Blackmagic Design ATEM Monitoring Rack Panel 40
SKU: BMDATEMRPN MFR: SWPANELABRMP40
Earn VIP Reward PointsKey Features
- Seamlessly convert 10G Ethernet SMPTE-2110 to 12G-SDI and HDMI outputs for versatile monitoring.
- Enjoy high-quality video monitoring with reliable signal conversion for your live productions.
- Simplify your setup with this essential monitoring rack panel, perfect for complex multimedia mixers.
- Experience effortless integration into existing systems, enhancing your production workflow.
- Achieve professional-grade video output, ensuring every detail is perfectly displayed and monitored.
- Trust in Blackmagic Design's robust engineering for consistent, high-performance video monitoring.
Pre Order Now?
Free Expedited Shipping
See Options
1
Add Adorama Protect:
Available to U.S. customers only.
Need help? Ask our experts.
Overview
Compare
Specs
Protection
About Blackmagic Design ATEM Monitoring
ATEM Monitoring Rack Panel, a new combination monitoring converter and control panel that can be used with ATEM Constellation IP live production switchers. The ATEM Monitoring Rack Panel converts SMPTE 2110 IP to HDMI and 12G-SDI for connecting to monitors, however it also has front panel input buttons for controlling the switcher as well as an LCD and talkback connections.
The ATEM 4 M/E Constellation IP’s broadcast style design features front-to-back cooling so there is limited space for front panel controls. To solve this problem customers can add an ATEM Monitoring Panel into their rack. It has the same controls as regular ATEM Constellation SDI models, but it’s an independent monitoring converter and control panel combination. It features a rack mount design with premium buttons for operating their ATEM 4 M/E Constellation IP switcher. There's even a dedicated Ethernet control port. It’s also a redundant 10G Ethernet SMPTE-2022-7 to 12G-SDI and HDMI converter so customers can connect to local video monitoring. There's even a 5 pin talkback interface on the front panel.
Blackmagic Design ATEM Monitoring Rack Panel 40 Features:
- Monitoring converter built into a rack mount ATEM control panel.
- Converts 10G Ethernet SMPTE-2110 to 12G-SDI and HDMI outputs.
- 2 Redundant 10G Ethernet ports for SMPTE-2022-7 compliance.
- Includes dedicated NMOS connection for routing IP sources.
- Front panel LCD allows monitoring of video and audio meters.
- Front panel includes a 5 pin broadcast talkback headset connector.
- Dual redundant AC power supplies for broadcast reliability.
Warranty Information
This product has a limited warranty of 12 months.
