Behringer Xenyx QX1622USB Premium 16-Input 2/2-Bus Mixer with Xenyx Mic Preamps and Compressors, KLARK TEKNIK Multi-FX Processor

SKU: BEQX1622USB

This item is no longer available.

Recommended Alternatives

Overview
Compare
Accessories
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Behringer QX1622USB Specifications

  • Total number Of Inputs

    16 inputs

  • Mic/Line Inputs

    4 x XLR microphone inputs
    4 x 1/4" TRS line-level inputs

  • Stereo Line Inputs

    4 x 1/4" TRS left & right paired inputs

  • AUX Sends

    2

  • AUX Returns

    2 stereo returns

  • Inserts

    4

  • BUS (Group) Outputs

    2 sub groups

  • 2 Trk Master I/O

    2 x balanced XLR outputs
    2 x 1/4" TRS outputs

  • ALT I/O

    2 x 1/4" TRS sub outputs
    Stereo RCA 2-track outputs

  • Monitor Outputs

    2 x 1/4" TRS control room outputs
    1 x 1/4" stereo headphone output

  • EQ Section

    3-Band EQ with mid sweep on every channel

  • Solo/Mute

    Mute and solo buttons on every channel

  • Channel Level Control

    60 mm faders

  • Trim/Gain Control

    Yes

  • Metering

    12-Segment stereo LED meters
    Clip LEDs on every channel

  • Microphone Inputs: Type

    XLR, electronically balanced, discrete input circuit

  • Microphone Inputs: Noise (E.I.N.)

    20 to 20,000 Hz
    At 0Ohms source resistance: -134 dB / -136 dB A-weighted
    At 50Ohms source resistance: -131 dB / -133 dB A-weighted
    At 150Ohms source resistance: -129 dB / -131 dB A-weighted

  • Microphone Inputs: Frequency Response

    Preamp:
    < 10 to 150,000 Hz (-1 dB)
    < 10 to 200,000 Hz (-3 dB)

    Mic input to main output:
    <10 to 160,000 Hz: +/-3 dB

  • Microphone Inputs: Gain Range

    10 to 60 dB

  • Microphone Inputs: Maximum Input Level

    +12 dBu at +10 dB Gain

  • Microphone Inputs: Impedance

    Approximately 2kOhms balanced

  • Microphone Inputs: Signal-to-Noise Ratio

    107 dB / 110 dB A-weighted (0 dBu In at +22 dB gain)

  • Microphone: Total Harmonic Distortion

    0.005% / 0.004% A-weighted

  • Microphone Inputs: Phantom Power

    Switchable, +48V

  • Line Input: Type

    1/4" TRS connector, balanced

  • Line Input: Impedance

    Approximately 20kOhms
    10kOhms unbalanced

  • Line Input: Gain Range

    -10 to +40 dB

  • Line Input: Maximum Input Level

    30 dBu

  • Stereo Input: Type

    4 x 1/4" TRS connector, balanced

  • Stereo Input: Impedance

    Approximately 20kOhms, 10kOhms

  • Stereo Input: Gain Range

    -20 to 20 dB

  • Stereo Input: Maximum Input Level

    22 dBu

  • Stereo Input: EQ Type Mono Channels

    Low: 80 Hz, +/- 15 dB
    Mid: 100 to 8,000 Hz, +/- 15 dB
    High: 12,000 Hz, +/- 15 dB

  • Stereo Input: EQ Type Stereo Channels

    Low: 80 Hz, +/- 15 dB
    Low Mid: 500 Hz, +/- 15 dB
    High Mid: 3,000 Hz, +/- 15 dB
    High: 12,000 Hz, +/- 15 dB

  • AUX Section: AUX Sends

    Type: 1/4" TRS connector, balanced
    Maximum Output Level: 22 dBu

  • AUX Section: AUX Returns

    Type: 1/4" TRS connector, electronically balanced
    Impedance: Approximately 20kOhmsbalanced, 10kOhms unbalanced
    Maximum Input Level: 22 dBu

