Canon REALiS WUX7500 Pro AV WUXGA LCoS Projector, 1920x1200, 7500-Lumen, No Lens, White

SKU: CAWUX7500WH MFR: 2499C002
Earn VIP Reward Points

Key Features

  • Experience vibrant visuals with this 7500-Lumen projector, perfect for large venues.
  • Enjoy crystal-clear images with WUXGA resolution, ideal for detailed presentations.
  • This Canon projector's LCoS technology delivers superior color accuracy every time.
  • Achieve seamless connectivity with HDMI, DisplayPort, and HDBaseT inputs on this projector.
  • With a long-lasting lamp life, this projector minimizes maintenance and maximizes use.
  • The REALiS projector offers versatile mounting options for easy setup in any environment.
See More Product Details
Special Order?Estimated to Ship: 08/12/2025
Free Shipping

See Options

Qty
1

Add a Canon Protection Plan:

Need help? Ask our experts.

Overview
Compare
Accessories
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

warranty-logo

Protect your product against accidents, breakage and more!

CarePAK PLUS provided through Canon offers protection from accidental damage such as drops, spills, power surges, and more including normal wear and tear, beyond the standard warranty period.

SELECT YOUR PROTECTION PLAN:

Canon REALiS WUX7500 Specifications

Projector

Projector

Jump to...
  • Imaging Device

    0.71", LCoS Panel x3

  • Native Aspect Ratio

    16:10

  • Native Resolution

    1920 x 1200 (WUXGA)

  • Brightness

    7500/5200/4500 Lumens

  • Uniformity

    90%

  • Contrast Ratio

    2000:1

  • Digital Keystone

    V:+/-20 deg. , H:+/-20 deg.

  • Image Size

    40 - 600"

Image Adjustments

Jump to...
  • Image Mode

    Standard / Presentation / Dynamic / Vivid Photo / Video / Cinema / Photo / sRGB / DICOM SIM / User (1-5)

  • Color Adjustment

    Color Level, Color Balance, Color Temperature, Gain (R,G,B), Offset (R,G,B)

  • Screen Color Correction

    Normal / Greenboard / Adjust (custom)

  • Mounting

    Ceiling, Table, Rear, Rear Ceiling, Rear Table

  • Adjustable Feet

    4x, Extension Length: 14.6 mm, Maximum angle of inclination: +/- 1.8 deg.

Image Signals

Jump to...
  • Scanning Frequency

    H: 15.625kHz - 75kHz, V: 24Hz - 60Hz

  • HDMI (Digital PC Input)

    WUXGA, UXGA, WSXGA+, SXGA+, WXGA+, FWXGA, WXGA, SXGA, XGA, SVGA, VGA

  • HDMI (Digital Video Input)

    1080p, 1080i, 720p, 576p

  • DVI-I (Digital PC Input)

    WUXGA, UXGA, WSXGA+, SXGA+, WXGA+, FWXGA, WXGA, SXGA, XGA, SVGA, VGA

  • DVI-I (Analog PC Input)

    WUXGA, UXGA, WSXGA+, SXGA+, WXGA+, FWXGA, WXGA, SXGA, XGA, SVGA, VGA

  • DisplayPort

    1080p, 1080i, 720p, 576p, 576i, 480p, 480i

  • Mini Dsub15 (Analog PC Input)

    WUXGA, UXGA, WSXGA+, SXGA+, WXGA+, FWXGA, WXGA, SXGA, XGA, SVGA, VGA

  • Mini Dsub15 (Component Video Input)

    1080p, 1080i, 720p, 576p, 576i, 480p, 480i

  • RJ-45 (HDBaseT Input)

    Image, Audio, Control, Network; Equivalent to image and audio of HDMI/DP

  • RJ-45 (Network Connection)

    100BASE-TX, NMPJ screen transfer

  • USB Type A

    JPEG still image (10912x8640)(Maximum pixels)

  • Dot Clock

    162MHz (maximum)

