Crest Audio Pro 9200 Professional Stereo Power Amplifier, 6500W at 4Ohms Bridged Mono Power, 10Hz-100kHz Frequency Response, 15kOhms Impedance

SKU: CAPRO9200

This item is no longer available.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Shopper : Why Did You Choose This?Roderick Z : fits with existing system

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failures, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Failure Protection

Failure Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for international or U.S. territories purchases. Plans on open box items do not cover pre-existing damage.
Adorama Protect plans are available for ABS clients. If you have any questions or require assistanse, please call 800-223-2500

Crest Audio Pro 9200 Specifications

  • Power Rating

    Stereo Power:
    2 Ohms : 3,250 W
    4 Ohms : 2,200 W
    8 Ohms : 1,300 W

    Bridge Mono Power:
    4 Ohms : 6,500 W
    8 Ohms : 4,400 W

  • Gain

    Selectable between x40 (32 dB) and x20 (26 dB)

  • Input Sensitivity

    4 Ohms Rated output power: 40x: 2.35 V +/- 3%
    20x: 3.16 V +/- 3%

  • Input Impedance

    15 kOhms , balanced

  • Maximum RMS Voltage Swing

    75 V

  • Frequency Response

    10 Hz to 100 kHz, +0 dB, -3 dB at 1 W

  • Power Bandwidth

    10 Hz to 50 kHz, +0 dB, -2 dB at 4 Ohms rated power

  • Damping Factor

    >300:1 8 Ohms at 20 Hz to 1 kHz

  • Input CMRR

    > -85 dB at 1 kHz

  • Crosstalk

    > -70 dB at 1 kHz at 8 Ohms rated power

  • Hum and Noise

    >-113 dB, "A" weighted referenced to rated power at 8 Ohms

  • Input connectors

    Balanced female XLR

  • Output connectors

    Speakon connectors and five-way binding post

  • Controls

    Front Panel:
    twin recessed stepped attenuators
    circuit breaker/power switch

    Rear Panel:
    mode select, gain select

  • LED Indicators

    Signal presence, ACL (Active clip limiting), Active status, Temp

  • Cooling

    2 variable speed 80 mm DC fans, back to front

  • Construction

    Aluminum chassis

  • Power Supply

    Switched Mode

  • Power Requirements

    Current Draw 120 VAC at 1/8:
    3,350 W 27.9 A at 2 Ohms
    2,200 W 18.4 A at 4 Ohms

    Current Draw 120 VAC at 1/3:
    7,300 W 60.9 A at 2 Ohms
    5,000 W 41.7 A at 4 Ohms

  • Thermal Emissions

    At 1/3 power, 4 Ohms bridged BTU/hour: 13,308

  • Class

    H

  • Dimensions (H x W x L)

    3.5 x 19.0 x 12.25" (8.89 x 48.26 x 31.11cm), +Rear Support Ears: 1.5" (3.81 cm)

  • Weight

    24.0 lb (10.88 kg)

  • UPC Code

    875866003324

About Crest Audio Pro 9200

The Crest Audio Pro 9200 6500W Professional Stereo Power Amplifier designed to achieve unsurpassed sonic performance and long-term reliability under extreme stress in touring or fixed installation applications. Absolute sonic accuracy is the hallmark of every Crest amplifier. Bass is solid and defined to the limits of audibility with ample current reserves. Wide-bandwidth output devices ensure detailed, transparent high frequency response. And, thanks to Crest's exclusive IGM circuit, the Pro 200 Series will drive 2ohms loads safely without compromising performance. The ACL (Active Clip Limiting) prevents speaker damage by providing gentle gain reduction when the signal approaches the clipping threshold. IGM (Instantaneous Gain Modulation) monitors speaker loads to detect conditions that may overstress output devices.

This allows safe operation into nominal 2ohms speaker loads. AUTORAMP gradually increases gain to the attenuator level settings when the amplifier is turned on. This prevents abrupt turn-on level. Other protection features include short circuit, DC voltage, comprehensive thermal management and current in-rush turn-on/off; transient sub-sonic input.

Crest Audio Pro 9200 Features

  • Dramatically reduced net weight
  • Latest generation of high speed, wide-bandwidth output devices
  • Dual, variable speed fans
  • Balanced XLR inputs
  • Speakon and 5-way binding post speaker outputs
  • Mode selector switch for stereo, parallel and bridged- Mono operation
  • Input sensitivity selection
  • Recessed, stepped attenuators
  • Front panel circuit - breaker switch

Key Features

  • Dramatically reduced net weight
  • Dual, variable speed fans
  • Balanced XLR inputs
  • Speakon and 5-way binding post speaker outputs
  • Input sensitivity selection
  • Recessed, stepped attenuators

What's in the box:

  • Crest Audio Pro 9200 Professional Stereo Power Amplifier
  • Crest Audio 5 Year Warranty
