Bosch Video Management System Specifications

System Specifications

System Specifications

Jump to...

  • Maximum number of workstations

    Multicast: 100
    Unicast: 5
    (simultaneously viewing the same camera)

  • Supported GUI languages

    English, German, Dutch, Italian, Portuguese, French, Spanish, Simplified Chinese, Traditional Chinese, Russian, Hungarian, Japanese, Czech, Danish, Finnish, Greek, Norwegian, Polish, Swedish, Thai, Turkish, Korean, Arabic, and Vietnamese

  • Event reaction time

    <1 second, assuming sufficient network bandwidth

  • Alarm reaction time

    Maximum 2 seconds, assuming sufficient network bandwidth (incl. 1 live Image pane, 1 instant playback Image pane and 1 map Image pane)

  • Text data

    Restrictions for text data written into the Logbook (this applies, if entry is stored only in Logbook, not in recordings):
    10*Virtual Input (VI) with length 300 = 3000 characters: 109 items/sec (average)
    10*VI data field with length 800 = 8000 characters: 22 items/sec (average)
    10*VI data field with length 30 = 300 characters: 500 items/sec (average)(item = data input event)

  • Text data (Contd.)

    Restrictions for text data written into recordings:
    Bosch VMS can only process up to 3200 Bytes (corresponds to about 3200 English characters in Unicode) per event.

  • Bandwidth requirements for LAN

    Min. 1 Gbps for connections between:
    Operator Client and Management Server
    Operator Client and VRM/DiBos Management Server and NVR/VRM/DiBos

  • Bandwidth requirements for remote access

    >= 300kbps

  • Hardware transcoder

    Hardware transcoder VIP-XTCXF-INT or VJT-XTCXF must be configured in VRM, refer to VRM documentation.
    Hardware transcoding only applicable for VRM connected BVIP cameras.
    For transcoding live streams it is not required that the respective camera is recording.

  • Required open ports

    See Online Help or Manual for Configuration Client, chapter on used ports.

Server Specifications

Jump to...

  • Maximum number of sustained events

    For highest performance server:
    500 events/s with Logbook
    1000 events/s without Logbook
    5000 events/s at peaks (within 60 minutes) with Logbook
    500 events/s from ONVIF cameras

  • Logbook

    Supported by SQL Server 2014 Express (64-bit version)
    4 GB Logbook size

  • Maximum number of Task Schedules

    200

Server Specifications for Redundancy

Jump to...

  • Management Server Redundancy (VMware)

    Available with VMware HA.
    The following software versions are used:
    ESXi Server 5.1.0 U1 build 1065491
    vCenter Server 5.1.0 U1 build 1064983

    Required hardware
    2x HP ProLiant DL380 PCs with 8 GB RAM and 1x 4-port NIC (one DLxxx for each ESXi server)
    1x HP ProLiant DL380 PC with 8 GB RAM (for Control computer with monitoring)
    1x Bosch DSA E-Series

  • Management Server Redundancy (VMware)

    Available with VMware HA.
    The following software versions are used:
    ESXi Server 5.1.0 U1 build 1065491
    vCenter Server 5.1.0 U1 build 1064983

    Required hardware
    2x HP ProLiant DL380 PCs with 8 GB RAM and 1x 4-port NIC (one DLxxx for each ESXi server)
    1x HP ProLiant DL380 PC with 8 GB RAM (for Control computer with monitoring)
    1x Bosch DSA E-Series

  • Management Server Redundancy (VMware)

    Available with VMware HA.
    The following software versions are used:
    ESXi Server 5.1.0 U1 build 1065491
    vCenter Server 5.1.0 U1 build 1064983

    Required hardware
    2x HP ProLiant DL380 PCs with 8 GB RAM and 1x 4-port NIC (one DLxxx for each ESXi server)
    1x HP ProLiant DL380 PC with 8 GB RAM (for Control computer with monitoring)
    1x Bosch DSA E-Series

