Atomos Sumo 19" HDR/High Brightness Monitor Recorder / Switcher

SKU: ATOMSUMO1

This item is no longer available.

Recommended Alternatives

Overview
Compare
Accessories
Specs
Protection
Q&A

Questions & Answers

JOHN M : The "What's in the box" lists a Battwing Mounting Bracket - is this the hardware that's required to mount v mount or Gold Mount battery plates?Roger C : Hello John, what comes in the box is the sumo, power supply 1x caddy and the batt wing. That is only things that come with it. you'll need to get the v or gold mount plates to XLR power. you can mount those plates to the batt wing.
Shopper : Why Did You Choose This?MAX A : great monitor at this price pointVICTOR B : Have 10 needed two more for a dozen. you know. full setJohn W : It is a awsome monitorSTEVEN S : Directors MonitorJOSE A : great value. limited availability from other sourcesMICHAEL G : For client monitor and switcher/recorderANDREAS V : monitor and back up in one package!

Reviews about this item

Review Summary

2022-02-09T07:52:00

Rated 5 out of 5

Great director?s monitor

Works as advertised. I love using it as a director?s monitor.

STEVEN S.

2021-06-11T10:35:43

Rated 5 out of 5

Amazing value

Amazing value

Jose A.

2021-03-15T08:20:23

Rated 5 out of 5

Fabulous on location monitor

Fantastic on-location monitor we use for event recording. Love the iso recording features. Colours are pretty accurate. Sharp display. Would recommend buying the Matthew’s vesa mount with it so you can easily put on a cstand.

ANDREW W.

2020-11-13T08:43:33

Rated 3 out of 5

It's big, but...

I think I got a little charmed by Atomos. This sumo 19 is very limited in it's ability to switch and record. The monitor is nice for proofing and monitoring, but it doesn't seem to be very color accurate. It's too bad convergent design is going out of business. Their product is far superior.

Scott H.

2019-03-20T08:35:49

Rated 5 out of 5

WORK HORSE MONITOR / RECORDER

WORK HORSE MONITOR / RECORDER Built well, free sun hood, REQUIRED for outdoor work

AUDIO I.

2018-11-15T14:01:48

Rated 5 out of 5

12-bit ProRes RAW from Varicam LT

The Sumo is a great monitor and recorder which has changed our workflow. We used to send footage wirelessly to a monitor, now we prefer to be wired (with a long pair of SDI cables) to the Sumo. It let’s us review clips easily and record in 12-bit ProRes RAW from the Varicam LT.

JOSE M.

2018-09-07T18:35:09

Rated 4 out of 5

Does not include USB to serial LANC cable for calibration

The bundle with the i1 profiler is an attractive deal, but it doesn’t include one critical cable required to perform calibration: the Atomos USB to serial LANC cable. You’ll need to purchase this cable separately, and it really should have been included in the package. Otherwise the i1 color checker can’t be used to calibrate the Atomos Sumo. Be sure to factor this into your purchase decision because you’ll need to spend more to buy this cable.

Anthony T.

2017-12-19T14:45:04

Rated 5 out of 5

Great monitor

A great monitor for the set and I like it very much, despite the fact that the first one I got was defective and had the UK plug with it. The replacement works very well so far and still came with a UK electric plus not a US one!!

HAMID S.

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Atomos Sumo 19" Specifications

Touchscreen

Touchscreen

Jump to...
  • Size

    19"

  • Resolution

    1920 x 1080

  • PPI

    120

  • Aspect ratio

    16:9 native

  • Color Gamut

    REC709 HDTV

  • Look up table (LUT) support

    3D LUT (.cube format)

  • Anamorphic de-squeeze

    2x, 1.5x, 1.33x, Panasonic 8:3

  • Technology

    SuperAtom IPS panel (capacitive touch), calibration to Rec.709 with optional calibration unit

  • AtomHDR

    Yes

  • Supported Log formats

    Sony SLog2 / SLog3, Canon CLog / CLog 2, Arri Log C, Panasonic Vlog, JVC JLog, Red LogFilm

  • Supported Gamuts

    Sony SGamut / SGamut3 / SGamut3.cine, Canon Cinema / BT2020 / DCI P3 / DCI P3+, Panasonic V Gamut, Arri Alexa Wide Gamut

  • Bit depth

    10-bit (8+2 FRC)

  • Brightness

    1200nit (+/- 10% at center)

