Review Summary
QCIF, CIF, 2CIF, 4CIF, HD 720p, HD 1080p
Megapixel (arbitrary JPEG resolution up to 2048 x 1536 pixels)
PAL: 0.5 - 25 IPS
NTSC: 0.5 - 30 IPS
Bosch MPEG-4
Bosch H.264
Axis MPEG-4
JPEG/MJPEG via HTTP/TFTP
AutoDome Junior HD / HD IVA
AutoDome 100/200/300/500
AutoDome Easy IP / IP II / IP II E
Axis MPEG4 (no PTZ)
Dinion IP (MPEG4)
Dinion NBN-832V-P HD
Dinion NBN-921-P
Dinion NBx 4xx P / P IVA
Dinion NBx 4xx P SD / P SD IVA
Dinion NDx 4xx P SD / P SD IVA
Dinion HD 1080p D/N
Dinion NER-L2
Extreme IP
FlexiDome IP
FlexiDome NDN-921-P
FlexiDome NDx 4xx P / P IVA
FlexiDome HD 1080p D/N
NBC 255-P / 265 P / 225 P
NBC-255-W / NBC-265-W 265-W
NDC 265 P / 225-P / 225 P I
NDC-255-P / 255 P I
NDC-274 / 284
NTC-265-PI
NDN-265-PIO
NDN-822 x
AutoDome 700 IP
VG4 AutoDome (H.264 IP module)
VG5 AutoDome HD / SD
VOT 320V
NEI-30 IR Imager IVA
Supported Bosch H.264 and MPEG-4 encoders (video servers): VideoJet 10/1000
VideoJet X10 / X20 /X40
VideoJet X10 SN / X20 SN / X40 SN
VideoJet X1 XF / X1 XF W
VideoJet X20 XF E / X40 XF E
VIP10
VIP 1600 / 1600 XFM4
VIPX1 / VIPX1A / VIPX2 / VIPX2A / VIPX1
XF E
VJ8004 / VJ8004A
VJ8008 / VJ8008A
NWC-0700/0800 Megapixel IP camera
NWC-0900 Day/Night Megapixel IP camera
From other manufacturers:
IP cameras from Arecont Vision, Axis, Mobotix, Sony and other compatible cameras that support HTTP/TFTP and provide fixed path to JPEG image
AXIS M7014 Video Encoder
AXIS P1347 Network Camera
AXIS P5534 PTZ Dome Network Camera
AXIS Q6035 PTZ Dome Network Camera
AXIS Q1604
Sony SNC-CH240
Panasonic WV-SC386 Series PTZ
64
Maximum number of configured remote station at one receiver station: 500 (can be configured, visible in devices list)
Number of simultaneously connected remote stations at one receiver station: Maximum: 32
Czech, Danish, Dutch, German, Greek, English, Finnish, French, Hungarian, Italian, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish and Turkish
IIS must be installed and configured on the Bosch Recording Station. A custom HTTP port is possible
ActiveX required on browser
For Windows XP Professional: Maximum 3 connections to one station
Windows 7 (32-bit / 64-bit)
Windows Server 2008 (32-bit)
Windows Server 2008 R2 (64-bit)
Windows XP Professional SP3 (32-bit)
Windows Server 2003 (32-bit)
Running Bosch Recording Station (Recorder and Receiver):
Maximum recording rate: 50 Mbit/s
CPU: Core 2 Duo CPU
RAM: 2GB
Graphic Card: 32-Bit color depth (DirectX 9 Hardware Support, no shared memory)
Free disk space: 2GB on system partition
Recording partition: Dedicated partition (e.g. D:) for recording
Network adapter: 1000 Base-T, Gbit
Standard performance: NVIDIA FX380, NVIDIA FX580
High performance : NVIDIA FX1700, NVIDIA FX1800, NVIDIA FX4800
Running Bosch Recording Station (Recorder Only):
Maximum recording rate: 100 Mbit/s (no local viewing)
CPU: Quad-core Intel Xeon 5504 processor (2.0 GHz)
RAM: 4GB
Recording partition: Dedicated partition (e.g. D:) for recording, storage expansion possible with disc arrays directly attached to internal SCSI port
Reference HP servers: DL360/DL380
Supported disk arrays: DVA-xxK-xxxxxRA SCSI disk array; DVA-08E-xxxxxRA SCSI disk array; No daisy chaining, max. 16TB physical storage
Supported servers: MHW-S360xx-xx, MHW-S380xx-xx
Version 3.0
Requires 1 Gbit/s connections to central server and workstation; communication via TCP Port 135 plus 4 TCP ports and 4 UDP ports dynamically assigned in the range from 1025 to 65535
DTP3N via RS232 (only EMEA)
Any IP server using socket connections for communication
Integration via RS232: AZ1010, BZ500, BZ1012, BZ1060, FPA5000, G-Series Panels, NZ500, NZ1008, NZ1012, NZ1060, UEZ, UGM2020 (intrusion, fire, access)
Digital I/O Advantech ADAM-6017, ADAM-6018, ADAM-6022, ADAM-6024, ADAM-6050, ADAM-6050-W, ADAM-6051, ADAM-6051-W, ADAM-6052, ADAM-6055, ADAM-6060, ADAM-6060-W, ADAM-6066
The DiBos 8 OPC server (v8.7) also supports Bosch Recording Station and must be installed separately. The installation file is included on the SetupDVD (OPC server is not supported on Windows 7 and Windows Server 2008)
Up to 132 virtual inputs
800549580137
