Bosch LTC 8300 32x6 Matrix Switcher with LTC 8555 Keyboard

Allegiant Matrix Switcher Systems
Bosch Security Systems' Allegiant Matrix Switchers are designed to meet the specific needs of your security application. Featuring full matrix switching capabilities and state-of-the-art technology, these highly reliable products have a proven field history providing enhanced performance and unique system features. Simple to use, yet feature rich, these switchers are easily customized to meet even the most demanding requirements. The Allegiant series was not only designed with the operator in mind, it is also installer friendly. Utilizing high density switching electronics means less rack space usage, less external connections to make, and less time required to complete the installation. Convenience and simplicity is the name of the game.

Sophisticated technology provides a full set of system features:
• Full Crosspoint matrix provides switching of any input to any or all outputs.
• Up to 60 sequences can be programmed to run independently in either a forward or reverse direction. SalvoSwitching mode allows any number of system monitors to be programmed to switch as a synchronized group.
• Computer interface ports allow you to use an external PC with our GUI software to make system operation and programming intuitive.
• Operate a group of remote Allegiant Satellite sites from a central Master location.
• Flexible alarm response modes.
• Control, configure and update over the video cable with Bilinx Bi-directional Communication Technology
• Compatible with many popular third party Access Control platforms.
• High density, installer friendly design means less rack space usage and quicker installs.
• 48-character on-screen display for time/date, camera number, camera title, and status/monitor title.
• Powerful system macro functions for implementing customized user defined scripts.
• Hybrid analog and digital integrated system configurations possible with Bosch IP devices.
• Product meets applicable industry immunity and safety standards.
• Intuitive system operation and control realized through user-friendly keyboards and/or the Allegiant GUI PC-based software package.
• 2-digit site and 4-digit camera identification mode

LTC 8555/00 Allegiant Keyboard
The LTC 8555/00 Allegiant Keyboard is used with the LTC 8200 Allegiant Video Switcher. It provides a convenient means of operating and configuring the switcher. It is equipped with a variable-speed pan and tilt joystick control for positioning cameras, and also has an attractive screen for displaying camera information.

The Allegiant Keyboard and Allegiant Video Switcher are used with the DCN Next Generation Automatic Camera Control software. A range of Allegiant Keyboard accessories is available, including a keyboard extension cable, keyboard extension kit and keyboard rack mount kit.

Controls and Indicators
• Joystick control
• On-screen display
