Canon CR-X300 21.1MP 4K UltraHD Outdoor 20x PTZ Camera, Titanium White

SKU: CACRX300W MFR: 5638C001
Earn VIP Reward Points

Key Features

  • Capture stunning 4K Ultra HD video with the Canon PTZ camera's exceptional image quality.
  • Achieve incredible zoom with the 20x optical zoom, perfect for detailed close-ups in any broadcast.
  • Enjoy seamless connectivity with LAN, Serial, 6G-SDI, and HDMI for versatile video workflows.
  • Weatherproof IP65 rating ensures the Canon PTZ camera is durable and reliable outdoors.
  • Control remotely via hardware (RC-IP100) or software for easy PTZ camera adjustments.
  • Benefit from smooth pan and tilt operations, ideal for live events and studio recordings.
See More Product Details
Temporarily On Backorder?Expected Availability: 09/2025Request assistance or get notified
Free Shipping

See Options

Qty
1

Protect your gear with Adorama Protect.* Learn more

2 Year

$229.99

3 Year

$274.99

4 Year

$369.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Learn
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Canon CR-X300 Specifications

Camera
  • Color

    Titanium White

  • Image Sensor

    Type 1/2.3 (1/2.3 in.) single-plate CMOS Sensor
    Total Pixels: approx. 21.14 Megapixels
    Effective Pixels: approx. 8.29 Megapixels (3840 x 2160)

  • Lens

    f=3.67 - 73.4 mm, F/1.8 - 2.8, 20x optical zoom 35mm equivalent focal length:
    [4K UHD] approx. 29.3 (W) - 601 mm (T)
    [Full HD] approx. 30.5 (W) - 627 mm (T)
    8-bladed circular aperture
    12 elements in 10 groups (including 2 aspheric elements)

  • Zoom

    Optical: 20x
    Digital: 20x

  • Minimum Focusing Distance

    1 cm (0.39 in.) at maximum wide angle, 60 cm (2.0 ft.) throughout the zoom range (from the front window)

  • Angle of View

    [4K UHD]
    Horizontal: 65.6 Degree (W) - 3.6 Degree (T)
    Vertical: 39.8 Degree (W) - 2.0 Degree (T)

    [Full HD]
    Horizontal: 63.5 Degree (W) - 3.4 Degree (T)
    Vertical: 38.4 Degree (W) - 1.9 Degree (T)

  • Shutter Speed

    1/6 - 1/2000 sec. (specific values depend on the frame frequency)

  • Focus

    Focus mode: Manual, Continuous AF, Face Detection AF, Tracking AF type: Hybrid AF, Contrast AF

  • Shooting Mode

    Shooting Mode

  • Scene Mode

    Portrait, Sports, Low light, Spotlight

  • Gamma

    Normal1, Normal3

  • Color Space

    Auto, Manual 1/3 - 1/1000 sec.

  • Color Matrix

    BT.709, BT.2020

  • ND Filter

    ND filter: 1/8 at maximum
    Enhanced ND filter: 1/32

  • IR Mode

    Electrically switchable

  • Image Stabilizer

    Optical-shift (Standard IS, Powered IS)

  • White Balance

    AUTO (AWB), Set A, Set B, preset settings (daylight: approx. 5600 K, tungsten lamp: approx. 3200 K), color temperature setting (2000 K - 15000 K), Manual

  • Gain

    0.0 dB - 36.0 dB

  • Min. Subject Illumination

    Approx. 3.0 lux (shutter speed 1/60 sec., frame frequency 59.94 Hz (P (Program AE) shooting mode), auto slow shutter Off)

  • Video Flip

    Supports upright/ceiling installation, flip function (Auto Flip enabled/disabled)

  • Built-in Microphone

    Equipped
    Waterproof Microphone

Video Output Signal

Jump to...
  • SDI

    3840 x 2160: 29.97P, 25.00P, 23.98P (4:2:2 10 bit)
    1920 x 1080: 59.94P/59.94i, 50.00P/50.00i/25.00P, 29.97P/23.98P (4:2:2 10 bit)
    1280 x 720: 59.94P, 50.00P (4:2:2 10 bit)
    Same video format required for SDI and HDMI (cannot select different formats for SDI and HDMI)
    When 3840 x 2160 is selected for SDI, video will not be outputted to HDMI.

  • HDMI

    3840 x 2160: 29.97P, 25.00P, 23.98P (4:2:2 10 bit)
    1920 x 1080: 59.94P/59.94i, 50.00P/50.00i/25.00P, 29.97P/23.98P (4:2:2 10 bit)
    1280 x 720: 59.94P, 50.00P (4:2:2 10 bit)
    Same video format required for SDI and HDMI (cannot select different formats for SDI and HDMI)
    When 3840 x 2160 is selected for HDMI, video will not be outputted to SDI.

