Audient ASP800 8-Channel Microphone Preamplifier with HMX and IRON

SKU: AUP800 MFR: ASP800
Earn VIP Reward Points

Key Features

  • Capture pristine audio with this 8-channel microphone preamplifier, ensuring low noise recordings.
  • Sculpt your sound using the HMX & IRON harmonic enhancement, ideal for adding warmth to vocals.
  • Achieve versatile gain staging with up to 70dB of gain, perfect for dynamic microphone use.
  • Integrate seamlessly with your studio via ADAT output for digital connectivity and expansion.
  • Experience superior sound quality with Burr-Brown converters, great for professional recordings.
  • Optimize instrument recordings with the built-in JFET D.I, offering high input impedance.
See More Product Details
Special Order?Estimated to Ship: 09/08/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

2 Year

$139.99

3 Year

$184.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Audient ASP800 Specifications

Microphone Preamplifiers

Microphone Preamplifiers

Jump to...
  • MIC Gain

    0 to 70 dB (extra gain stage for more!)

  • Switchable Pad

    -15 dB (all channels front panel switchable)

  • Line Gain

    -10 to 60 dB (-25 to 45 dB inc. PAD)

  • Phantom Power

    48V +/-4V @ 10mA / channel

  • MIC EIN

    <-127.0 dBu

  • CMRR

    >80 dB @ 100Hz to 2kHz

  • Maximum Input Level

    +20 dBu (+35 dBu with PAD)

  • Input Impedance (Mic)

    >2k Ohm balanced (approx. 2.2k Ohm)

  • Input Impedance (Line)

    >8k Ohm balanced (approx. 8.6k Ohm)

  • Frequency Response

    +/-0.5 dB 10Hz to 100kHz @ min. gain

  • Crosstalk

    < -90 dBu 10Hz to 10kHz

  • THD+N @ 0dBu (1kHz)

    <0.003% (-90.5 dBu) mostly 3rd harmonic

  • SNR

    >90 dB @ min. gain

  • XLR Combi Female

    Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)

  • 1/4" TRS Jack

    Tip (Hot), Ring (Cold) & Sleeve (Shield)

Discrete JFET D.I

Jump to...
  • D.I Gain

    0 dB unity gain (0 to 70 dB)

  • Maximum Input Level

    +17 dBu

  • Input Impedance

    1Meg Ohm unbalanced

  • Frequency Response

    +/-0.5 dB 10Hz to 50kHz

  • THD+N @ 0dBu (1kHz)

    <0.01% (-80 dBu) mostly 2nd & 3rd

  • SNR

    >85 dB @ min. gain

  • 1/4" Jack

    Tip (Hot) & Sleeve (Shield)

Balanced Analogue Line Outputs

Jump to...
  • Maximum Output Level

    +22 dBu

  • Output Impedance

    <200 Ohm ground sensing, <100 Ohm unbalanced

A-D Converter

Jump to...
  • Chipset

    Burr-Brown PCM4204 24-bit PCM

  • Digital Reference Level

    Selectable via Rear Panel, 0 dBFS = +18 dBu (iD22 Professional), 0 dBFS = +12 dBu (iD14 Prosumer)

  • Frequency Response

    +/-0.1 dB 20Hz to Fs/2 (Nyquist)

  • Crosstalk

    <-110 dBFS @ 1kHz & <-90 dBFS @ 10kHz

  • THD+N @ -1 dBFS (1kHz)

    0.0015% (-96.5 dB)

  • THD+N @ -6 dBFS (1kHz)

    0.0009% (-101 dB)

  • Dynamic Range

    113.5 dB un-weighted, 116.0 dB A-weighted

  • Peak LED Lineup

    -2 dBFS (moves with reference level)

  • Signal LED Lineup

    -38 dBFS (moves with reference level)

