Crest Audio X-Series Professional Rack-Mountable Mixing Console, 20Hz-20kHz Frequency Response

SKU: CAX18R MFR: X18R
Earn VIP Reward Points

Key Features

  • Achieve pristine sound quality with this Crest Audio recording mixer for professional results.
  • Enjoy flexible EQ control, shaping your audio with precision using this professional mixer.
  • Connect mics & instruments easily with multiple input channels on this versatile mixer.
  • Experience ultra-low noise performance, ensuring clean audio recordings every single time.
  • This rack-mountable mixer offers exceptional durability, built to withstand rigorous use.
  • Use the USB interface for seamless integration with your favorite recording software.
See More Product Details
Temporarily On Backorder?Expected Availability: 12/2025Request assistance or get notified
Free Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Crest Audio X-Series Professional Rack-Mountable Mixing Console Specifications

  • Frequency response

    20 Hz-20 kHz

  • T.H.D. + noise

    Any output <0.01% THD 20 Hz to 20 kHz at +15dBu out

  • Noise

    (22 Hz to 22 kHz Bandwidth) Mic EIN: <-128dBu (Measured at +60dB gain, 150 Ohms source)
    Bus Noise: Below -85dBu (w/32 Channels Routed)

  • Crosstalk

    Channel Mute: >90dB
    Channel Routing: >80dB
    Channel fader attenuation: >90dB
    Aux Send attenuation: >85dB

  • Phase shift

    <+/-30 degrees 20 Hz to 20 kHz Mic in to Main out

  • XLR inputs

    XLR 4 kOhms Balanced

  • Max voltage gain

    Mic-In To Group To Left/Right Balanced Out = 100 dB

  • Line-in and TRS

    10 kOhms balanced

  • RCA tape input

    10 kOhms unbalanced

  • Bus inputs

    10 kOhms balanced

  • Main outputs

    XLR, 100 Ohms Balanced (switchable between line or mic level)

  • Group outputs

    TRS 50 Ohms ground compensated

  • Auxiliary outputs

    XLR & TRS 50 Ohms ground compensated

  • Headphones

    Stereo, intended to drive > 8 Ohms

  • Internal power supply

    AC Input: 100-240 VAC, 50/60 Hz via 15A IEC Mains connector

  • Dimensions (W x D x H)

    19 x 4.5 x 17.5" / 482.6 x 114.3 x 444.5mm

  • Weight

    29.98lbs / 13.6kg

  • UPC Code

    014367154481

About Crest Audio X-Series Professional Rack-Mountable Mixing Console

Take your audio mixing capabilities to the next level with the Crest Audio X-Series Professional Rack-Mountable Mixing Console, a pinnacle of sonic precision and operational tranquility in the realm of professional audio equipment. Engineered for high-end performance and constructed with unwavering durability, this console boasts a modular design that adapts seamlessly to a variety of professional audio environments.

Experience the versatility of up to 14 mono and four stereo inputs, all designed to accommodate a diverse range of audio sources. The long-throw faders offer meticulous control over sound levels, ensuring that every nuance of your mix is captured with clarity and depth. The four-band semi-parametric EQ on each channel allows for detailed sculpting of audio frequencies, providing the flexibility needed to fine-tune your sound to perfection.

Channel inserts on each mono channel enable the integration of external processing equipment, expanding the creative possibilities of your mix. The high-quality microphone preamplifiers are a testament to the console's commitment to audio excellence, delivering pristine amplification that captures the true essence of your source material.

With six configurable aux buses and three main buses, this mixing console offers an abundance of routing options, making it an ideal choice for front-of-house mixing, whether you're managing a live concert, theater production, or corporate event. The rack-mountable design ensures that your setup remains streamlined and professional, fitting effortlessly into your existing audio rack for a tidy and efficient workspace.

Crafted by Crest Audio, a brand synonymous with reliability and high-quality sound, the X-Series Professional Rack-Mountable Mixing Console stands as a reliable workhorse for sound engineers and audio professionals who demand nothing less than the best. With a frequency response of 20Hz-20kHz, this console guarantees a full spectrum of sound, capturing every detail from the deepest bass to the highest treble.

Whether you're in a live sound venue, recording studio, or any other professional audio setting, the X-Series Professional Rack-Mountable Mixing Console is your partner in achieving audio excellence.

Crest Audio X-Series Professional Rack-Mountable Mixing Console Features

  • 14 mono inputs + 2 stereo inputs, all with mic preamps and individual 48V phantom power switches
  • 100 mm faders on all inputs and Left, Right and Mono (center) outputs, 60 mm faders on the four sub groups
  • Four-band EQ on all inputs
  • 18dB per octave high-pass filters on mono input channels
  • Insert on all inputs, subgroups, aux outs and L, R & M outputs
  • Six aux buses, selectable pre or post fader in pairs
  • Auxes 1 & 2 are configured as Level/Pan for stereo operation
  • XLR L, R & Mono outputs switchable between line and mic level
  • 1/4" TRS and RCA connectors provided on alt output, monitor output and tape input
  • Internal universal power supply

Product Documents

User Manual

Key Features

  • Achieve pristine sound quality with this Crest Audio recording mixer for professional results.
  • Enjoy flexible EQ control, shaping your audio with precision using this professional mixer.
  • Connect mics & instruments easily with multiple input channels on this versatile mixer.
  • Experience ultra-low noise performance, ensuring clean audio recordings every single time.
  • This rack-mountable mixer offers exceptional durability, built to withstand rigorous use.
  • Use the USB interface for seamless integration with your favorite recording software.

What's in the box:

  • Crest Audio Professional Rack-Mountable Mixing Console
  • Crest Audio 5 Year Parts and Labor Warranty
