Bosch LTC 8768/00 Signal Distribution Unit, 64 Outputs
See all Bosch items

Bosch LTC 8768/00 Signal Distribution Unit, 64 Outputs

SKU: BHLTC876800

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Bosch LTC 8768 Specifications

Electrical

Electrical

Jump to...

  • Operating Voltage

    12 VAC (supplied by main CPU bay)

  • Power

    3 W

  • Indicators

    Power: LED
    Code: LED

Connectors

Jump to...

  • Input

    9-pin connector for data/power

  • Outputs

    64 separate biphase outputs

Mechanical

Jump to...

  • Construction/Finish

    Charcoal colored metal enclosure

  • Dimensions (W x D x H)

    17.5 x 12.5 x 3.5" (445 x 318 x 89mm) Integral mounting flanges for EIA 19-inch rack

  • Weight

    4 lb (1.8kg)

Other

Jump to...

  • UPC Code

    800549009317

About Bosch LTC 8768

Main site Bi-Phase control code distribution and line driver unit for communicating to AutoDome Series cameras, receiver/drivers, switcher/ followers, and Allegiant satellite systems. it contains twice the number of output connectors which provide 64 separate outputs for driving up to 512 remote devices. Not applicable to the LTC 8100, LTC 8200, and the LTC 8300 Series systems.

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

What's in the box:

  • LTC 8768/00 Signal Distribution Unit
  • Cable with 9-Pin D-Sub Connectors
  • Connector Kit (Containing 8x Pieces of 12x Pin Connector)
  • Installation Manual
  • Bosch 3 Year Limited Warranty
