200nit brightness, perfect for on-set monitoring and recording.
  • Record and switch up to 4 x ISO feeds to 1080p60, streamlining multicamera workflows with ease.
  • Seamlessly switch between multiple SDI inputs with auto or manual XML transitions for live events.
  • Utilize advanced on-screen tools like waveform, vectorscope, and focus peaking for precise control.
  • Power your Atomos Sumo19 SE with optional V-Lock or Anton Bauer batteries for extended recording.

What's in the box:

  • Atomos Sumo19 SE 19" HDR Pro/Cinema Monitor-Recorder-Switcher
  • Master Caddy II Case
  • AC Power Supply
  • BattWing Mounting Bracket with 4x Screws
  • 2x Desktop Feet with 4x 1/4" Mounting Screws
  • Atomos 1 Year Limited Warranty (Extended 3 Year Limited Warranty with Registration)