Building on DiBos technology the Recording Station uses Bosch's proven video management, recording and communications technology and takes IP based video surveillance to a new level. It forms an integral part of overall security solutions for many applications - including banks, large retailers, railway stations, city centers, industrial facilities and office buildings. With Recording Station you can retrieve live and recorded video from anywhere in the network. Whether they are on site or at a remote network location, authorized personnel have quick, convenient access to all information making Recording Station the perfect solution for surveillance over distributed networks.
Recording Station supports live viewing and recording at any resolution up to 2048 x 1536 pixels (3 Megapixel) including HD widescreen resolutions. It manages up to 64 IP video sources (Bosch and 3rd party) that are compatible to the following video compression standards:
Bosch H.264
Bosch MPEG-4
Axis MPEG-4
MJPEG via HTTP and TFTP
ONVIF camera support.
The unique, scalable GUI allows live and recorded images from multiple remote stations to be viewed from a single PC (receiver station). With this powerful function, security managers can monitor and supervise multiple locations simultaneously even if remote stations are connected through a WAN. Each camera offers in-window pan/tilt/zoom functionality from local or remote facilities. Images are displayed with date/time, location, camera name and the status of connected devices such as detectors and sensors.
Recording Station can be programmed to respond to specific situations and events automatically. In response to alarms, the system can be programmed to record at a higher quality and to transmit images or messages to security personnel. Playback is easy thanks to familiar search and navigation functions using a graphical timeline control. Users can playback recordings from multiple stations simultaneously and synchronously on one interface. Fast, powerful image search functions like the Smart Motion Search eliminate time consuming manual searches.
Export the video to an archive with the push of a single button - all digitally watermarked to ensure the credibility of your recordings. You can even export multiple cameras from different recorders. Use the scheduled export to recurrently backup your recordings on various storage devices, such as external disk arrays and NAS (network attached storage).
To ensure the highest security, all system access is controlled by multiple user authorization levels which determine individual permissions for each user to a very high level of detail. These authorization levels determine what a user can do in the system. Elements such as camera viewing and control, playback and export of recordings, as well the types of system configuration settings that are allowed can be individually configured.
Events, such as login, log-off, status changes, image transmission, video export and system shutdown are logged in a database and can be easily imported to spreadsheet programs like MS Excel. Video authentication is built-in to detect any attempt to alter the recorded images. Recording Station provides various interfaces to other systems such as Bosch access solutions and alarm panels, as well as external systems like ATM and POS terminals, fire alarm systems, number plate capture equipment and video content analysis solutions. Integration with other security and building management systems is accomplished using OPC (OLE for Process Control). When even tighter integration is required, our VideoSDK provides you with a complete toolbox of modules for playback, searching, viewing and much, much more.
Use Recording Station in a LAN environment with Bosch Video Management System to advance to a true enterprise solution which provides a comprehensive feature set such as centralized user, event and alarm management, multi-monitor workstations with zoom able sitemaps and CCTV keyboard control. For special cases when the customer wants to be hardware independent we offer a USB dongle that provides a unique Computer Signature (Dongle ID). Recording Station still needs to be licensed via a software authorization and SLMS.
This USB dongle also can be used in case the Computer Signature changes on every start of Recording Station caused by for example:
RAID which covers / alters the HDD IDs or provides an own - mostly cryptically - hardware ID
Windows 7 / Server 2008 which shows only these MACs which are actually connected
Different Windows users which have different permissions to access PC hardware
