Canon DP-V3120 31.1" 17:9 4K HDR Reference Display, Without Power Cord

SKU: CA4274C006 MFR: 4274C006
Earn VIP Reward Points

Key Features

  • Experience superior clarity with this 31.1" Canon 4K HDR reference display.
  • Achieve accurate color grading with the DP-V3120's exceptional color accuracy.
  • Enjoy wide viewing angles on the production monitor, perfect for collaborative work.
  • Ensure reliable connectivity using the monitor's 12G/6G/3G/HD/SD-SDI inputs.
  • This HDR reference display offers a peak brightness of 2,000 cd/sq. m.
  • The Canon DP-V3120 production monitor supports VESA mounting for flexible setup.
See More Product Details
Special Order?Estimated to Ship: 09/11/2025
Free Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Q&A

Questions & Answers

Reviews about this item

Review Summary

Canon DP-V3120 Specifications

Panel
  • Panel Type

    IPS LCD panel

  • Screen Size

    31.1" (79.0cm)

  • Aspect Ratio

    17:9

  • Resolution

    4096 x 2160 (8.8 Megapixels)

  • Active Display Area

    Approx. 27.5 x 14.5" (698.0 x 368.1mm)

  • Pixel Pitch

    132 microm/193 ppi

Image Quality

Jump to...
  • Brightness

    Standard: 100 cd/sq. m
    Peak, full screen white: 2,000 cd/sq. m

  • Viewing Angle (Up, Down, Left, Right)

    89 Degree (contrast ratio 10:1 or higher)

  • Surface Treatment

    Anti-glare coating

Interface: Input

Jump to...
  • 12G/6G/3G/HD/SD- SDI

    4x (1 channel) BNC (75 Ohm) receptacle terminal

  • HDMI

    1x (1 channel) Type A terminal
    Copy protection: HDCP 2.2

Interface: Output

Jump to...
  • 12G/6G/3G/HD-SDI

    4x (1 pass-thru 1 channel)

  • Headphone

    1x Stereo mini-jack (supported impedance: 32-64 Ohm)

Interface: Control

Jump to...
  • USB

    1x USB A terminal
    niversal Serial Bus Specification Revision 2.0 compliant
    LS (Low Speed)/FS (Full Speed)/HS (High Speed) mode compatible
    Enhanced Host Controller Interface Specification for Universal Serial Bus Revision
    1.0 compliant

  • LAN

    1x RJ-45 terminal
    IEEE802.3 10BASE-TX compliant IEEE802.3u 100BASE-TX compliant

  • Remote

    1x RJ-45 terminal, GPI 8 pin

General

Jump to...
  • Backlight Type

    LED, Matrix Array

  • Power

    Rated voltage: 100 - 240 V AC
    Rated Frequency: 50/60 Hz

  • Power Consumption

    At maximum load (including change in brightness through aging): Approx. 510 W
    At factory shipment: Approx. 180 W

  • Environmental Conditions

    Operating:
    Temperature and humidity: 41-95 Degree F (5-35 Degree C) (20-85% RH no condensation)
    Recommended: 59-86 Degree F (15-30 Degree C) (20-80% RH no condensation)
    Pressure: 700-1060 hPa

    Storage/Transporting
    Temperature and humidity: -4-104 Degree F (-20-40 Degree C) (10-85% RH no condensation) 106-140 Degree F (41-60 Degree C) (10-30% RH no condensation)
    Pressure: 700-1060 hPa

  • Mounting Hole Pitch

    VESA standard 7.9 x 3.9" (200 x 100mm)

  • Dimensions (W x H x D)

    Including Handle: Approx. 29 x 19 x 13" (749 x 492 x 335mm)
    Display unit only, without protruding parts: Approx. 29 x 19 x 12" (749 x 470 x 295mm)

  • Weight

    Approx. 68 lbs (31kg)

  • UPC Code

    13803340624

About Canon DP-V3120

You can elevate your video editing and post-production work with the DP-V3120 31.1" 4K HDR Reference Display from Canon. This state-of-the-art, professional-grade display is designed to deliver high-quality, accurate, and consistent visuals across its 31-inch LCD panel.

