Canare L-3CFB 300m 75Ohms Digital Video Coaxial Cable, White
See all Canare items

Canare L-3CFB 300m 75Ohms Digital Video Coaxial Cable, White

SKU: CAL3CFB300MW MFR: L-3CFB 300METERW
Be the first to review this itemAsk a Question
$252.90
OR
$43/mo suggested payments with 6‑month special financing. Learn how.
Earn VIP Reward Points

Key Features

  • Ensure optimal signal quality with this 300m Canare coaxial cable for video applications.
  • Experience reliable data transmission using our 75Ohms digital video coaxial cable.
  • Enjoy superior shielding performance, minimizing interference with this coaxial cable.
  • Built to last: Durable Canare L-3CFB coaxial cable designed for long-term use.
  • Perfect for professional video setups, delivering exceptional clarity and precision.
  • Bare Copper #22 conductor ensures excellent conductivity in this coaxial video cable.
See More Product Details
Special Order?Estimated to Ship: 09/08/2025
Free Shipping

See Options

1
Add to ListGet Sale Alert

Protect your gear with Adorama Protect.* Learn more

1 Year

$29.99

2 Year

$49.99

3 Year

$59.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

Canare L-3CFB 300m 75Ohms Digital Video Coaxial Cable, White Specifications

  • Cable Length

    300m (984.24')

  • Nominal Outer Diameter

    5.5mm (0.22")

  • PVC Jacket Thickness

    0.9mm (0.04")

  • Brittle Point

    -22 deg. F (-30 deg. C)

  • Conductor Material AWG

    Bare Copper #22

  • Conductor Outer Diameter

    0.65mm (0.03")

  • Insulation Outer Diameter

    3.1mm (0.12")

  • Dielectric Insulation Type

    Foam PE

  • Shield Material Coverage

    AL Foil 100%
    TAC Braid >91%

  • Conductor D.C.R.

    <16.8Ohms / 1000' (<5.5Ohms / 100m)

  • Shield D.C.R

    <4.3Ohms / 1000' (<1.4Ohms / 100m)

  • Nominal Capacitance at 1 kHz

    17 pF/ft (55 pF/m)

  • Nominal Impedance

    75Ohms

  • Velocity of Propagation

    0.79

  • Serial Digital Transmission Lengths

    650' minimum, 830' maximum at 270 Mbps

  • Nominal Attenuation

    At 10MHz dB 1.0 (3.2)
    At 50MHz dB 2.5 (8.0)
    At 135MHz dB 3.7 (12.3)
    At 270MHz dB 5.2 (17.2)
    At 360MHz dB 6.1 (20.0)
    At 720MHz dB 8.9 (29.1)
    At 1GHz dB 10.6 (34.7)
    At 1.45GHz dB 13.0 (42.6)
    At 1.8GHz dB 14.7 (48.3)
    At 2GHz dB 15.6 (51.2)

  • Connectors

    BNC: BCP-B3F
    F: FP-C3F
    RCA: RCAP-C3F

  • Cable Stripper

    TS-100E
    TS-3C

  • Crimp Tool

    TC-1

  • Die Set

    TCD-35CA

About Canare L-3CFB 300m 75Ohms Digital Video Coaxial Cable, White

Canare 75Ohms precision digital video cables, offers the professional Broadcaster a high performance, 100% Sweep Tested, low cost, low loss coax that meets the demands of today's facility migration trends toward Serial Digital Video and HDTV standards.

Canare L-3CFB 300m 75Ohms Digital Video Coaxial Cable, White Features

  • HD-Serial Digital Video
  • Satellite Head Ends
  • HDTV Upgrades
  • Broadband Facilities
  • SMPTE 259M, 292M, 424M
  • Solid Copper Center Conductor
  • Foam PE Dielectric
  • Tinned Copper Braid + 100% Foil Shield
  • Dielectric strips away clean from Conductor
  • Precision Coax 100% Sweep Tested

Warranty Information

This product has a limited warranty of 12 months.

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Ensure optimal signal quality with this 300m Canare coaxial cable for video applications.
  • Experience reliable data transmission using our 75Ohms digital video coaxial cable.
  • Enjoy superior shielding performance, minimizing interference with this coaxial cable.
  • Built to last: Durable Canare L-3CFB coaxial cable designed for long-term use.
  • Perfect for professional video setups, delivering exceptional clarity and precision.
  • Bare Copper #22 conductor ensures excellent conductivity in this coaxial video cable.

What's in the box:

  • Canare L-3CFB 300m 75Ohms Digital Video Coaxial Cable
  • Canare 1 Year Limited Warranty
