Canare L-3CFB 100m 75Ohms Digital Video Coaxial Cable, Yellow
See all Canare items

Canare L-3CFB 100m 75Ohms Digital Video Coaxial Cable, Yellow

SKU: CAL3CFB100MY MFR: L-3CFB 100METERY
Be the first to review this itemAsk a Question
$84.92
Earn VIP Reward Points

Key Features

  • Experience superior signal quality with this 100m Canare coaxial cable, perfect for video applications.
  • Ensure reliable data transmission with our 75Ohms digital video coaxial cable, minimizing signal loss.
  • This yellow Canare L-3CFB coaxial cable offers exceptional durability for long-lasting performance.
  • Achieve optimal shielding against interference with this high-coverage braided coaxial cable.
  • Enjoy versatile connectivity with this unterminated coaxial cable, customize to fit your needs.
  • Get the best value with this Canare coaxial cable, balancing price and high-quality performance.
See More Product Details
Special Order?Estimated to Ship: 10/19/2025
Calculate Shipping

See Options

1
Add to ListGet Sale Alert

Add Adorama Protect:

Available to U.S. customers only.
1-Year Adorama Protect$6.99
2-Year Adorama Protect$13.99
3-Year Adorama Protect$20.99

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What makes the Canare L-3CFB 100m 75Ohms Digital Video Coaxial Cable suitable for professional use?

This high-performance cable is 100% sweep tested, ensuring optimal performance and minimal loss. It is designed to meet the rigorous demands of today's digital video and HDTV standards, making it ideal for professional use.

Why is the Canare L-3CFB 100m 75Ohms Digital Video Coaxial Cable yellow?

The vibrant yellow color of the cable is not just for aesthetics. It is designed to be UV-resistant, making it suitable for outdoor use. The color also aids in easy identification of the cable.

What does 'bulk unterminated' mean and how does it benefit the user?

A 'bulk unterminated' cable is one that is not pre-terminated with connectors. This allows the user to easily terminate the cable to fit the specific needs of their system, offering greater flexibility and customization options compared to pre-terminated cables.

What type of signals can the Canare L-3CFB 100m 75Ohms Digital Video Coaxial Cable transmit?

The Canare L-3CFB 100m 75Ohms Digital Video Coaxial Cable is designed for the transmission of both video and audio signals over long distances.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Browse our FAQ

See Terms & Conditions

Canare L-3CFB 100m 75Ohms Digital Video Coaxial Cable, Yellow Specifications

  • Cable Length

    100m (328.08')

  • Nominal Outer Diameter

    5.5mm (0.22")

  • PVC Jacket Thickness

    0.9mm (0.04")

  • Brittle Point

    -22 deg. F (-30 deg. C)

  • Conductor Material AWG

    Bare Copper #22

  • Conductor Outer Diameter

    0.65mm (0.03")

  • Insulation Outer Diameter

    3.1mm (0.12")

  • Dielectric Insulation Type

    Foam PE

  • Shield Material Coverage

    AL Foil 100%
    TAC Braid >91%

  • Conductor D.C.R.

    <16.8Ohms / 1000' (<5.5Ohms / 100m)

  • Shield D.C.R

    <4.3Ohms / 1000' (<1.4Ohms / 100m)

  • Nominal Capacitance at 1 kHz

    17 pF/ft (55 pF/m)

  • Nominal Impedance

    75Ohms

  • Velocity of Propagation

    0.79

  • Serial Digital Transmission Lengths

    650' minimum, 830' maximum at 270 Mbps

  • Nominal Attenuation

    At 10MHz dB 1.0 (3.2)
    At 50MHz dB 2.5 (8.0)
    At 135MHz dB 3.7 (12.3)
    At 270MHz dB 5.2 (17.2)
    At 360MHz dB 6.1 (20.0)
    At 720MHz dB 8.9 (29.1)
    At 1GHz dB 10.6 (34.7)
    At 1.45GHz dB 13.0 (42.6)
    At 1.8GHz dB 14.7 (48.3)
    At 2GHz dB 15.6 (51.2)

  • Connectors

    BNC: BCP-B3F
    F: FP-C3F
    RCA: RCAP-C3F

  • Cable Stripper

    TS-100E
    TS-3C

  • Crimp Tool

    TC-1

  • Die Set

    TCD-35CA

  • Weight

    4kg (8.82 lbs)

About Canare L-3CFB 100m 75Ohms Digital Video Coaxial Cable, Yellow

Why settle for less when you can have the best The Canare L-3CFB 100m 75Ohms Digital Video Coaxial Cable, in a vibrant yellow, is a high-performance solution designed for the professional broadcaster. This durable and reliable cable is 100% sweep tested, ensuring optimal performance and minimal loss.

Crafted by Canare, a reputable brand renowned for its high-quality audio and video cables, this product stands out in the market. It's not just a cable, but a commitment to quality and reliability, designed to meet the rigorous demands of today's digital video and HDTV standards.

This high-quality coaxial cable is not just robust but also flexible, making it an ideal choice for those seeking customization. As a bulk unterminated cable, it can be easily terminated to fit the specific needs of your system, offering greater flexibility than pre-terminated cables.

Designed for outdoor use, its yellow color is more than just aesthetically pleasing. It's a symbol of its resistance to UV light and other environmental factors, ensuring longevity and consistent performance.

Whether you're transmitting video or audio signals over long distances, the Canare L-3CFB 100m 75Ohms Digital Video Coaxial Cable is the affordable, high-quality solution you've been searching for. Experience the difference of a cable designed with precision, flexibility, and durability in mind.

Canare L-3CFB 100m 75Ohms Digital Video Coaxial Cable, Yellow Features

  • HD-Serial Digital Video
  • Satellite Head Ends
  • HDTV Upgrades
  • Broadband Facilities
  • SMPTE 259M, 292M, 424M
  • Solid Copper Center Conductor
  • Foam PE Dielectric
  • Tinned Copper Braid + 100% Foil Shield
  • Dielectric strips away clean from Conductor
  • Precision Coax 100% Sweep Tested

Warranty Information

This product has a limited warranty of 12 months.