Terminals

Jump to...
  • DVI-I

    Digital PC/Analog PC Input

  • HDMI

    Digital PC/Digital Video Input

  • DisplayPort

    Digital PC/Digital Video Input

  • Mini Dsub15

    Analog PC2/Component Video Input

  • Mini Jack

    Stereo Audio, Wired Remote Control Connection

  • Dsub9

    RS-232 Connection

  • USB type A

    USB Connection

  • Wi-Fi

    IEEE 802.11b/g/n

  • RJ-45

    HDBaseT/Network

Remote Control

Jump to...
  • Wireless Remote

    Infrared

Built-In Sound

Jump to...
  • Internal Speaker

    1W

Light Source

Jump to...
  • Type

    Super High Pressure Lamp

Ratings

Jump to...
  • Life

    3500/4000/3000

  • Fan Noise

    40/29/27dB

  • Power Consumption

    430/300/262 W

  • Standby Power Consumption

    1.6 - 0.28 W

  • Power Voltage

    AC100 - 240V: 50/60 Hz

  • Heat Dissipation

    Up to 1468 BTU/h

General

Jump to...
  • Operating Temperature

    32 to 104 deg. F (0 to 40 deg. C), 20%RH - 85%RH

  • Storage Temperature

    -4 to 140 deg. F (-20 to 60 deg. C)

  • Dimensions (WxHxD)

    19 x 7.7 x 20" (48.26 x 19.56 x 50.80cm)

  • Weight

    28.6 lbs (12.97kg) (Approx.)

  • UPC Code

    013803300109

2 Accessories for Canon REALiS WUX7500 Pro AV WUXGA LCoS Projector, 1920x1200, 7500-Lumen, No Lens, White

  • All Accessories (2)
  • Extended Warranty (1)
  • Stands (1)

About Canon REALiS WUX7500

An advanced and high-quality choice for diverse projection needs, the Canon REALiS WUX7500 Pro AV WUXGA LCoS Projector delivers superior image quality with its native WUXGA resolution of 1920x1200. This innovative projector is designed to produce vibrant, detailed images, making it an ideal choice for presentations, visual displays, and more in large venues and well-lit environments.

The REALiS WUX7500 boasts a high lumen output of 7500, ensuring bright and clear images even in large spaces. Its high contrast ratio of 2000:1 guarantees deep blacks, bright whites, and outstanding color accuracy, critical for discerning users.

This projector is built with Canon's unique LCoS (Liquid Crystal on Silicon) technology with AISYS-enhancement, which produces virtually seamless images with exceptional color reproduction and saturation. It also features advanced color management tools for independent color adjustment, offering highly detailed color control.

The REALiS WUX7500 offers flexible installation with its center lens design and compatibility with six interchangeable Genuine Canon lens options. These lenses provide consistent brightness and superior stability for a variety of applications. The projector is designed to reduce fan noise for quiet operation, making it suitable for environments such as higher education and medical fields.

With a comprehensive range of industry-standard interfaces, including HDBaseT, HDMI, DVI-I, DisplayPort, USB Type A, RJ-45, RS-232, audio inputs, and Network Multi Projection (NMPJ) over Wi-Fi, the REALiS WUX7500 ensures user-friendly connection.

The projector also includes pre-set Image Modes and additional customizable Image Modes to suit a wide range of user preferences and projection environments. It offers extensive image quality adjustments to help users customize the image to meet their specific projection needs.

The Canon REALiS WUX7500 Pro AV WUXGA LCoS Projector is a reliable and durable choice for professional projection needs, offering superior image quality, advanced features, and flexible installation options.

Canon REALiS WUX7500 Features

  • High-quality WUXGA (1920x1200) resolution for vibrant, detailed images
  • 7500-lumen output ensures bright and clear projection in large venues
  • Advanced LCoS technology with AISYS-enhancement for seamless, color-rich images
  • Quiet operation with noise reduction to as low as 27 decibels
  • Flexible installation with six interchangeable Genuine Canon lens options
  • Comprehensive connectivity with interfaces like HDMI, DVI-I, DisplayPort, and Wi-Fi

Warranty Information

This product has a limited warranty of 60 months.

Key Features

  • Experience vibrant visuals with this 7500-Lumen projector, perfect for large venues.
  • Enjoy crystal-clear images with WUXGA resolution, ideal for detailed presentations.
  • This Canon projector's LCoS technology delivers superior color accuracy every time.
  • Achieve seamless connectivity with HDMI, DisplayPort, and HDBaseT inputs on this projector.
  • With a long-lasting lamp life, this projector minimizes maintenance and maximizes use.
  • The REALiS projector offers versatile mounting options for easy setup in any environment.

What's in the box:

  • Canon REALiS WUX7500 Pro AV WUXGA LCoS Projector
  • Power Cord
  • RS-RC07 Projector Remote Controller with 2x AAA Batteries
  • RS-LP12 Lamp
  • Important Information Book
  • Canon 5 Year Limited Warranty (3 Year Advanced Exchange Service & Service Loaner Program)