  • Management Server Redundancy (VMware)

    Available with VMware HA.
    The following software versions are used:
    ESXi Server 5.1.0 U1 build 1065491
    vCenter Server 5.1.0 U1 build 1064983

    Required hardware
    2x HP ProLiant DL380 PCs with 8 GB RAM and 1x 4-port NIC (one DLxxx for each ESXi server)
    1x HP ProLiant DL380 PC with 8 GB RAM (for Control computer with monitoring)
    1x Bosch DSA E-Series

  • Management Server Disaster Recovery

    Hyper-V from Microsoft OS requirement:
    Windows Server 2012 SR2 (64-bit)

    Minimum hardware requirements:
    2 HP ProLiant DL380 PCs with 16 GB RAM and 1x 4-port NIC, 200 GB hard disk (Hyper-V Replica)

  • Management Server High Availability

    Hyper-V from Microsoft; OS requirement:
    Windows Server 2012 SR2 (64-bit) with Domain Controller for HA

    Minimum hardware requirements:
    2 HP ProLiant DL380 PCs with 16 GB RAM and 1x 4-port NIC Shared storage for HA
    Tested with NetApp DSA E-Series 2600 with 2 controllers (Hyper-V Failover Cluster and Starwind)

VRM Specifications

Jump to...

  • Version

    3.60
    Previous versions are not supported.

  • Maximum count of VRM servers

    125 (maximum 2000 Cameras in total) (per Management Server)

  • Max. number of playback sessions

    64

PC Requirements

Jump to...

  • Operating System

    Windows 8.1 (64-bit, Professional or Enterprise)
    Windows 10 (64-bit, Professional or Enterprise, patched with Anniversary Update)

  • Operating System

    Windows 8.1 (64-bit, Professional or Enterprise)
    Windows 10 (64-bit, Professional or Enterprise, patched with Anniversary Update)

  • CPU

    Intel Core i7 4770
    3.4 GHz (up to 3.9 GHz)

  • CPU

    Intel Core i7 4770
    3.4 GHz (up to 3.9 GHz)

  • RAM

    Minimum 8 GB

  • RAM

    Minimum 8 GB

  • Free disk space

    Minimum 3 GB for Single Site Systems
    Minimum 5 GB for Enterprise Systems
    We recommend having minimum 15% free disk space.

  • Free disk space

    Minimum 3 GB for Single Site Systems
    Minimum 5 GB for Enterprise Systems
    We recommend having minimum 15% free disk space.

  • Network card

    1000Base-T

  • Network card

    1000Base-T

  • Display Resolution

    Minimum per monitor 1024x768
    1280x1024 or higher recommended

  • Display Resolution

    Minimum per monitor 1024x768
    1280x1024 or higher recommended

  • Recommended Graphic Cards

    MHW-AWGC-K2200
    MHW-AWGC-K620
    MHW-AWGC-K4200
    MHW-AWGC-K5200

Minimum VRM Server PC Requirements

Jump to...

  • Operating System

    Windows Server 2008 R2 (Standard Edition, 64-bit)
    Windows Storage Server 2008 R2 (Standard Edition, 64-bit)
    Windows 7 Ultimate, Professional (SP1, 32-bit, 64-bit)
    Windows Server 2012R2
    Windows Storage Server 2012R2

  • CPU

    1x or 2x Quad-Core Intel Xeon Processor E5606 (2.13 GHz, 8 MB L3 cache) or faster

  • RAM

    Minimum 4 GB

  • Free disk space

    1000 MB
    We recommend having minimum 15% free disk space.

  • Network card

    1 Gbps

  • Display Resolution

    1024x768 or higher

Mobile App/Web Client Requirements

Jump to...

