Bosch EX30-IP Infrared Imager, 940nm, 5-50mm, White

The EX30 is a single-sensor infrared imager for outdoor day/night surveillance applications. The EX30 features a 5-50 mm lens, the longest identification range of the infrared imagers at telephoto (150 ft), Black Diamond infrared illumination and a powerful processor for Intelligent Video Analysis (IVA). The EX30 also provides detection-level night-time imaging up to 330 ft, resulting in outstanding versatility for critical 24/7 surveillance applications.

The EX30-IP Infrared Imager includes a 5-50mm IRcorrected lens and Black Diamond infrared illumination, calibrated to provide industry leading night vision imaging.

The EX30 provides outstanding day and night imaging performance with lower bandwidth network impact than standard IP cameras. Ideal for critical applications such as force protection, perimeter surveillance and public area surveillance.

Functions

Intelligent Video Analysis (IVA)
• On-board video content analysis monitors scene activity and flags user-defined events such as alarms (additional license required)

Black Diamond Infrared Technology
• Black Diamond technology eliminates hotspot foregrounds and underexposed backgrounds
• Extended range infrared to deliver detection-level imaging at 100 m (330 ft)
• Reduces image noise and enables better compression, reducing bit rates and enhancing network stability
• Enables effective night-time performance of video analytics

Rugged All-Weather Construction
• Weather-sealed housing design to NEMA 4X
• Cable-managed wall bracket
• Sliding optical chassis for easy-optical adjustments

High Performance Video Encoder
• MPEG-4 and MJPEG at 30 fps, full resolution
• Tri-stream video allows for simultaneous high resolution viewing with high efficiency storage (or vice versa)
• Supported by a wide range of VMS and NVR solutions

Precision Engineered Performance Optics
• 540 TVL hi-resolution day/night CCD for vivid daytime color and outstanding night vision
• 5-50 mm infrared-corrected lens delivers a wide surveillance range from 45 m (150 ft) to 100 m (330 ft) for maximum imaging versatility
• Infrared-corrected lens eliminates focus shift and infrared bleed
