Bosch AutoDome 100 Fixed Color Analog Indoor Pendant Camera, 2.7-13.5mm Lens, Tinted Bubble

The AUTODOME 100 Series is an easy to install fixed camera that delivers superb video in all indoor and outdoor applications. The camera features day/night functionality for high quality images in low light conditions. This discrete dome camera has an IP66 rating ensuring reliable uncompromised functionality even in dusty and potentially wet environments. By using the same housing components, all AUTODOME installations have a consistent look, and observers have no idea which type of camera (if any) is watching over them.

100 Series highlights
The AUTODOME 100 Series combines the same highquality housings used by AUTODOME PTZ cameras with the award-winning imaging technology of Dinion high-resolution color or day/night fixed cameras and varifocal lenses.

The AUTODOME 100 Series supports a variety of standard and optional video and data transmission methods, including Bilinx (over coax and UTP) and fiber. Remote control, configuration, and firmware updates can also be performed over these cables, offering you unparalleled control of your cameras.

The AUTODOME 100 Series maximizes your security investment by integrating with Bosch video storage products, as well as the full range of Bosch video over IP products.

And, the AUTODOME 100 Series is simple to install and use. The in-ceiling and pendant housings come fully assembled. The pendant housings are ready for wall or pipe applications with the proper mounting hardware (purchased separately). Also available for pendants, are corner, mast, and roof mounting kits which allow the AUTODOME 100 Series to be easily adapted to the individual site requirements.

Functions
The following are some of the features that make the AUTODOME 100 Series the most flexible fixed dome camera in the security industry.

High-performance camera features
AUTODOME 100 Series cameras have a 1/3" color or day/night CCD with Bosch's unique 15-bit Dinion digital imaging technology to deliver a 32-fold sensitivity improvement and a full 540 horizontal lines of resolution. In addition, AUTODOME 100 Series cameras incorporate a number of features not found in other fixed dome cameras.

These include:
• XF-Dynamic - Extends the camera's dynamic range to deliver sharper, more detailed images and outstanding color reproduction accuracy.
• NightSense - Automatically activated under low-light conditions to extend the 100 Series' exceptional sensitivity by a factor of three during monochrome operation.
• SensUp - Increases integration time by a factor of 10 to dramatically enhance sensitivity.
• Back Light Compensation (BLC) - A fully programmable backlight compensation (BLC) area of interest and variable BLC level let AUTODOME 100 Series day/night cameras overcome even the most challenging entrance, vestibule, and lobby applications.
• Auto Black - Enhances contrast by compensating for reduced contrast due to fog, mist, or glare.
• Default Shutter - Automatically adjusts to the lens opening at fast shutter speeds, eliminating motion blur and providing remarkably clear and detailed images of fast-moving objects.

AUTODOME 100 Series day/night versions automatically switch from color to monochrome by removing a mechanically switching IR filter in low-light conditions. This boosts the infrared illumination sensitivity while maintaining superior image quality.

Unsurpassed reliability
All housings feature recessed screws and latches for increased tamper resistance. AUTODOME pendant housings (indoor and outdoor) are rated to provide IP 66 protection. In addition, the pendant housings come equipped with a low-impact, high-resolution acrylic bubble for enhanced image clarity. Outdoor Pendant housings provide an operating temperature range down to -40 degree C (-40 degree F).

AUTODOME in-ceiling housings provide IP54 (with optional kit) protection and are rated IK 8 (IEC 62262). These housings feature an impactresistant polycarbonate rugged bubble to protect your camera from vandalism. The rugged bubble can withstand impacts equivalent to a 4.5 kg (10 lb) weight dropped from a height of 3 m (10 ft).

Ease of installation and servicing
Bosch's innovative software, the Configuration Tool for Imaging Devices (CTFID), allows operators or technicians to change camera settings, and even update firmware from virtually anywhere without need for additional wiring.
