Bright Tangerine LeftField 3 DJI RS 4/RS 3 Quick Release Baseplate for Canon C70 Camera

Add a dual-stage quick-release base to your Canon C70. Simply release the top stage to transfer straight to a DJI RS 4 or RS 3 gimbal and the lower stage for any ARRI standard dovetail. Kit includes: The LeftField 3 15mm LWS Baseplate core, Low profile dovetail plate, and the dovetail & riser for the DJI RS 4 & RS 3.

This Bright Tangerine baseplate kit is designed for Canon EOS C70 users wanting to add the quick-release 15mm LWS baseplate with support for 15mm rods. With the included RS 4 dovetail plate, transitioning from gimbal to tripod or handheld is seamless. Quickly release between setups without the need to dismount or swap plates.

The top stage releases the DJI RS 4 dovetail, so you can quickly transition to a compatible DJI gimbal, and the lower stage allows you to securely lock off the camera onto any ARRI standard balance plate.

The whole kit combined is extremely lightweight & low profile, which keeps all of your Canon C70 builds, nimble and compact.

Unique Open UP Quick-release System
The baseplate kit features our patented Open UP Quick-Release system that lets you slide, lock & vertically release the camera from any ARRI standard balance plate, or the included low profile dovetail plate.

LeftField 3 System
Customize your camera build with the extensive selection of accessories in the LeftField system. Letting you create the right setup for each and every task. This kit has been updated to LeftField 3 and is not compatible with LeftField 2 accessories.

No Compromises
Machined and hand-finished in our single factory in Church Crookham from high-grade materials. Hard anodized for extended durability.

- LeftField 3 15mm LWS QR Baseplate Core -
Add a riser for your compatible camera and securely lock onto any ARRI standard balance plate or dovetail. With support for 15mm rod support, you can outfit your camera for any cinematic challenge.

Upgrade your production with the LeftField 3 15mm LWS Quick Release Baseplate Core, streamlining your filming workflow and helping you accomplish more in less time.

Vertical Lift Off
Feel secure with our patented Open Up quick release system, providing the confidence that your camera will remain safely and securely locked off, with no danger of it slipping or falling off

• The lever has three positions - locked, slide & release
• When the lever is in its rearmost position, the bridgeplate locks firmly into place
• Position the lever to the midpoint, allowing you to shift your bridgeplate along the balance plate with ease
• To release the camera, press the safety eject button on the lever and adjust the lever to its forward position

Accessory Mounting
The baseplate offers a secure and sturdy foundation for mounting accessories on 15mm rods, including lens supports, focus motors, matte boxes, hand grips and more. When you pair our Drumstix rods with the bridgeplate, you'll get a combination of strength and lightweight performance that can't be beaten.

The sides feature mounting points for compatible side plates and the rear has mounting points for the LeftField 3 KASBAH Shoulder Pad.

LeftField 3 System
Customize your camera build with the extensive selection of accessories in the LeftField system. Letting you create the right setup for each and every task The 15mm LWS Baseplate Core has been updated to LeftField 3 and is not compatible with LeftField 2 accessories

Features
• Compatible with multiple camera systems using LeftField risers, setting correct 15mm LWS height and spacing
• Safe and reliable Open Up quick release system
• Compatible with LeftField 3 & ARRI standard balance plates
• Compatible with KASBAH shoulder pad
• Mounts onto any ARRI standard bottom plate & LeftField 3 balance plates

- LeftField Dovetail Plate -
The Left Field ARRI Dovetail Plate is a quick release cheese plate that is compatible with the Left Field 15mm LWS Baseplate and Sliding Top Plates. The LeftField ARRI Dovetail Plate is a multipurpose quick release plate featuring multiple 1/4", 3/8" & ARRI Accessory Mounts.

The low profile plate is based on the ARRI standard dovetail and acts as a quick release plate for a camera setup using the LeftField 15mm LWS Baseplate making the transition going from tripod to handheld much quicker.

When used with the LeftField Sliding Top Plates, the Dovetail plate provides a mounting surface for other accessories like the carrying handle and Titan Arm quick release brackets.

Two removable safety screws prevent the plate from sliding out of the receiving accessory. These two screws can also be mounted on the right side of the plate to fix the dovetail plate into position.

The LeftField ARRI Dovetail Plate can also snap in and out by releasing the Dovetail clamp further. This is especially handy if you have other accessories mounted onto your camera setup which can obstruct the camera package from sliding on and off the plate.

