Auralex 2x24x48" Fabric-Wrapped Acoustical Absorption ProPanel with 4 CTC Corner Impaling Clips, Mitered Edge, Slate

SKU: AURM224SLA MFR: M224SLA
$196.99
Earn VIP Reward Points

Key Features

  • Improve your studio acoustics with these Auralex corner bass traps, essential for sound clarity.
  • Control low-frequency sound issues using these fabric-wrapped acoustic ProPanels in your studio.
  • Achieve balanced sound! These corner acoustic treatments absorb unwanted bass frequencies effectively.
  • Enjoy easy installation with included corner impaling clips; set up your bass traps quickly!
  • Enhance your space with these slate-colored, mitered-edge bass traps, adding aesthetic appeal.
  • Get professional-grade sound absorption; these ProPanels boast a high 1.05 NRC rating.
See More Product Details
Special Order?Estimated to Ship: 08/18/2025
Calculate Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

1 Year

$15.99

2 Year

$23.99

3 Year

$35.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Auralex Corner Traps Panel Specifications

ProPanel

ProPanel

Jump to...
  • Color

    Slate

  • Edging

    Mitered

  • Fire Rating

    ASTM-E84

  • Center Frequency

    125 Hz: 0.42
    250 Hz: 0.89
    500 Hz: 1.12
    1000 Hz: 1.07
    2000 Hz: 1.10
    4000 Hz: 1.09

  • NRC Rating

    1.05

  • Dimensions

    2 x 24 x 48" (5.1 x 610 x 1220mm)

  • Weight

    8 lb (3.6kg)

Impaling Clip

Jump to...
  • Corner Clip Size

    4.75 x 6" (121 x 152.4mm)

  • UPC Code

    818105014170

About Auralex Corner Traps Panel

Discover the transformative power of Auralex's 2x24x48" Fabric-Wrapped Acoustical Absorption ProPanel. This professional-grade, high-quality corner trap is meticulously designed to fit seamlessly within a standard 90-degree corner, enhancing the acoustics of any room by effectively absorbing low-frequency sound reflections.

Constructed with a durable, 2" thick fabric-wrapped fiberglass, this innovative bass trap is available in two sizes, 2x2' (M222) or 2x4' (M224), to cater to your specific acoustic needs. Its mitered edge design ensures a smooth, sleek fit, making it an aesthetically pleasing addition to any space.

The ProPanel comes equipped with 4 CTC Corner Impaling Clips, a standard feature across all ProPanel products. These clips can be easily mounted to the wall using standard drywall screws (sold separately), facilitating quick and effortless panel placement on virtually any surface.

For panels in low-traffic areas or when temporary mounting is necessary, the impaling clips alone are sufficient. However, for a more permanent solution, combine the impaling clips with TubeTak Pro adhesive.

Experience the difference in sound quality with Auralex's 2x24x48" Fabric-Wrapped Acoustical Absorption ProPanel, a reliable solution for superior sound absorption and reduced reverberation.

Auralex Corner Traps Panel Features

  • Acoustical ProPanel Features
  • Reduce Unwanted Acoustical Reflections
  • Tame Chaotic Reverberation
  • Improve Speech Intelligibility
  • Commercial and Residential Applications
  • Choose from A Wide Variety of Shapes, Sizes and Fabrics
  • Custom Options Available
  • Class A Fire Rated: ASTM-E84
  • CTC Corner Impaling Clip Features
  • Increase your room's low frequency absorption
  • Included with all M224 ProPanels
  • Vertical & horizontal corner installations: For horizontal corners use 2" thick panels only

Warranty Information

This product has a limited warranty of 3 months.

Key Features

  • Improve your studio acoustics with these Auralex corner bass traps, essential for sound clarity.
  • Control low-frequency sound issues using these fabric-wrapped acoustic ProPanels in your studio.
  • Achieve balanced sound! These corner acoustic treatments absorb unwanted bass frequencies effectively.
  • Enjoy easy installation with included corner impaling clips; set up your bass traps quickly!
  • Enhance your space with these slate-colored, mitered-edge bass traps, adding aesthetic appeal.
  • Get professional-grade sound absorption; these ProPanels boast a high 1.05 NRC rating.

What's in the box:

  • 2x24x48 " Corner Traps ProPanel (Slate)
  • 4x Corner Impaling Clips
  • Auralex 3 Month Limited Warranty