  • Maximum number of Mobile Video

    5 (Service instances per Management Server)

  • Number of simultaneous connections

    up to 20 (per Mobile Video Service)(1 mobile device consumes 1 connection, each stream consumes another connection)

  • Supported cameras

    IP cameras with H.264 or H.263 support that are controlled by Bosch VMS (not controlled by VIDOS)
    ONVIF cameras
    BRS/DiBos/DVR cameras

  • iOS Version for iPhone/iPad

    7.1
    8.3
    9.0.2
    9.3.5
    10.0.1

  • Hardware version iPad

    iPad
    iPad 2
    iPad 3rd generation

  • Hardware version iPhone

    iPhone 4
    iPhone 4S
    iPhone 5C

  • Browser (Web Client)

    Internet Explorer 11.0.96
    Firefox 45.0.2
    Chrome 50.0.2661

Device Compatibility

Jump to...

  • Intrusion panels from Bosch

    For use with Bosch VMS, the Automation Device in the intrusion panels must be configured as Mode 2

    G-Series US1A:
    B9512G (required firmware version: 3.03.14)
    B8512G (required firmware version: 3.03.14)

    B-Series US1B: B5512 (required firmware version: 3.03.14)
    B4512 (required firmware version: 3.03.14)
    B3512 (required firmware version: 3.03.14)

  • Intrusion panels from Bosch

    For use with Bosch VMS, the Automation Device in the intrusion panels must be configured as Mode 2

    G-Series US1A:
    B9512G (required firmware version: 3.03.14)
    B8512G (required firmware version: 3.03.14)

    B-Series US1B: B5512 (required firmware version: 3.03.14)
    B4512 (required firmware version: 3.03.14)
    B3512 (required firmware version: 3.03.14)

  • Barco Monitor WallTransform

    Barco RCPPlus-Agent 0.9.0.7 (N Series)

  • Analog Matrix Switch

    Bosch Allegiant series
    Firmware 8.75 or later
    Master Control Software version 2.94

  • Bosch POS/ATM Bridge

    Version 1.10.00.12(63029)/2010-9-10

  • CCTV Keyboard

    KBD-Universal XF keyboard (USB keyboard)
    Bosch IntuiKey keyboard, firmware version 1.96

  • Digital I/O

    Digital I/O Advantech ADAM-6050, ADAM-6052, ADAM-6060, ADAM-6066

  • Digital Video Recorders

    DVR 431, 440, 451, 480, 630, 650, 670, 700 series (maximum 50 managed DVRs per Management Server)

    Bosch Recording Station 8.10, 8.11
    DIVAR AN 3000 / 5000
    DIVAR hybrid 3000 / 5000
    DIVAR network 3000 / 5000

  • Digital Video Recorders

    DVR 431, 440, 451, 480, 630, 650, 670, 700 series (maximum 50 managed DVRs per Management Server)

    Bosch Recording Station 8.10, 8.11
    DIVAR AN 3000 / 5000
    DIVAR hybrid 3000 / 5000
    DIVAR network 3000 / 5000

  • USB to Serial adapter

    Belkin serial adapter cable F5U103vea

  • Ethernet to Serial adapter

    Comtrol DeviceMaster RTS 4-Port

  • BVIP Devices

    DINION IP starlight 6000 HD, DINION IP starlight 7000 HD, FLEXIDOME IP starlight 6000 VR, and FLEXIDOME IP starlight 7000 VR

    FLEXIDOME IP panoramic 5000/7000 FLEXIDOME and DINION 2000/4000/5000/7000/8000/9000 cameras seriesBVIP Devices

  • BVIP Devices (Contd.)

    EXTEGRA IP 9000; MIC 7000 with VIDEOJET 7000 (supporting alarm inputs, and outputs, audio, washer relay, local recording and playback); MIC 612/550

    MIC 550, 612, MIC7000 cameras with VIDEOJET connect 7000 (supporting alarm inputs and outputs, audio, washer relay, local recording, and playback)

  • BVIP Devices (Contd.)

