16 x 1/4" TRS, balanced, line-level
+4 dBu optimal, +22 dBu maximal
-10 dBV / 0 dBu / +4 dBu / +22 dBu, adjustable
4-position switch (per channel) Digital Inputs
2 x standard TOS-link optical connector
ADAT, 16 / 20 / 24-bit 48 kHz (standard)/ 44.1 kHz
Per 8 channels
From ADAT input A only Indicators(external clock)
2 x LED's
Auto select for channels 1 - 8 /9 - 16
6 x RJ45
24-bit, 48 kHz (standard for analog in), 44.1 kHz (if ADAT 44.1 kHz)
24-bit, delta-sigma
16 channels, plus bus-power for P16-M
<0.9 ms (from P16-I to P16-M)
20 Hz to 20 kHz (+0 / -3 dB)
typical 92 dB
RJ45
Shielded CAT5
recommended: 246' (74.98)
(1U): 44 x 482 x 190mm (1.73 x 18.97 x 7.48")
4.60lbs (2.08kg)