Digital Output

Jump to...
  • ADAT 8 Channels SMUX

    44.1 to 96.0 kHz

  • Clock

    Internal Crystal or External Source

  • Wordclock Input

    75 Ohm BNC - switchable 75 Ohm termination

Power Supply

Jump to...
  • Low Noise Shielded Linear PSU

    Fanless, quiet operation: custom transformers, 35W maximum consumption

  • Internal D.C Power Rails

    +/-15V, +48, +30V & +9V

  • Switchable Mains Voltage

    100, 120, 220 or 230Va.c

  • Fuse

    200mA (UK) or 315mA (US), Time Delay (T) Slow-Blow Type

Physical

Jump to...
  • Dimensions

    18.97 x 11.27 x 1.73" (482 x 286.5 x 44mm) (1RU)

  • Weight

    9.9 lbs (4.5kg)

  • UPC Code

    5060374260153

About Audient ASP800

Make your audio recording experience superior with the ASP800 8-Channel Microphone Preamplifier with HMX and IRON. This audio powerhouse is engineered with scalability in mind, making it an ideal complement to your existing audio interface. Enhance your current setup with eight channels of Audient's Console mic preamps, eight line inputs, industry-leading converters, two JFET D.I's, and two Retro Channels equipped with robust tone control.

The ASP800 is an exceptional tool for expanding your existing interface. By adding eight channels of Audient mic pre via ADAT, you can transform your current setup into a comprehensive recording rig. This makes it easier to record drums and bands, take on larger sessions, and use line inputs to record analog instruments.

Experience the professional sound quality you deserve with the renowned Audient Console Mic Preamp. This discrete circuit design, found in our acclaimed recording console the ASP8024-HE, delivers ultra-low noise and low distortion with a touch of classic analog warmth. The ASP800's eight Audient Console mic pre's will provide you with the professional sound quality you've been seeking.

The Retro Channels feature allows you to add color to your audio. Designed to emulate tones often associated with 1960's tube designs and the coveted transformer zing of British audio in the 1970s, HMX & IRON give you the option to add analog tone to your recordings.

The ASP800 also offers two harmonically rich JFET D.I inputs, replicating the input stage of a classic valve amplifier. This allows you to plug in your guitar, bass, keyboard, or drum machine and start recording instantly.

The ASP800's industry-leading converter technology ensures that every nuance and detail of your audio is captured with stunning clarity. This, combined with its all-metal construction, hand-finished aluminum knobs, and high-grade component selection, makes the ASP800 a durable and powerful addition to any recording setup.

The ASP800 comes bundled with a free suite of creative software, including Cubase LE and Cubasis LE for iOS, alongside industry-leading plugins and virtual instruments. This allows you to start recording as soon as you open the box. With the ASP800 8-Channel Microphone Preamplifier with HMX and IRON, you're not just recording audio, you're creating a masterpiece.

Audient ASP800 Features

  • 8x Audient Console Mic Preamps
  • HMX & IRON Retro Channels
  • 2x Discrete JFET Instrument Inputs
  • Pristine Converters
  • Balanced Analogue Line Outputs
  • ADAT Output for Expandability
  • Word Clock Input
  • All-Metal Enclosure
  • Free plugins and software with ARC

Warranty Information

This product has a limited warranty of 36 months.

Product Documents

User Manual

Key Features

  • Capture pristine audio with this 8-channel microphone preamplifier, ensuring low noise recordings.
  • Sculpt your sound using the HMX & IRON harmonic enhancement, ideal for adding warmth to vocals.
  • Achieve versatile gain staging with up to 70dB of gain, perfect for dynamic microphone use.
  • Integrate seamlessly with your studio via ADAT output for digital connectivity and expansion.
  • Experience superior sound quality with Burr-Brown converters, great for professional recordings.
  • Optimize instrument recordings with the built-in JFET D.I, offering high input impedance.

What's in the box:

  • Audient ASP800 8-Channel Microphone Preamplifier
  • Mains IEC Power Cable
  • Quick Start Guide
  • Audient 3 Year Limited Warranty
