ATTO Technology ExpressSAS H12F0 16-Port External Low Profile 12Gb/s SAS/SATA to PCIe 3.0 x8 Host Bus Adapter

The ExpressSAS H12F0 leverages two next-generation storage technologies - PCIe 3.0 host interconnect and a 12Gb/s SAS/SATA interface to storage. Featuring 16-external ports using the latest miniSAS HD connector, the H12F0 is designed with the enterprise customer in mind. With extensive testing and qualifications, it performs flawlessly in transactional environments such as banking, finance, business intelligence, cloud computing and database applications.

• 19200 MB/s transfer rate
• 16 external ports
• SFF-8644 miniSAS HD connectors designed to support 12Gb/s data rates (supports copper and optical cables)
• SAS, SATA, SATA II connectivity
• Backward-compatible with 6Gb/s and 3Gb/s SAS/SATA products
• RoHS Compliant
• 3-year standard product warranty
• Advanced Data Streaming (ADS) Technology provides controlled acceleration for smooth high performance data streaming
• NUMA support for high performance multiprocessor applications
• WriteStop available for specialized data security applications for OEMs
• Advanced management through ConfigTool and vConfigTool utilities
• Up to 1,200 MB/s throughput per port
• Over 1 million sustained lOPS
• Features a high-performance x8 PCIe 3.0 host interface
• Low-profile, MD2 short form factor for versatility and improved airflow
• Copper and optical miniSAS HD high-density connectors with cable management support
• Driver support for the latest Windows, Linux, VMware and FreeBSD operating systems
• Target mode software development kit available
• Automatic link negotiation: i2Gb/s, 6Gb/s and 3Gb/s SAS targets, 6Gb/s, 3Gb/s and 1/5Gb/s SATA targets
• Supports up to 2048 targets
• Supports Serial SCSI Protocol (SSP), SATA Tunneling Protocol (STP), SMP, SAT and direct attached SATA protocol
• Supports T10-DIF/PI standards
• 16MB on-board flash memory to store persistent parameters
• Wide-port end device support
• Support for advanced format storage media: 512e, 4Kn
• Supports ATAPI devices
• Dual port SAS support for redundant configurations
• Support for SAS tape devices and transport layer retries (TLR) for error handling
• Target mode driver (TMD) development kit available for storage servers, storage systems and appliances

ATTO 12Gb SAS HBAs double the performance over previous generations of SAS/SATA cards and offer fresh new features that reduce downtime, improve efficiency and save money on the bottom line. They provide more flexibility for connecting storage, greatly decrease latency to SATA drives, make it easier to manage the overall storage infrastructure and improve connection diagnostic capabilities - all at a lower total cost of ownership. Additionally, ExpressSAS HBAs provide the highest and smoothest throughput for streaming applications such as tape backup and archiving, video post-production, geologic survey and video-on-demand applications.

Industry Proven Technology
ATTO Technology, Inc.'s ExpressSAS 12Gb/s SAS host bus adapters (HBAs) provide high-performance data protection to direct attached SAS and SATA storage. For nearly 30 years, ATTO has been at the forefront of the latest innovations in storage connectivity.

Flexible Connectivity Solutions
The ExpressSAS 12Gb/s SAS HBAs are available with a wide selection of 8, 12 and 16 port options to support a dense and efficient connection to storage from rack-mounted servers and workstations in datacenter, data warehousing, video on demand and other high-availability, high-performance applications.

Performance Engineered
ExpressSAS 12Gb/s HBAs combine 12Gb/s SAS speeds and x8 PCI Express 3.0 with powerful hardware and software elements to manage latency in real-time environments. Exclusive Advanced Data Streaming (ADSTM) technology maximizes CPU processes to deliver smooth and reliable data transfers and the highest consistent performance. ATTO pays close attention to detail in board design and signal integrity to minimize transmission errors and data corruption. These differentiating capabilities make ATTO the premier choice for high-performance direct-attached SAS/SATA storage connectivity.

Advanced Management Tools
ATTO's easy-to-use ConfigTool features an intuitive GUI that simplifies the installation, management and monitoring of the host bus adapter. With advanced troubleshooting and performance tuning capabilities, ExpressSAS HBAs provide users with sophisticated diagnostics and the flexibility to control settings for specific applications.

We offer a broad array of management and diagnostic capabilities. Cables, the most significant point of failure, are often difficult to troubleshoot. ExpressSAS 12Gb/s SAS HBAs are able to help isolate cable and connector failures (and intermittent problems) through independent control of each port, as well as discovery and cable management of data passed through the mini-SAS HD connectors.

Applications
• The ExpressSAS 12Gb/s SAS/SATA family of HBAs offers the fastest available connection to direct-attached SAS or SATA storage
• The impressive speed of the 12Gb/s SAS interface, coupled with a x8 PCI Express 3.0 host interface, delivers a dense and efficient connection to all types of storage - from rack-mounted servers and workstations in data center, data warehousing, VOD and other high availability, high-performance applications
• ADS latency-management technology controls the acceleration of data transfers to move large amounts of data faster and more efficiently
