Canare L-4.5CHD 100m 75 Ohms Digital Video Super Low Loss Coaxial Cable, Green
See all Canare items

Canare L-4.5CHD 100m 75 Ohms Digital Video Super Low Loss Coaxial Cable, Green

SKU: CAL45CH100MG MFR: L-4.5CHD 100METERG
Be the first to review this itemAsk a Question
$159.68
Earn VIP Reward Points

Key Features

  • Experience superior signal quality with this 75 Ohms low loss coaxial cable.
  • This 100-meter digital video cable ensures reliable connections for your devices.
  • Enjoy optimal shielding with 91% coverage, reducing interference in your coax setup.
  • Built for durability, this Canare coaxial cable guarantees long-lasting performance.
  • Perfect for professional video applications, this cable delivers exceptional clarity.
  • Get the best value with our super low loss coaxial cable, priced for your project.
See More Product Details
Special Order?Estimated to Ship: 09/07/2025
Free Shipping

See Options

1
Add to ListGet Sale Alert

Protect your gear with Adorama Protect.* Learn more

1 Year

$15.99

2 Year

$23.99

3 Year

$35.99

Available to U.S. customers only.

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Browse our FAQ

See Terms & Conditions

Canare L-4.5CHD 100m 75 Ohms Digital Video Super Low Loss Coaxial Cable, Green Specifications

  • Cable Length

    100' (30.48m)

  • Nominal Outer Diameter

    0.28" (7.11mm)

  • Inner Conductor Component

    18 (AWG), 1/1.02A (Q'ty/mm)

  • Inner Conductor Outer Diameter

    0.04" (1.02mm)

  • Insulation Outer Diameter

    0.18" (4.57mm)

  • Outer Conductors Shield Coverage & Comp.

    0.14TA/6/24 (91% or more)

  • Inner Conductor Resistance

    14.48 (23.3) (Ohms/km)

  • Outer Conductor Resistance

    6.15 (9.9) (Ohms/km)

  • Static Capacity

    53 pF/m

  • Characteristic Impendence

    75 Ohms

  • Attenuation

    17.4 dB/100m (328ft) (750MHz)

  • Weight

    13.67 lbs (6.20kg)

About Canare L-4.5CHD 100m 75 Ohms Digital Video Super Low Loss Coaxial Cable, Green

Canare's variety of 75 ohm coaxial cables support full-range of video formats. Our cutting-edge Supper Low Loss Coax is ideal for 3G-SDI / HD-SDI distribution.

Canare L-4.5CHD 100m 75 Ohms Digital Video Super Low Loss Coaxial Cable, Green Features

  • HD-Serial Digital Video
  • Satellite Head Ends
  • HDTV Upgrades
  • Broadband Facilities
  • SMPTE 259M, 292M,424M
  • Best suited to 3G-SDI / HD-SDI transmission
  • Highly-foamed PE insulation allows further improvement in the attenuation characteristics
  • Multi-layer insulation in which to each layer is given a different foaming ratio is used to increase strength
  • Tinned copper braid with aluminum foil brings excellent shielding
  • Flame resistance UL 1666 Riser

Warranty Information

This product has a limited warranty of 12 months.

Join VIP PRO

2 Day Delivery on thousands of items!

Sell or Trade your Gear

Get started in 3 easy steps

Key Features

  • Experience superior signal quality with this 75 Ohms low loss coaxial cable.
  • This 100-meter digital video cable ensures reliable connections for your devices.
  • Enjoy optimal shielding with 91% coverage, reducing interference in your coax setup.
  • Built for durability, this Canare coaxial cable guarantees long-lasting performance.
  • Perfect for professional video applications, this cable delivers exceptional clarity.
  • Get the best value with our super low loss coaxial cable, priced for your project.

What's in the box:

  • Canare L-4.5CHD 100m 75 Ohms Digital Video Super Low Loss Coaxial Cable
  • Canare 1 Year Limited Warranty
