Canare 110 Ohm DA202 AES/EBU Digital Audio Cable, 200m (656')

SKU: CADA202200M MFR: DA202 200M
Earn VIP Reward Points

Key Features

  • Experience pristine digital audio with this 200m Canare AES/EBU cable, ensuring top signal quality.
  • Get superior noise reduction with >95% braid shield coverage in this professional audio cable.
  • This 25 AWG Canare cable offers a 110 Ohm impedance, perfect for balanced digital audio signals.
  • Enjoy reliable performance with a durable PVC jacket, protecting your audio cable investment.
  • Customize your studio setup; cut this bulk audio cable to the exact length you need for any job.
  • Achieve optimal sound; recommended AES/EBU length up to 590', delivering clear audio fidelity.
See More Product Details
Special Order?Estimated to Ship: 08/17/2025
Free Shipping

See Options

1

Protect your gear with Adorama Protect.* Learn more

1 Year

$39.99

2 Year

$69.99

3 Year

$79.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Canare 110 Ohm DA202 AES/EBU Digital Audio Cable, 200m (656') Specifications

  • Outer Diameter

    0.197" (5 mm) (nominal)

  • Thickness

    PVC Jacket: 0.03" (0.8 mm) (nominal)
    Insulation: (16.9 mm) IPE

  • Number of Conductors

    2 (orange and white)

  • Conductor

    AWG (AC): 25 (7/7.09 quantity/mm)
    Cross Sectional Area: 0.18 mm square

  • Pitch Twist Quad

    1.26" (32 mm)

  • Shield Coverage

    >95% braid

  • Dielectric Strength

    500 VAC/min

  • Insulation Resistance

    >= 1,000 MOhm/3 Mft

  • Electrical

    Conductor D.C.R.: <32.3 Ohm/1,000' (<10.6 Ohm/100 m)
    Shield D.C.R.: <6.8 Ohm/1000' (<2.2 ohm/100m)>
    Nominal Capacitance: 45pF/m
    Nominal Impedance: 110 Ohm
    Nominal Attenuation at 3 MHz: 5 dB/100 m

  • Length

    656.17' (200 m)
    Maximum recommended AES / EBU Length: 590' (180 m)

About Canare 110 Ohm DA202 AES/EBU Digital Audio Cable, 200m (656')

How the Canare DA202 AES/EBU Digital Audio Cable revolutionizes your audio experience is truly remarkable. This 200m (656') long, high-quality digital audio cable is a compact version of the renowned DA206 model, designed to seamlessly transmit digital audio signals between your audio devices such as mixers and digital audio workstations.

Constructed with durable 25 AWG conductors, this robust cable is compatible with common IDC punch down blocks and 110 ohm type Patchbays, making it a versatile addition to your audio setup. The Canare DA202 cable is not only reliable but also flexible, allowing for easy installation and maneuverability.

One of the standout features of this cable is its superior shielding. This strong, shielded cable is specifically designed to reduce electromagnetic interference (EMI) and radio frequency interference (RFI). This ensures a clear, stable signal transmission, enhancing the overall sound quality of your audio equipment.

Additionally, the Canare DA202 AES/EBU Digital Audio Cable comes with an integral drain wire, simplifying the ground wiring process. This feature further enhances its reliability, making it a preferred choice for professionals seeking a dependable digital audio transmission solution.

In summary, the Canare DA202 AES/EBU Digital Audio Cable is a durable, high-quality, and reliable choice for your digital audio needs, offering superior signal transmission and easy installation.

Canare 110 Ohm DA202 AES/EBU Digital Audio Cable, 200m (656') Features

  • AES/EBU Digital Audio
  • Audio Rack Wiring
  • Post Productions
  • Twisted Pairs with Braid Shield
  • Special PE Filter Rods maintain constant 110 ohm impedance
  • Nominal Attenuation @ 3MHz : 50 dB/100m

Warranty Information

This product has a limited warranty of 12 months.

Key Features

  • Experience pristine digital audio with this 200m Canare AES/EBU cable, ensuring top signal quality.
  • Get superior noise reduction with >95% braid shield coverage in this professional audio cable.
  • This 25 AWG Canare cable offers a 110 Ohm impedance, perfect for balanced digital audio signals.
  • Enjoy reliable performance with a durable PVC jacket, protecting your audio cable investment.
  • Customize your studio setup; cut this bulk audio cable to the exact length you need for any job.
  • Achieve optimal sound; recommended AES/EBU length up to 590', delivering clear audio fidelity.
