Mix It Up with an 11x2 Presentation Scaler Switcher | BZBGEAR BG-PSC11x2-HDBT
1 video
BZBGEAR BG-PSC11X2-HDBT 11x2 Presentation Scaler Switcher w/VGA/HDMI/YPbPr/CV
See all BZB GEAR items

BZB GEAR BG-PSC11X2-HDBT 11x2 Presentation Scaler Switcher with VGA/HDMI/YPbPr/CV/HDBaseT

SKU: BZPSC1X2HDBT
Be the first to review this item

This item is no longer available.

Recommended Alternatives

BZB GEAR BG-UM44-100M-KIT: Picture 1 regular
BZB GEAR BG-UM44-100M-KIT 4x4 4K HDMI/HDBaseT/Audio Matrix Switcher w/4x RX,328'
$6,999.00
BZB GEAR BG-UM88-100M-KIT: Picture 1 regular
BZB GEAR BG-UM88-100M-KIT 8x8 4K HDMI/HDBaseT/Audio Matrix Switcher w/8xReceiver
$12,999.00
BZB GEAR BG-4K-VP1616: Picture 1 regular
BZB GEAR BG-4K-VP1616 16x16 4K 60Hz HDMI Matrix Switcher & Video Wall Processor
$13,999.00$10,999.00
BZB GEAR BG-4K-VP1616PRO: Picture 1 regular
BZB GEAR BG-4K-VP1616PRO 16x16 4K HDMI/LAN Matrix Switcher/Video Wall Processor
$17,999.00$16,999.00
See More Recommendations
Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

BZB GEAR BG-PSC11X2-HDBT Specifications

  • Bandwidth

    10.2Gbps

  • Video Input Connectors

    4x HDMI Type A, 4x VGA, 1x RJ45, 1xYPbPr, 1x AV

  • Video Output Connectors

    1x HDMI Type A, 1x RJ45

  • Audio Input Connectors

    11x 3.5mm stereo jack

  • Audio Output Connectors

    1x 3.5mm stereo jack,1x RCA (SPDIF)

  • RS-232 serial port

    1x DB 9 connector, 1x 3 phoenix terminal

  • TCP/IP

    1x RJ45

  • IR Input ports

    2x 3.5mm stereo jack

  • IR Output ports

    1x 3.5mm mono jack

  • Temperature

    Operating: 32 to 104 Degree F (0 to 40 Degree C)
    Storage: -4 to 140 Degree F (-20 to 60 Degree C)

  • Power Supply

    DC 12V/5A

  • Dimensions (W x H x D)

    17.2 x 8.8 x 1.7" (438 x 225 x 44mm) (without feet)

  • UPC Code

    850009357984

About BZB GEAR BG-PSC11X2-HDBT

The BG-PSC11X2-HDBT is an 11-Input multi-format Switcher with built-in video scaling, audio embedding/ de-embedding, EDID management and HDBaseT inputs & outputs. This switcher can utilize multiple sources through its array of A/V input options and is also able to transmit signals up to 4k@30Hz. Input formats include HDMI, VGA, Component, Composite, and HDBaseT.

Embed or Extract audio using multiple audio inputs and outputs. In addition, this unit includes an HDBaseT output capable of transmitting signals to a remote display location up to 100m (330 feet) away via Cat6 cable. The thoughtful addition of an integrated ethernet hub add to the flexibility of this device. With full control using the front-panel push buttons, IR remote control, RS-232, and IP control, it seamlessly integrates in nearly any scenario.

BZB GEAR BG-PSC11X2-HDBT Features

  • Switch & Scale 11-inputs to 2 HD/UHD displays
  • 4x HDMI, 4x VGA, 1x YPbPr, 1x Composite, 1xHDBaseT Inputs
  • 2 simultaneous outputs (1x HDMI, 1x HDBaseT), bypass and scaled formatted output selectable
  • Dual mode selectable (1x2 Splitter Mode and 5x1 &11x1 Dual Switcher Mode)
  • Scaling from 640x480 to 1920x1080 @ 60Hz
  • HDTV formats up to 4K @ 30Hz
  • HDBaseT POE Transmitter & Receiver supports distance up to 330ft /100m
  • HDCP 1.4 compliant
  • Audio embedder and audio extractor
  • OSD menu for volume control and resolution selection
  • Controllable via front panel, IR remote, TCP/IP or RS232
  • Front-panel LCD display for status feedback
  • Easy installation with rack-mounting ears

Join VIP PRO

Earn 2X Points + Exclusive Perks!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Switch & Scale 11-inputs to 2 HD/UHD displays
  • 4x HDMI, 4x VGA, 1x YPbPr, 1x Composite, 1xHDBaseT Inputs
  • 2 simultaneous outputs (1x HDMI, 1x HDBaseT), bypass and scaled formatted output selectable
  • Dual mode selectable (1x2 Splitter Mode and 5x1 &11x1 Dual Switcher Mode)
  • Scaling from 640x480 to 1920x1080 @ 60Hz
  • HDTV formats up to 4K @ 30Hz

What's in the box:

  • BG-PSC11X2-HDBT 11x2 Presentation Scaler Switcher with VGA/HDMI/YPbPr/CV/HDBaseT
  • 12V/5A Power Supply
  • Remote Control
  • 3x IR Emitter
  • 4x IR Receiver
  • Rack-Mounting Ears
  • BZBGEAR 2 Year Limited Warranty
