BSS SW9015 Wall Controller, 8 Position Source/Preset Selector and Up/Down Momentary Buttons, United States, Beige

The Soundweb London SW9015US Wall Controllers is simple analog wall controller which provide a cost-effective and familiar interface to even the most involved audio / video system. The SW9015US is designed to be installed in a single-gang US back box. The SW9015US feature an eight position source / preset selector and an up / down pair of momentary buttons. The simple analog wall controllers are designed to connect to the Control Inputs of the Soundweb London BLU-800,BLU-320, BLU-160, BLU-120, BLU-80, BLU-32 and BLU-16 devices.

The SW9015US require three Control Inputs. This controller is configured using HiQnet London Architect and almost any parameter can be mapped to the controls. However, the most common uses for these simple analog wall controllers are to select between sources and control level for a single zone or select between presets and control level for a single zone. The SW9015US provide the building blocks of the perfectly tailored system solution.