Features
• Versatile quick release plate for camera or top mounted accessories
• Ability for fine adjustment of counter balance
• Multiple 1/4", 3/8" & ARRI Accessory Mounts
• Removable safety screws to prevent sliding out
• Option to place the Dovetail Plate into fixed position with safety screws

- DJI RS 4 & RS 3 Dovetail for Canon C70 -
Mount your Canon C70 onto the DJI RS 4 & RS 3 Dovetail for faster transitions between gimbal, handheld & tripod setups. The dovetail is designed to be paired with LeftField 15mm LWS Baseplates using the DJI RS 4 Riser for Canon C70.

This DJI RS 4 & RS 3 Dovetail is designed for the Canon C70 & DJI gimbals. It lets you seamlessly move from the LeftField baseplate to a handheld gimbal, without having to swap out dovetails or remove any accessories. Specifically made for the DJI RS 4 & RS 3, it has a 4mm offset to provide clearance for the handgrip and the gimbal arm. The extended 129mm (5") long plate and lightweight design also assists with balancing.

Easily balance your Canon C70 on DJI gimbals
The dovetail connects to the camera using a 3/8" & 1/4" screw, with an additional locating pin. This prevents the camera from twisting on the plate. Rubber pads on the top of the dovetail also add extra grip. Our engineering team have machined out any excess weight, resulting in an extremely lightweight dovetail at only 75g (2.6oz).

The dovetail uses the same DJI standard, complete with a racking gear. It works directly with the RS 4 Pro, RS 4, RS 3 Pro, RS 3 & earlier models without the need to change camera plates. The extra length provides ample room for balancing & adjustment.

Laser etched markers along the length of the dovetail let ACs mark down balanced positions on the gimbal. When paired with our LeftField DJI RS 2 & RS 3 quick release risers, the camera is set at the correct height for 15mm LWS support & accessories.

Support For Accessories
Lens adapters can be secured using the front channel and supplied screws. Depending on the camera height, not all lens feet will be compatible or require spacers.

The broad, flat surface of the universal dovetail ensures your camera remains stable, maximizing surface area to eliminate any flex. Rubber grips prevent twisting, even with smaller cameras. The camera remains low, creating a natural pivot point for smooth operation with the gimbal.

Compatibility
The DJI gimbal plates ship from the factory with washers of varying thicknesses. While these variations work fine with DJI's own plate, they may cause clearance issues with the Bright Tangerine DJI compatible plates. This is due to the low-profile design of the protruding support and anti-rotation features, which are crucial for securing the camera.

If you are finding that the bottom of the Bright Tangerine DJI plate is hitting the gray clamp lever and preventing fore and aft slide, you can swap the original washer out with the thinner one supplied in this kit. This will lower the gray lever sufficiently to clear the Bright Tangerine DJI plate. Please note, the use of the thinner washer in this kit will not impact the use of any other baseplates on the DJI camera plate.

Extra Care Comes Standard
Machined and hand-finished in our single factory in Church Crookham from high-grade materials. Hard anodized for extended durability.

Features
• Compatible with the Canon C70
• Slides onto LeftField 15mm LWS Baseplates with DJI RS 4 & 3 riser
• 144mm length provides ample fore/aft range with racking gear
• Wide anti-twist platform for extra stability with rubber pads for grip
• Support for lens adapters using 3/8" or 1/4" screw

- DJI RS 4 & RS 3 Riser for Canon C70 -
Set the Canon C70 to the correct height when using the Left Field 15mm LWS Baseplate with this riser attached, pairing with the DJI RS 4 & RS 3 dovetail for the Canon C70. The quick release allows for fast transitions between tripod, handheld & gimbal work without needing to change plates.

This Canon C70 DJI RS 4 & RS 3 Riser mounts to the LeftField 15mm LWS Baseplate, providing a quick release base for DJI RS dovetails. When paired with the DJI RS 4 & RS 3 Dovetail for the Canon C70, the camera will sit at the correct 15mm LWS standard height.

Compatibility
The riser is designed for the LeftField 15mm LWS Baseplate & DJI RS 4 & RS 3 Dovetail.

Safety Release
The riser has an integrated safety which prevents the dovetail from falling out accidentally. To release the dovetail, unlock the clamp and press the orange safety before sliding out the camera.
