Blackmagic Design ATEM Mini Extreme ISO G2 Switcher

9

4

4

1.5G, 3G

8x HDMI type A, 10-bit HD switchable.
2 channel embedded audio

3

3

2x XLR Combo with phantom power.
1x BNC 32 Ch MADI digital audio

1x 6.35mm headphone jack

None

None

On all 8 HDMI inputs and remote sources

On all 8 HDMI inputs and remote sources

2x USB-C supporting 720p or 1080p at PGM frame rate

1x HDMI
1x Webcam

Ethernet. Direct connection between panel and chassis, or via network

Yes

On Blackmagic HDMI and remote cameras

1x 1G Ethernet for simple streaming, control panels and internet connection,
1x 10G Ethernet connection for recording

2x USB Type-C 3.1 Gen 1 for external drive recording, webcam out, software control, software updates and panel connection.
1x Thunderbolt for fill key video out, video input, ethernet to storage, and power

720p50, 720p59.94, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
1080i50, 1080i59.94, 1080i60

1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60

1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60

4:2:2 YUV

10-bit

Rec 709

1280 x 720p 50Hz, 59.94Hz and 60Hz
1920 x 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60Hz
1920 x 1080i 50, 59.94Hz and 60Hz

Hardware based real time

1

10

NKK Buttons

1

Set using Multi Function Controls and Fairlight Audio Status Output

6

Set using Multi Function Controls and Fairlight Audio Status Output

Set using Multi Function Controls and Fairlight Audio Status Output

8

6

1

2

2

6

1 NKK button

4

2

Up to 4

1

2

Up to 4

DVE only

2

Set using Multi Function Controls and Fairlight Audio Status Output

16

Red for program and green for preview indication

26 input x 2 channel mixer.
(8 HDMI+16MADI+XLR+Thunderbolt)
Selectable On/Off/Audio-Follow-Video per channel plus separate gain control per channel.
Level and Peak metering. Plus new Fairlight audio enhancements: Compressor, Gate, Limiter, 6 bands of parametric EQ. Master gain control

Balanced stereo XLR combo connectors

Up to 8 frames

+48V phantom power on XLR combo inputs

Up to 8

RTMP/SRT video with audio over a local network or internet connection from compatible Blackmagic Design cameras outputting HyperDeck High, HyperDeck Medium, HyperDeck Low, Streaming High, Streaming Medium or Streaming Low quality setting

Mapped to inputs in ATEM Software Control Settings

Supports direct live streaming using Real Time Messaging Protocol (RTMP) and Secure Reliable Transport (SRT) over ethernet or a shared internet connection over USB-C

CFExpress slot for recording
Network Recording
USB-C Recording

8x HDMI ISO inputs as H.264 .mp4 files at up to 70Mb/s quality at the ATEM video standard with AAC audio.
1x Program out as H.264 .mp4 file at the Streaming quality setting and at the ATEM video standard with AAC audio

26x 2 channel audio inputs recorded as separate 24-bit 48KHz .wav files. Including 1 x analog 2 channel audio input, 8 x Input source 2 channel embedded audio inputs and 32 x MADI audio channels

Program switching recorded as a DaVinci Resolve project .drp file

Supports media formatted ExFAT (Windows/Mac). APFS or HFS+ (Mac)

Configurable to 16, 13, 10, 7 or 4 up views including Program, Preview, 8 HDMI inputs, SuperSource, Clean Feed, Media Player, Streaming Status, Recording Status and Audio Meters

HD

2

Fill and key for each Media Player

20 with fill and key

200 frames in 1080 HD.
PNG, TGA, BMP, GIF, JPEG and TIFF

TGA Sequence

WAV, MP3 and AIFF

Built in control panel.
Software control panel with camera control included. Supports optional hardware panel

Ethernet supports 10/100/1000/10G BaseT.
Ethernet used for direct connection between panel and chassis or via network. Also supports direct USB-C connection. Ethernet or USB-C used for updating the software

Includes ATEM Software Control Panel.
Also compatible with ATEM Micro Panel, ATEM 1 M/E Advanced Panel, ATEM 2 M/E Advanced Panel and ATEM 4 M/E Advanced Panel.
Can be configured using Blackmagic Videohub Hardware Panel Setup utility to route sources to destinations using Videohub Smart Control Pro and Videohub Master Control Pro

ATEM Software Control Panel included free for Mac 10.14 Sonoma, Mac 10.15 Sequoia or later and Windows 11, Windows 10 64 bit only

58 Channel mixer.
Selectable On/Off/Audio-Follow-Video.
Level and Peak metering.
Master gain control.
6 band parametric EQ,
Dynamics including Expander,
Gate, Compressor and Limiter

When used with most Blackmagic Design cameras, ATEM can control focus, iris and zoom of compatible lenses and camera settings including gain, white balance, tint, shutter, ND filter, color corrector, tally and record start/stop

ATEM Software Control Panel included free for macOS 14.0 Sonoma, macOS 15.0 Sequoia or later. and Windows 10 or 11

Using USB or Ethernet connection directly connected to macOS or Windows computers.
Includes ATEM Setup Utility

Set via ATEM Software Control, excluding ATEM chassis IP address which is set via the ATEM Switcher Utility connected via USB to chassis

Mac 14.0 Sonoma, Mac 15.0 Sequoia or later.
Windows Icon: Windows 10 and 11, Windows 11 for ARM

1x External 12V power supply

41 - 104 Degree F (5 to 40 Degree C)

14 to 140 Degree F (-10 to 60 Degree C)

0% to 90% non-condensing

16.3 x 7.35 x 1.97" (41.4 x 18.66 x 5cm)

4.09 lbs (1.85kg)

9338716009965