  • HDR input (PQ/HLG)

    Yes / Yes

  • HDR output (PQ/HLG)

    Yes / Yes

Video Input/Loop Out

Jump to...
  • HDMI

    1 x HDMI (2.0)

  • SDI

    Quad link 4x 3G SDI or up to 12G single link SDI

  • Signal

    Uncompressed true 10-bit or 8-bit 422 (camera dependent)

Video Output (Play Out)

Jump to...
  • HDMI

    1 x HDMI (2.0)

  • SDI

    1x 4K-SDI 12G/6G or HD-SDI 3G/1.5G

  • Signal

    Uncompressed true 10-bit or 8-bit 422 (playback file dependent)

Supported Loop Out Formats

Jump to...
  • HDMI to HDMI

    720p 50/60, 1080i 50/60
    1080p 24/25/30/50/60/100/120
    2160p 24/25/30/50/60

  • SDI to SDI

    720p 50/60, 1080i 50/60
    1080pSF 24/25/30
    1080p 24/25/30/50/60/100/120
    2160p 24/25/30/50/60

Video Signal Conversion

Jump to...
  • HDMI to SDI

    720p 50/60, 1080i 50/60
    1080p 24/25/30/50/60/100/120/200/240
    2160p 24/25/30/50/60

  • SDI to HDMI

    720p 50/60, 1080i 50/60
    1080p 24/25/30/50/60/100/120/200/240
    2160p 24/25/30/50/60

Supported Codecs & FPS (Record/Playback)

Jump to...
  • Raw Record

    Sony FS5/FS7/FS700 - CDNG
    4K DCI; 24/25/30p
    4K UHD; not supported in camera
    2K; 24/25/30/50/60/100/120p
    1080; not supported in camera

    Canon C300MKII/C500 - CDNG
    4K DCI; 24/25/30p
    4K UHD; 24/25/30p
    2K; not supported in camera
    1080; not supported in camera

  • Raw Record (Cont.)

    Panasonic VaricamLT / Varicam35 - CDNG
    4K DCI; 24/25/30p
    4K UHD; 24/25/30p
    2K; not supported in camera
    1080; not supported in camera

    Arri Alexa Mini .ARI
    2880x1620; 24/25/30/50/60p
    2880x2160; 24/25/30/50/60p

  • Raw to ProRes / DNxHR

    Sony FS5/FS7/FS700, ProRes (HQ, 422, LT), DNxHR (HQX, HQ, SQ, LB)
    4K DCI; 24/25/30/50/60p
    4K DCI Burst; 120p (Sony FS series)
    4K UHD; not supported in camera
    2K; 24/25/30/50/60/100/120/200/240p
    1080; not supported in camera

    Canon C300MKII/C500, ProRes (HQ, 422, LT), DNxHR (HQX, HQ, SQ, LB)
    4K DCI; 24/25/30p
    4K UHD; 24/25/30p
    2K; not supported in camera
    1080; not supported in camera

  • Raw to ProRes / DNxHR (Cont.)

    Panasonic VaricamLT / Varicam35, ProRes (HQ, 422, LT), DNxHR (HQX, HQ, SQ, LB)
    4K DCI; 24/25/30/50/60p
    4K UHD; 24/25/30/50/60p
    2K; not supported in camera
    1080; not supported in camera

  • Video to ProRes / DNxHR

    Codecs - Apple ProRes HQ, 422, LT AVID DNxHR HQX. HQ, SQ, LB (DNx utilizes a .MOV wrapper):
    4K DCI; 24/25/30/50/60p
    4K UHD; 24/25/30/50/60p
    2K; not supported in camera
    1080p; 24/25/30/50/60/100/120/200/240p
    1080i; 50/60i
    720p; 50/60p

Onboard Processing

Jump to...
  • Pulldown removal

    24/25/30pSF > 24/25/30p (2:2 pulldown) 60i > 24p (3:2 pulldown)

  • 4K UHD downscale for HD monitoring

    Yes - Loop-out and playback (Not available in RAW)

Audio In/Out (48kHz PCM Audio)

Jump to...
  • HDMI

    2 or 8ch 24-bit, camera dependent

  • SDI

    12ch 48kHz 24-bit

  • Audio

    2ch balanced XLR analog in/out (direct XLR connection)
    Dynamic range >90dB
    Max signal level +24dBu
    Max analog gain +52dB
    48V Phantom Power for Mic

