Bosch NDC-225-PI Day/Night Infrared IP Dome Camera
See all Bosch items

Bosch NDC-225-PI Day/Night Infrared IP Dome Camera

SKU: BHNDC225PI

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Bosch Infrared IP Dome Camera Specifications

  • Video

    Sensor type: 1/4" CMOS
    Sensor pixels: 640 x 480
    Sensitivity: 1.0 lux
    Video resolution: VGA, QVGA
    Video compression: H.264 MP (Main Profile); H.264 BP+ (Baseline Profile Plus); M-JPEG
    Frame rate: 30fps

  • Lens

    Lens type: Fixed 4mm,F1.5
    Lens mount: Board mounted

  • Connection

    Analog video out: 2.5 mm jack for installation only
    Alarm input: Short or DC 5V activation
    Relay out: Input rating Maximum 1 A 24 VAC/VDC

  • Audio

    Audio input: Built-in microphone, Line in jack connector
    Audio output: Line out jack connector
    Audio communication: Two-way, full duplex
    Audio compression: G.711

  • Local Storage

    MicroSD card slot (card not included)

  • Storage

    Memory card slot: Supports up to 32 GB microSD/SDHC card

  • Network

    Protocols: HTTP, HTTPs, SSL, TCP, UDP, ICMP, RTSP, RTP, RTCP, IGMPv2/v3, SMTP, POP3, FTP, DHCP client, ARP, DNS, DDNS, NTP, SNMP, UPnP
    Ethernet: 10/100 Base-T, auto-sensing, half/full duplex, RJ45
    PoE: IEEE 802.3af compliant

  • Power Consumption

    6.6 W (max)

  • Operating Temperature

    -10 Degree C to +45 Degree C (14 Degree F to +113 Degree F)

  • Storage Temperature

    -20 Degree C to +70 Degree C (-4 Degree F to +158 Degree F)

  • Dimensions

    Diameter: 5.32" (135mm)
    Height: 4" (102mm)

  • Weight

    1.25 lb (566g)

  • UPC Code

    800549582001

About Bosch Infrared IP Dome Camera

The Bosch NDC-225-PI infrared IP dome camera is a ready-to-use, complete network video surveillance system inside a compact camera. This camera brings Bosch's high-performance technology into the realm of small office and retail businesses by offering a cost-effective solution for a broad range of applications. The camera uses H.264 compression technology to give clear images while reducing bandwidth and storage by up to 30%. The built-in active infrared illuminator provides high performance in extreme low-light environments.

Bosch Infrared IP Dome Camera Features

  • Complete network video surveillance system
  • High performance in extreme low-light
  • Sharp images of moving objects
  • Dual H.264 and M-JPEG streams simultaneously
  • ONVIF conformant

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Complete network video surveillance system
  • High performance in extreme low-light
  • Sharp images of moving objects
  • Dual H.264 and M-JPEG streams simultaneously
  • ONVIF conformant

What's in the box:

  • NDC-225-PI Day/Night Infrared IP Dome Camera
  • Quick Installation Guide
  • Installation Paper Sticker
  • Torx Screwdriver for Dome Cover
  • CD ROM
  • Camera Attachment Screw Kit
  • MicroSDHC Card
  • Universal Power Supply with US/EU and UK Plug
  • Bosch 3 Year Limited Warranty
