Canare 110 Ohm AES/EBU Digital Audio Cable, 100m (328.08')
See all Canare items

Canare 110 Ohm AES/EBU Digital Audio Cable, 100m (328.08')

SKU: CADA202AT1M
Be the first to review this item

This item is no longer available.

Recommended Alternatives

Canare : Picture 1 regular
Canare 4 Conductor 14 AWG Speaker Cable, 100m
$470.80
Canare : Picture 1 regular
Canare 4 Conductor 13 AWG Speaker Cable, 100m
$420.20
Canare : Picture 1 regular
Canare 4 Conductor 20 AWG Speaker Cable, 200m
$278.30
Canare : Picture 1 regular
Canare 4 Conductor 16 AWG Speaker Cable, 100m
$247.50
See More Recommendations
Overview
Compare
Specs
Protection

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Canare 110 Ohm AES/EBU Digital Audio Cable, 100m (328.08') Specifications

  • Outer Diameter

    0.16" (4 mm) (nominal)

  • Thickness

    PVC Jacket: 0.01" (0.3 mm) (nominal)
    Insulation: 0.82" (20.9 mm) (IPE)

  • Conductor

    AWG (AC): 25 (7/7.09 quantity/mm)
    Cross Sectional Area: 0.18 mm square

  • Pitch of Quad

    1.5" (38 mm)

  • Shield Coverage

    100% aluminum foil

  • Dielectric Strength

    500 VAC/min

  • Insulation Resistance

    >= 1,000 MOhm/3 Mft

  • Brittle Point

    -56 Degree F (-49 Degree C)

  • Length

    328.08' (100 m)

  • Electrical

    Conductor D.C.R: < 32.3 Ohm/1,000' (<10.6 Ohm/100 m)

  • Nominal Capacitance

    45 pF/m

  • Nominal Impedance

    110 Ohm

  • Nominal Attenuation at 3 MHz

    6.7 dB/100 m

About Canare 110 Ohm AES/EBU Digital Audio Cable, 100m (328.08')

Good choice for short cable runs. 25 AWG conductors suitable for all Rack Wiring applications, especially IDC Punch Down Block Digital Audio "110 ohm Type" Patchbays. Foil Shield with Drain Wire allows easy strip, prep and ground wire termination. Maximum recommended AES/EBU Length: 426ft (130meters). Jacket color: BLUE.

Canare 110 Ohm AES/EBU Digital Audio Cable, 100m (328.08') Features

  • AES/EBU Digital Audio
  • Audio Rack Wiring
  • Post Productions
  • Twisted Pairs with Foil Shield
  • Special PE Filter Rods maintain constant 110 ohm impedance
