Behringer 2600-VCO Specifications

Inputs
  • Keyboard CV

    Type: 1x 3.5mm TS jack, DC coupled
    Impedance: 100 K Ohm, unbalanced
    CV range: 10 V, 1 V/oct.

  • FM1 / 2 / 3 CV

    Type: 3x 3.5mm TS jacks, DC coupled
    Impedance: 50 K Ohm, unbalanced
    CV range: 10 V, 1 V/octave

  • PWM CV

    Type: 1x 3.5mm TS jack, DC coupled
    Impedance: 75 K Ohm, unbalanced
    CV range: 10 V, typically 1 V/10%

Outputs

Jump to...
  • TRI/SINE/SAW/PULSE

    Type: 4x 3.5mm TS jacks, DC coupled
    Impedance: 1 K Ohm, unbalanced
    TRI level: +/-5 V
    SINE level: +/-5 V
    SAW level: 0 V / +10 V
    PULSE level: 0 V / +10 V

Controls

Jump to...
  • Initial oscillator frequency fader

    Sets oscillator frequency (10 oct. range)

  • Fine tune knob

    Oscillator fine tune adjustment ( +/-0.4 oct.)

  • Audio (Kybd on) / LF (Kybd off)

    Slide Switch: Select audio band (10 Hz to 10 kHz) or LFO (0.03 Hz to 30 Hz)

  • FM 1 / 2 /3 faders

    Attenuate FM inputs (-Infinite to unity gain)

  • Pulse width fader

    Pulse width adjustment (10% to 90%)

  • PWM fader

    Pulse width modulation attenuator (-Infinite to unity gain)

  • Power supply

    Eurorack

  • Current draw

    140 mA (+12 V), 5 mA (-12 V)

Physical

Jump to...
  • Rack units

    16 HP

  • Dimensions (H x W x D)

    5.08 x 3.19 x 1.65" (129 x 81 x 42mm)

  • Weight

    5.28 oz (149.68g)

  • UPC Code

    1922232393576

About Behringer 2600-VCO

Modular Synthesis
The original 2600 came out in the '70s and was a mainly all discrete transistor design with some op-amps. The discrete circuitry gave the 2600 a very distinctive sound and were used by artists like Jean Michel Jarre, Depeche Mode, Stevie Wonder and so many more. The 2600-VCO is a compact and versatile module, giving you a VCO featuring four simultaneous waveforms with the ability to control a wide frequency band for amazing flexibility. Modular synths were a landmark development in electronic music and today, it's about to get better.

2600-VCO
This is the Behringer 2600-VCO. An analog VCO module and an authentic reproduction of the original ARP 2600 circuitry that can fit in a standard Eurorack case. The best part It's at a very affordable price. Mix the 2600-VCO in with your existing rig or start your modular synth journey from here. Either way you're sure to have a lot of fun.

Mix It Up
The 2600-VCO is a feature rich module with four simultaneous waveforms: sine, triangle, saw and pulse which allow for an awe-inspiring palette of tonal possibilities. You can even control the oscillators frequency which ranges from 10 Hz to 10 kHz and from 0.03 Hz to 30 Hz when the 2600-VCO is switched to LF mode. The VCO can also be tuned to other instruments or VCOs with the Fine Tune knob. Adjust the pulse width range anywhere from 10% to 90% and you'll be ready to rock whether you're in a band or integrating the 2600-VCO into your monstrous setup!

Ins and Outs
The 2600-VCO comes with an array of FM and CV inputs. Each FM input comes with their own attenuator to control the level of modulation. A separate PWM input can be used if you want to control or modulate the Pulse waveform. The 2600-VCO even accepts control voltages from a keyboard or MIDI/CV converter which you can turn on or off with the Keyboard On/Off switch, which also switches the VCO to low frequency mode.

Eurorack Ready
Installing the 2600-VCO is easy as it is designed to fit into a standard Eurorack case. Just connect the power cables to the power supply and screw in the module using the included screws. This allows the 2600-VCO to be mixed with other synth modules for a truly unique set up.

Amazing Gear at an Affordable Price
Whether you're just getting into modular synths or looking to complete your collection, the 2600-VCO from Behringer is a great tool to have when creating amazing music.

Behringer 2600-VCO Features

  • Amazing sounding VCO module from the '70s
  • Authentic reproduction of original ARP 2600 circuitry
  • VCO features 4 simultaneous waveforms: sine, triangle, saw and pulse
  • VCO offers wide frequency control from 10 Hz to 10 kHz or 0.03 Hz to 30 Hz in LF mode
  • PWM can be simultaneously controlled manually and via external CV input
  • Switchable between LF (keyboard off) and Audio (keyboard on)
  • Separate outputs for each waveform and 5 CV inputs for pitch control and PWM
  • 8 controls and switches give you real-time access to all important parameters
  • Eurorack specs: 16 HP, XX mA +12 V, XX mA -12 V

Warranty Information

This product has a limited warranty of 12 months.

800-815-0702

Product Documents

User Manual

Key Features

  • Amazing sounding VCO module from the '70s
  • Authentic reproduction of original ARP 2600 circuitry
  • VCO features 4 simultaneous waveforms: sine, triangle, saw and pulse
  • VCO offers wide frequency control from 10 Hz to 10 kHz or 0.03 Hz to 30 Hz in LF mode
  • PWM can be simultaneously controlled manually and via external CV input
  • Switchable between LF (keyboard off) and Audio (keyboard on)

What's in the box:

  • Behringer 2600-VCO Legendary Analog VCO Module
  • Power Cable
  • Screws
  • User Manual
  • Adorama 1 Year Limited Warranty
  • 2x 3' Stereo Mini Male to Stereo Mini Male Auxilary Cable
  • 2x 6' Stereo Mini Male to Stereo Mini Female Headset Extension Cable