  • IP

    [Frame Frequency 59.94 Hz]
    1920 x 1080: 59.94 fps, 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
    1280 x 720: 59.94 fps, 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
    640 x 360: 59.94 fps, 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)

    [Frame frequency 29.97 Hz]
    3840 x 2160: 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
    1920 x 1080: 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)

  • IP (Contd.)

    1280 x 720: 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
    640 x 360: 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)

    [Frame frequency 50.00 Hz]
    1920 x 1080: 50.00 fps, 25.00 fps, 12.50 fps, 5.00 fps (4:2:0 8 bit)
    1280 x 720: 50.00 fps, 25.00 fps, 12.50 fps, 5.00 fps (4:2:0 8 bit)
    640 x 360: 50.00 fps, 25.00 fps, 12.50 fps, 5.00 fps (4:2:0 8 bit)

  • IP (Contd..)

    [Frame frequency 25.00 Hz]
    3840 x 2160: 25.00 fps, 12.50 fps, 5.00 fps (4:2:0 8 bit)
    1920 x 1080: 25.00 fps, 12.50 fps, 5.00 fps (4:2:0 8 bit)
    1280 x 720: 25.00 fps, 12.50 fps, 5.00 fps (4:2:0 8 bit)
    640 x 360: 25.00 fps, 12.50 fps, 5.00 fps (4:2:0 8 bit)

    [Frame frequency 23.98 Hz]
    3840 x 2160: 23.98 fps, 11.99 fps, 5.99 fps (4:2:0 8 bit)
    1920 x 1080: 23.98 fps, 11.99 fps, 5.99 fps (4:2:0 8 bit)

  • IP (Contd...)

    1280 x 720: 23.98 fps, 11.99 fps, 5.99 fps (4:2:0 8 bit)
    640 x 360: 23.98 fps, 11.99 fps, 5.99 fps (4:2:0 8 bit)
    JPEG has one pattern fixed depending on the frame frequency

    Resolution: 1280 x 720
    When frame frequency is 59.94/29.97 Hz: 14.99 fps,
    When frame frequency is 50.00/25.00 Hz: 12.50 fps,
    When frame frequency is 23.98 Hz: 11.99 fps

Protocols

Jump to...
  • Preset

    Number of presets: Max. 100 (including home position)

Interface

Jump to...
  • Communication Control

    LAN, Serial

  • Network

    LAN x 1, RJ45, 1000Base-T

  • 6G-SDI

    BNC jack (output only) x 1, 0.8 Vp-p/75 Ohm, unbalanced SMPTE 2081, 424, 425, ST 299-2 compliant Embedded audio, Time code (VITC/LTC)

  • GEN-LOCK

    BNC jack x 1, 1.0 Vp-p/75 Ohm, input only

  • HDMI

    HDMI Connector x 1, output only

  • RS-422

    RJ45 Connector x 1

  • External Device I/O Terminal

    AUX connector x 1

Pan/Tilt

Jump to...
  • Operation Range

    Pan Operation Range: Horizontal +/-180 Degree
    Tilt operation range: Vertical -40 Degree - +215 Degree

  • Operation Speed

    0.3 Degree - 60 Degree /sec.

  • Position Accuracy

    within +/-10'

  • Noise

    NC45 or lower (when operating at 60 Degree /sec.)

  • Wiper

    Equipped

Operating Environment

Jump to...
  • Temperature

    -15 Degree C - +40 Degree C (+5 Degree F - +104 Degree F)

  • Humidity Resistance

    Humidity 90% or Less (without Condensation)
    (Startup Temperature -10 Degree C - +40 Degree C (+14 Degree F - +104 Degree F)

  • Survival Wind Speed

    Normal Operation: 15 m/sec.
    Operation Possible: 30 m/sec.
    Non Destruction: 60 m/sec.

  • Installation Method

    Supports Upright / Ceiling Installation

  • Power Supply

    PoE: PoE++ power supply via LAN connector (IEEE802.3bt compliant)
    PoE and PoE+ cannot be used
    External Power Source: 12 V DC (Use the included power cable with DC plug)

  • Power Consumption

    PoE++ Input: Approx. 39.8 W max. (body only)
    DC Input: Approx. 37.7 W* max. (body only)
    * Class 5 (40.0 W required) for power supply devices

  • Dust-resistant/Waterproof

    IP65

  • Paint

    Painted for outdoor-use

  • Supported Controllers

    Hardware: RC-IP100
    Software: Remote Camera Control Application

  • Dimensions (W x H x D)

    Approx. 8.54 x 12.24 x 8.54 in. (217 x 311 x 217 mm) (excluding protrusions and connector cover)

  • Weight

    Approx. 15.5 lbs (7kg)

  • UPC Code

    013803347845

Related Articles & Videos

PTZ Cameras: Everything You Need to Know

PTZ Cameras: Everything You Need to Know

PTZ (or pan, tilt, zoom) cameras offer a wealth of benefits and can be remotely controlled by camera operators or automated software.
Read more

About Canon CR-X300

Just unveiled, the CR-X300 21.1MP 4K UltraHD Outdoor 20x PTZ Camera in Titanium White is a state-of-the-art imaging device, designed to deliver exceptional video quality in a variety of settings. This PTZ camera is equipped with a 1/2.3-inch 4K UHD CMOS imaging sensor and a 20x optical zoom lens, complemented by a 20x digital zoom, all powered by Canon's cutting-edge autofocus technology.