The DP-V3120 boasts an impressive 4K resolution of 4096 x 2160 pixels, ensuring detailed and immersive viewing experiences. It surpasses Dolby Vision requirements, making it a reliable choice for HDR production. The display's advanced technology ensures minimal color shifting and edge-to-edge consistency, providing you with true-to-life visuals and superb image quality.

This innovative display is designed for quiet operation, thanks to its aluminum frame and fan system. This ensures minimal distractions, allowing you to focus entirely on your work. The DP-V3120 is also compatible with the Cinema EOS System and can efficiently operate with compatible cameras.

The DP-V3120 is the first in its class to deliver a 10-bit color, peak 2,000-nit edge-to-edge brightness, and 0.0001-nit full-screen black level. This results in an ultra-low black level and an impressive 2,000,000:1 contrast ratio.

This advanced display supports HD, 4K, and 8K workflows through its 12G-SDI interface, which includes four inputs and four pass-through outputs. Each 12G terminal supports signals up to 4K 60P, and all terminals can be combined to accept signals up to 8K 60P*.

The DP-V3120 Reference Display also supports the next-generation plug-and-play ACES standard (ACES2065-1) from the Academy of Motion Picture Arts and Sciences (AMPAS). This ensures that you're working with the latest industry standards.

Canon's 4K reference monitor offers a complete viewing angle of 89 degrees and minimizes color, brightness, and contrast variations with an IPS panel, anti-glare coating, and filtering layers. The DP-V3120 can display up to four input signals side-by-side for multi-view monitoring, making it ideal for settings checks from multiple cameras, different LUTs, and SDR vs. HDR comparisons.

The DP-V3120 is equipped with Canon's HDR Toolkit, providing support for HDR-compatible tools like a waveform monitor, vectorscope, histogram, false-color, frame luminance monitor, pixel value checker, out of gamut display, over-range detection, and side-by-side display.

Optimized for the Cinema EOS System, the DP-V3120 supports Cinema RAW and Canon Log formats. It allows creators to check focus, angle-of-view, and other attributes with a display connection. Metadata is conveniently placed next to the image for easy reference on set or in post-production.

The DP-V3120 4K Reference Display is a testament to Canon's commitment to providing imaging professionals with high-quality, reliable, and innovative solutions for HDR production.

Canon DP-V3120 Features

  • 31" 4K HDR Reference Display
  • 2,000-nit HDR Peak Edge-to-edge Luminance, 0.001-nit Full-screen Black Level (2,000,000:1 Contrast Ratio)
  • Exceeds the requirements for Dolby Vision Certified facilities
  • Quiet Operation
  • 12G-SDI with support for HD/4K/8K Workflows
  • Award-winning HDR Toolkit
  • ACES Support
  • 89 Degree Wide Viewing Angle
  • Dual Screen and Quad View
  • Remote Control by Wi-Fi/LAN Connection
  • Optimized for use with Cinema EOS System
  • Support for third party camera systems
  • ACES 1.0.1 Support

Warranty Information

This product has a limited warranty of 12 months.

Key Features

  • Experience superior clarity with this 31.1" Canon 4K HDR reference display.
  • Achieve accurate color grading with the DP-V3120's exceptional color accuracy.
  • Enjoy wide viewing angles on the production monitor, perfect for collaborative work.
  • Ensure reliable connectivity using the monitor's 12G/6G/3G/HD/SD-SDI inputs.
  • This HDR reference display offers a peak brightness of 2,000 cd/sq. m.
  • The Canon DP-V3120 production monitor supports VESA mounting for flexible setup.

What's in the box:

  • Canon DP-V3120 31.1" 17:9 4K HDR Reference Display
  • (Power Cord Not Included)
  • Canon 1 Year Limited Warranty
