Bosch LBB 4511 Integrus Medium-Power Radiator, Cover Up to 1300m2, Bronze

These radiators are used to distribute infrared signals throughout the conference venue, enabling delegates to listen to the proceedings by means of personal pocket receivers.

• LBB 4511/00 covers up to 1300 m2 (one carrier, 4 standard quality channels)
• Automatic gain control ensures the IREDs (infrared emitting diodes) function with maximum efficiency
• Power output selection for efficiency and economy
• Safety eye

Functions
• Universal mains power facility allows use worldwide
• No fan - cooled by convection - resulting in quieter operation and less moving parts to wear out
• LED indicators for radiator status checking
• Communication between radiator and transmitter for easy checking by the operator
• Automatically switches on when transmitter is switched on and vice versa
• Automatic cable equalization ensures maximum transmission efficiency with different quality of cables
• Automatic cable termination simplifies installation
• Temperature protection circuitry automatically switches radiator from full- to half- power if the temperature becomes too high
• Adjustable radiator angle ensures maximum coverage
• IREDs protected by a cover plate, making the units easy to maintain and clean
• Attractive and stylish design

Controls and Indicators
• Two yellow LEDs: one on each radiator panel to indicate that this panel is switched on and is receiving carrier waves from the transmitter
• Two red LEDs: one on each radiator panel to indicate that this panel is in standby mode
• Red and yellow LEDs simultaneously illuminated to indicate the radiator panel is malfunctioning
• Red LED flashing and yellow LEDs to indicate the radiator panel is in temperature protection mode
• Power reduction switch to reduce the output of the radiator to half-power
• Two delay compensation switches to compensate for differences in cable lengths between transmitter and radiators

Interconnection
• Male Euro socket for mains connection
• HF input and output connectors (2x BNC) for connection to transmitter and loop-through to other radiators