The CR-X300 is fully controllable via IP or serial connection, supporting multiple protocols for maximum flexibility. Its robust aluminum die-cast body houses an IP65-rated protection against dust and water, making it a perfect choice for both indoor and outdoor installations. Despite its robustness, the camera remains lightweight and portable, ensuring easy transportation and installation in any location.

With its advanced 4K UHD CMOS Image Sensor, the CR-X300 captures stunningly sharp and detailed high-definition video, boasting an impressive 8.29 effective megapixel resolution. The sensor's high sensitivity ensures vivid, accurate video through an excellent signal-to-noise ratio.

The camera's DIGIC DV 6 Image Processor enhances picture quality for both 4K UHD video and Full HD, while its Hybrid AF system combines high-precision contrast AF technology and high-speed phase-difference AF technology for faster and more reliable autofocus. The CR-X300 also features Face Detection and Tracking functions, automatically adjusting focus when a human is detected within the frame.

The CR-X300's Scene Modes offer four preset shooting modes suitable for different applications, including Portrait, Sports, Low Light, and Spotlight modes. Its Infrared Mode enables video capture in conditions with little to no ambient light, while its genuine Canon 20x 4K Optical Zoom Lens provides a highly versatile zoom range.

The CR-X300 also offers Image Stabilization Options with two types of IS Modes, internal optical ND filtration, and a 3-axis Simultaneous PTZ Movement for smooth, fast, and highly precise movement. Its various interfaces, including 6G-SDI and HDMI Outputs, PoE++ Single Cable Solution, LAN and Serial Control, and IP Multi-Stream Support, make it easy to integrate into professional video environments.

The CR-X300 supports multiple protocols for video, audio, and control, including RTMP Streaming Protocol, NDI|HX Live Video Production Support Protocol, Standard (VISCA) Protocol, and the all-new Canon XC protocol. This makes the CR-X300 a versatile and powerful tool for video production, broadcasting, live events, sports arenas, outdoor venues, and more.

Canon CR-X300 Features

  • Pioneering autofocus technology: Canon's superior autofocus system ensures crisp images every time
  • 4K UHD CMOS Sensor: Captures incredibly sharp 3840 x 2160 pixels, giving vivid and accurate video
  • DIGIC DV 6 Image Processor: Enhances both 4K UHD and Full HD videos, backed by Over-Sampled HD Processing
  • 6G-SDI & HDMI Outputs: Provides uncompressed 4K and Full HD signals, ideal for broadcasting applications
  • Hybrid AF System: Combines contrast and phase-difference autofocus technologies for faster and more reliable focusing. Also supports Face Detection and Tracking
  • Genuine Canon 4K UHD Lens: 20x optical zoom covers a range equivalent to 29.3 - 601mm in 35mm terms
  • 3-axis PTZ Movement: Ensures smooth, precise movements with a low noise rating for indoor environments
  • IP System with Multi-Stream Support: Distributes high-res videos and supports three simultaneous video streams
  • IR Mode: Enables video capture in low to no ambient light conditions
  • Robust Build: IP65 rated aluminum die-cast body protects against dust and water
  • PoE++ Integration: Single cable solution for faster and more cost-effective installations
  • Diverse Control Options: Operable via serial-based or IP-based controllers, whether hardware or software
  • Support for NDI|HX & RTMP Streaming Protocols: Facilitates easy live streaming and seamless integration into existing video production environments
  • Compatibility with Standard (VISCA) and Canon XC Protocols: Offers remote control options suitable for diverse production and broadcasting needs

Warranty Information

This product has a limited warranty of 36 months.

Product Documents

User Manual

Key Features

  • Capture stunning 4K Ultra HD video with the Canon PTZ camera's exceptional image quality.
  • Achieve incredible zoom with the 20x optical zoom, perfect for detailed close-ups in any broadcast.
  • Enjoy seamless connectivity with LAN, Serial, 6G-SDI, and HDMI for versatile video workflows.
  • Weatherproof IP65 rating ensures the Canon PTZ camera is durable and reliable outdoors.
  • Control remotely via hardware (RC-IP100) or software for easy PTZ camera adjustments.
  • Benefit from smooth pan and tilt operations, ideal for live events and studio recordings.

What's in the box:

  • Canon CR-X300 21.1MP 4K Ultra HD Outdoor 20x PTZ Camera
  • Power Cable
  • Connector Cover
  • EAC Leaflet
  • Manual
  • Canon 3 Year Limited Warranty