  • AUX Section: Main Outputs

    XLR, balanced
    Impedance: Approximately 240Ohms balanced, 120Ohms unbalanced
    Maximum Output Level: 28 dBu

  • AUX Section: Control Room Outputs

    Type: 1/4" TS balanced
    Impedance: Approximately 120Ohms
    Maximum Output Level: 22 dBu

  • AUX Section: Headphone Outputs

    Type: 1/4" TRS connector, unbalanced
    Impedance: 25Ohms
    Maximum Output Level: +21 dBu / 150Ohms (+25 dBm)

  • AUX Section: DSP

    Type: Klark Teknik
    Converter: 24-bit Sigma-Delta, 64/128-times oversampling
    Sampling rate: 40 kHz

  • AUX Section: Wireless

    USB dongle: Accepts signal from 2 independent Behringer ULM mics

  • AUX Section: USB

    Audio: Stereo In/Out
    Connector: Type B
    Converter: 16-bit
    Sample Rate: 48 kHz

  • AUX Section: Noise

    Main mix at -infinity with channel fader at -infinity: -100 dB / -102 dB A-weighted
    Main mix at 0 dB with channel fader at -infinity: -88 dB / -91 dB A-weighted
    Main mix at 0 dB with channel fader at 0 dB: -82 dB / -85 dB A-weighted

  • Mains

    100 to 240 V, 50/60 Hz

  • Power Consumption

    50 W

  • Fuse

    100 to 240 V: T 1.6 A H 250 V

  • Connection

    Standard IEC receptacle

  • Dimensions (W x D x H)

    12.8 x 13.7 x 3.50" / 325.12 x 347.98 x 88.9mm

  • Weight

    7.7lbs / 3.49kg

  • UPC Code

    713757154116

21 Accessories for Behringer Xenyx QX1622USB Premium 16-Input 2/2-Bus Mixer with Xenyx Mic Preamps and Compressors, KLARK TEKNIK Multi-FX Processor

  • All Accessories (21)
  • Headphones (3)
  • Cables & Adapters (16)
  • XLR Cables (1)
  • Microphones & Audio (1)

About Behringer QX1622USB

The Behringer xenyx QX1622USB Premium 16-Input 2/2-Bus Mixer allows you to effortlessly achieve premium-quality sound, thanks to its 4 onboard studio-grade xenyx Mic Preamps, super-easy "one- knob" studio-grade compressors and ultra-musical "British" channel EQs with semi-parametric mid band for warm and musical sound. And the easy-to-use "one-knob" compressors provide total dynamic control for the ultimate in punch and clarity, while respecting all the power and emotion you pack into every note. Add to this the KLARK TEKNIK FX processor with 32 studio-grade presets with dual addressable parameters, Tap function and storable user parameter settings - and the QX1622USB becomes an incredibly versatile mixer for your live performances.

But the xenyx QX1622USB isn't just designed to handle your live gigs; they also provide the state-of-the-art tools you need to make stunning, professional-quality recordings. Along with their built-in USB/audio interfaces, xenyx QX1622USB comes with all the recording and editing software needed to turn your computer system into a complete, high- performance home recording studio.

Studio-Quality Compressor - Stairway to Heaven
The studio-grade compressor is based on classic and famous studio equipment from the 70's. This totally transparent and musical compressor design allows your full dynamic range to shine through until your signal reaches the compression threshold, which is indicated by the highly visible status LED. The compressor increases sustain and gently smoothens out signal peaks, which is especially handy when you're laying down the funk, slap and pop - or hammering home your most-aggressive metal lines. The resulting output level lets you unleash powerful and impact-laden bass lines, while still sitting right where you need to be in the mix.

Sublimely Musical British EQ
The British consoles of the 1960s and '70s changed the sound of rock and roll - without them the British Invasion might not have happened. Those legendary mixing desks soon became the envy of engineers and producers all over the world. The channel EQ on the xenyx mixers is based on that very same circuitry, allowing you to imbue signals with incredible warmth and detailed musical character. Even when applied generously, these equalizers exhibit sweet forgiveness and superb audio quality.

