What is the data transfer rate of the BG-FS5P60 60W 5-Port 1G Ethernet L2 PoE+ Unmanaged Switch?

The BG-FS5P60 switch supports a high data transfer rate of 10/100/1000Mbps, ensuring efficient and rapid data transfer across all connected devices.

What power sources are compatible with the BG-FS5P60 switch?

The switch is compatible with both 802.3af (15W PoE) and 802.3at (25W PoE+) power sources, providing flexibility in terms of power supply options.

Can the BG-FS5P60 switch mode be manually changed?

Yes, users can manually switch between Normal VLAN mode and Monitoring VLAN mode, tailoring the switch's functionality to their specific networking needs.

Is the BG-FS5P60 switch suitable for both home and office use?

Absolutely. Its compact and portable design makes the BG-FS5P60 switch an ideal fit for both home and office network environments.

Does the BG-FS5P60 switch offer a standard solution for network performance enhancement?

Yes, the BG-FS5P60 switch provides a simple, economical, and standard solution for enhancing network performance.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

BZB GEAR BG-FS5P60 Specifications

  • Material

    Metal

  • Ports

    5x 10/100/1000BASE-T RJ45

  • MAC Address

    2K

  • Switching Capacity

    10 Gbps

  • Jumbo Frame

    9000

  • Forwarding Rate

    7.44 Mpps

  • Transfer Method

    Store-and-Forward

  • Packet Buffer

    0.19MB

  • Standards and Protocols

    IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az

  • Power Supply

    DC 51V, 1.25A (External Power Supply)

  • Max. Power Budget

    60W

  • PoE Standard

    IEEE 802.3af/at

  • Max. Power Consumption

    PoE on 66.1W (220V, 50Hz)

  • Mounting Methods

    Desktop or Wall-mount

  • Operating Temperature

    32 Degree F to 104 Degree F (0 Degree C to 40 Degree C)

  • Storage Temperature

    -40 Degree F to 158 Degree F (-40 Degree C to 70 Degree C)

  • Dimensions (H x W x D)

    1.10 x 6.38 x 4.02" (28 x 162 x 102mm)

About BZB GEAR BG-FS5P60

Under the umbrella of reliable and high-performance networking solutions, the BG-FS5P60 60W 5-Port 1G Ethernet L2 PoE+ Unmanaged Switch stands out as a superior choice for both home and office environments. This user-friendly switch seamlessly integrates 1000Mbps Gigabit Ethernet and 10/100Mbps Ethernet network capabilities, ensuring efficient and rapid data transfer across all connected devices.

Boasting four Power Sourcing Equipment (PSE) ports, this durable switch is capable of delivering power to devices compliant with IEEE802.3af/at standards. This flexibility in power supply options makes it an adaptable solution for various network-enabled devices, including computers and printers.

In addition to its robust performance, the BG-FS5P60 switch offers the convenience of manual mode switching. Users can effortlessly toggle between Normal VLAN mode and Monitoring VLAN mode, tailoring the switch's functionality to their specific networking needs.

Designed with a high level of integration, this switch is not only efficient but also exquisitely crafted. Its compact and portable design makes it an ideal fit for small to medium-sized network environments, without compromising on performance or quality.

Whether you're looking to enhance the performance of a department, working group, or simply your home network, the BG-FS5P60 60W 5-Port 1G Ethernet L2 PoE+ Unmanaged Switch provides a simple, economical, and standard solution for high-performance networking.

BZB GEAR BG-FS5P60 Features

  • Plug and Play, No Configuration Needed
  • 5x 10/100/1000Mbps Auto-Negotiation RJ45 Ports
  • Fanless and Silent Operation
  • 4 PoE+ Ports with 60W Total Power Budget
  • Support Port Auto MDI/MDIX
  • Energy Efficient Design Compliant with IEEE 802.3az
  • Durable Metal Casing, Desktop or Wallmount Options

Warranty Information

This product has a limited warranty of 36 months.

Key Features

  • High-performance 5-Port 1G Ethernet L2 PoE+ Unmanaged Switch for efficient data transfer
  • Integrated 1000Mbps Gigabit Ethernet and 10/100Mbps Ethernet network capabilities
  • Four Power Sourcing Equipment (PSE) ports for powering IEEE802.3af/at compliant devices
  • Manual mode switching between Normal VLAN mode and Monitoring VLAN mode for tailored functionality
  • Compact, portable design ideal for home and office network environments
  • Economical and standard solution for enhancing network performance

What's in the box:

  • BZB GEAR BG-FS5P60 60W 5-Port 1G Ethernet L2 PoE+ Unmanaged Switch
  • BZB GEAR 3 Year Limited Warranty