    EXTEGRA IP 9000; MIC 7000 with VIDEOJET 7000 (supporting alarm inputs, and outputs, audio, washer relay, local recording and playback); MIC 612/550

    MIC 550, 612, MIC7000 cameras with VIDEOJET connect 7000 (supporting alarm inputs and outputs, audio, washer relay, local recording, and playback)

  • ONVIF cameras

    Maximum 2000 ONVIF cameras

  • Unmanaged sites

    Maximum 9999 unmanaged sites.

    Supported unmanaged devices:
    Bosch VMS, DIVAR IP 3000/7000, DVR 431, 440, 451, 480, 630, 650, 670, 700 series, DIVAR AN 3000, DIVAR AN 5000, DIVAR hybrid 3000 / 5000
    DIVAR network 3000 / 5000, BVIP devices
    Maximum 5 DVR/DIVAR AN devices per site

  • Connectivity

    Version 4.2 / 4.3 (with Building Integration System)

  • Foyer Card Readers

    Maximum 2 readers per Management Server are supported.
    MINITER 485 is supported.

  • DTP 3N Box

    Allows for connecting maximum 4 ATM devices to your Management Server.

  • Audio devices

    Supported audio formats:
    G.711
    L16

Remote Access

Jump to...

  • VRM

    Live, playback, PTZ control

  • NVIF

    Live, playback, PTZ control (all via VSG)

  • Local Storage

    Live, PTZ control

  • Live Only

    Live, PTZ control

  • BRS/DiBos

    Not possible

  • DVR

    Live, playback, PTZ control

About Bosch Video Management System

You can elevate your security system with the Bosch BVMS Video Management System, Enterprise Edition V7.5. This advanced and sophisticated software is a comprehensive IP video security solution that seamlessly manages digital video, audio, and data across any IP network. It's specifically designed to maximize the unique capabilities of Bosch CCTV devices, making it the ideal VMS for Bosch cameras and recording solutions.

This innovative system is not limited to Bosch products alone. It offers interfaces and standards to integrate systems from other manufacturers, making it a versatile choice for diverse security needs. The high-tech system is equipped with an embedded resilience feature, ensuring continuous operation even in the event of Management and Recording Server failures.

The Bosch BVMS Video Management System is a state-of-the-art solution that supports intelligent Video Analyses and unmatched recording technology, capable of managing up to 2000 cameras with a single server. This dramatically reduces the total cost of ownership, making it a cost-effective solution for large-scale operations.

The system design is highly flexible, supporting single Management Server System for up to 2000 cameras out of the box. It also supports multi Management Server requirements for large industrial facilities like metros and airports across different time zones. It can monitor up to 10,000 cameras across 10 subsystems per user group, resulting in a total of 200,000 cameras.

The system also supports access to live PTZ control and recorded video of up to 9999 sites with Bosch DVR recorders, DIVAR IP 3000 / 7000, and single Management Server systems. It is installed on a Microsoft Windows Operating System and is optimized for use with Bosch Workstations and Servers.

The Bosch BVMS Video Management System also includes a range of software components for comprehensive management, monitoring, and control. These include the Management Server software, Enterprise Management Server, Video Recording Manager (VRM), Configuration Client software, Config Wizard software, Bosch VMS Appliance, Operator Client software, Mobile Video Service, Mobile App, Web Client, and Bosch Video Streaming Gateway.

With the Bosch BVMS Video Management System, Enterprise Edition V7.5, you can ensure efficient, reliable, and high-quality video management for your security needs.

Bosch Video Management System Features

  • Maximum resilience to ensure continuous operation
  • Up to 2000 cameras with a single recording server mean high savings
  • Smart automatic stream switching for live viewing
  • Best integration with Bosch video hardware
  • Encrypted communication to cameras

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Advanced IP video security solution seamlessly managing digital video, audio, and data
  • Sophisticated system designed to maximize the capabilities of Bosch CCTV devices
  • High-tech embedded resilience feature for continuous operation during server failures
  • Flexible system design supporting single and multi Management Server requirements
  • Comprehensive range of software components for efficient management, monitoring, and control