KLARK TEKNIK - The Reverb that Made History
KLARK TEKNIK is recognized worldwide as one of the most prestigious British audio companies, with a 40-year pedigree and even a TEC Lifetime Achievement Award to back it up. The Company has designed and manufactured products for world-class artists and their legendary DN780 reverb processor is considered by leading audio engineers around the world as the industry standard. Check out their website to learn more about KLARK TEKNIK's legendary heritage. Behringer is proud to incorporate custom-engineered KLARK TEKNIK effects into their products. Featuring 100 world-class presets to choose from including reverb, chorus, flange, delay, pitch shift and many other amazing effects, KLARK TEKNIK created the 24-bit, studio-grade effects engine for Behringer - to give your performance that truly professional finishing touch.

Own the Stage with Digital Wireless
Get wireless-ready with the built-in, dedicated connectivity of the ULTRALINK ULM Series wireless microphone system (to be ordered separately). Wireless gives you maximum freedom and mobility without the need to run cables. The highest-quality sound is provided thanks to the ULM's digital, license-free 2.4 GHz frequency spectrum. The ULM wireless system combines professional-quality sound with simple setup and an intuitive interface for legendary audio performance right out of the box. Just plug in the ULM receiver "dongle" and instantly you have an exceptional wireless mic system. Freeing you from cables is the simply easy way to own the stage.

Special Features
The xenyx QX1622USB comes equipped with channel Inserts and the "British" 3-band EQs with semi-parametric mid band on all mono channels, plus 4-band fixed EQ on the stereo channels. Other features include 2 Aux Sends: 1 pre/post fader switchable for monitoring/FX applications, 1 post fader (for internal FX or external send) - plus Clip LEDs, Mute, Main Mix and Subgroup routing switches, Solo and PFL functions on all channels.

Recording Bliss
There was a time when the recording process called for lots and lots of expensive gear, which meant the average musician had to buy time at a recording studio - and that time was pricey indeed. But modern technology has put personal recording well within the reach of virtually anyone with access to a computer. How do you get all that music flying around your brain into your computer? That's where the xenyx QX1622USB comes in. Thanks to the built-in, bidirectional stereo USB audio interface, you can connect directly to your PC or Mac computer via a single USB cable. Now any signal source you connect to the mixer can be recorded directly to your hard drive.
Free Software Would Be Nice
Because you'll want to take full advantage of the xenyx QX1622's recording and podcasting potential, they have included all the software you'll need for audio recording, editing and even podcasting - all free of charge and downloadable from Behringer.com. You'll be ready to go live on your PC or Mac right out of the box! They have also provided a free download of more than 150 virtual instruments and FX plug-ins - turning your computer into a powerful home-based or mobile recording studio from input to output.

Compose. Record. Mix. Share
Tracktion is one of the world's fastest and easiest Digital Audio Workstations (DAW) for composing, recording, editing, mixing and sharing your music with the world. Featuring a single-screen interface and pushing the envelope in design elegance, Tracktion brings together outstanding Pro DAW features, such as dynamic automation, unlimited track count, MIDI recording and support for VST and AU plug-ins. This powerful music production software gives you all the tools of an entire professional-grade recording studio. Learning a DAW has never been easier, thanks to their vast and readily available library of resources.

Amazing Value
No matter what your audio mixing needs, the QX1622USB provides the performance and features that can take your talent to the next level, at a price that is sure to amaze you. Professional sound quality, the legendary xenyx mic preamps and easy-to-use "one-knob" compressors, British EQs, KLARK TEKNIK 24-Bit Multi-FX Processor, "Wireless-ready" mic option - and built-in USB connectivity make the QX1622USB ideal for both your live gigs and recording.

What's in the box:

  • Behringer Xenyx QX1622USB Premium 16-Input 2/2-Bus Mixer
  • Behringer 3 Year Limited Warranty