  • Headphone Out

    3.5mm

  • Built-in Speakers

    Yes

Remote Start/Stop

Jump to...
  • HDMI

    Auto HDMI Trigger, Supported Protocols - Canon, Sony, Atomos Open Standard

  • SDI

    SDI trigger camera selectable

  • Other

    LANC control - Slave

Playback

Jump to...
  • Playlist / Genlock

    Yes / Yes

  • CDNG (Recorded content)

    No support

  • ProRes (Recorded content)

    All recorded files can playback. Playback in slow motion >= 100fps

  • DNxHR / DNxHD (recorded content)

    All recorded files can playback. Playback in slow motion >= 100fps

Live Switch & Recording

Jump to...
  • ISO recording

    4 x 1080p60 Inputs

  • Switching

    Yes

Recording

Jump to...
  • Pre-roll record

    Yes (HD 8s, 4K 2s)

  • Custom timelapse

    Yes

  • Meta data tagging

    Yes (10 tags available)

  • Supported media

    2.5" SSD/HDD compatibility depends on recording format, resolution and frame rate. Visit atomos.com/drives for list of tested and approved drives

  • Master caddy dock

    2.5" SATA to USB 2.0/3.0

  • Supported applications

    Supported Applications FCPX/FCP7+ / Media Composer 5.0+ / Premiere 5.5+, EDIUS 6.0+ / Vegas Pro 10+ / Lightworks / Autodesk Smoke 2015

  • XML support

    FCPX XML native, FCPX/Adobe limited supported with 3rd party conversion tools

  • Operating power

    75W

  • Compatible batteries

    V-Lock / Anton Bauer via XLR terminal (optional mounting plates available) 95Wh or larger recommended

  • Input voltage (battery)

    14.4V nominal

  • Battery time

    Depends on Watt Hours specification of battery used

  • DC In

    1x DC in (12 - 16.8V)

  • Continuous power

    Primary-secondary battery system
    Change batteries without losing power
    Loop batteries continuously

General

Jump to...
  • Construction

    Aluminum alloy chassis with built in armor protection

  • Mounting Points

    1/4-20 screw; 4 x top, 4 x bottom, 2 x side
    3/8-16 screw; 2 x top, 2 x bottom, 1 x side
    VESA mount rear

  • Dimensions (WxHxD)

    19.8 x 12.2 x 2.5" (50.29 x 30.99 x 6.35cm) (without stand)
    19.8 x 13 x 7.1" (50.29 x 33.02 x 18.03cm) (with stand)
    Master Caddy II: 75 x 105 x 12mm (2.95 x 4.13 x 0.47")

  • Weight

    Without batteries, media & stand: 12 lbs (5.44kg)
    With stand: 13.2 lbs (5.99kg)

  • UPC Code

    814164020824

12 Accessories for Atomos Sumo 19" HDR/High Brightness Monitor Recorder / Switcher

  • All Accessories (12)
  • Cables & Adapters (5)Required Item
  • Power Supply & Accessories (2)
  • Headphones (1)
  • Cleaning Accessories (1)
  • Brackets & Mounts (1)
  • Bags & Cases (2)

About Atomos Sumo 19"

FEATURED REVIEWS

Great monitor

By HAMID S.

A great monitor for the set and I like it very much, despite the fact that the first one I got was defective and had the UK plug with it. The replacement works very well so far and still came with a UK electric plus not a US one!!

WORK HORSE MONITOR / RECORDER

By AUDIO I.

WORK HORSE MONITOR / RECORDER Built well, free sun hood, REQUIRED for outdoor work

Atomos

Live quad channel HD switching and recording

Live switch four 1080p channels and record each as separate ISOs. Switch between feeds intuitively on-screen with hard cuts. Save space by replacing several boxes in your rack with a single Sumo19.

atomos
How To Capture ProResRAW

How To Capture ProResRAW

How To Edit ProResRAW

How To Edit ProResRAW

https://www.adorama.com/g/atomos-pro-res-raw

What's in the box:

  • Atomos Sumo 19" Monitor Recorder
  • Master Caddy II Case
  • Power Supply
  • BattWing Mounting Bracket with 4x Screws
  • 2x Desktop Feet with 4x 1/4" Mounting Screws
  • Atomos 1 Year Warranty (Extended to 3 Year on Product Registration)
