What are the unique features of the XF605 4K UHD 10-Bit Professional Camcorder?

The XF605 4K UHD 10-Bit Professional Camcorder is equipped with Canon's Dual Pixel CMOS AF for high-speed, high-accuracy focusing. It also features Eye Detection AF and iTR AF X head detection algorithm for accurate subject tracking. It's the first in the XF-series to feature USB Video Class, allowing use as a webcam without an adapter.

What is the benefit of the Canon's XC Protocol in the XF605 4K UHD 10-Bit Professional Camcorder?

Canon's XC Protocol, incorporated in the XF605 camcorder, is an IP-based protocol that enables remote control of key camera features through IP network-connected devices. This includes focus, auto focus, iris, shutter, ISO/gain, the recall of custom picture settings, and other important camera settings.

What does the 4K L-series 15x Optical Zoom lens offer in the XF605 4K UHD 10-Bit Professional Camcorder?

The 4K L-series 15x Optical Zoom lens enables the XF605 camcorder to shoot high-quality 10-bit 4:2:2 4K UHD footage in XF-AVC (Intra-frame and Long GOP) and MP4 formats. It records to dual SD cards, facilitating easy post-production and quick delivery.

What is the advantage of the 1.0-inch 4K UHD CMOS Sensor in the XF605 4K UHD 10-Bit Professional Camcorder?

The 1.0-inch 4K UHD CMOS Sensor in the XF605 camcorder allows for larger photosites compared to smaller-sized sensors, resulting in improved images with less noise in low-light situations. The larger sensor also exhibits a shallower depth of field at large apertures, providing greater depth of field control and creative options.

How does the XF605 4K UHD 10-Bit Professional Camcorder support 4K UHD recording?

The XF605 Professional Camcorder supports 4K UHD 59.94p 4:2:2 10-bit recording to support natural and realistic 4K video production. Users can choose between MXF-based XF-AVC Intra-frame and Long GOP and versatile MP4 formats. The latest firmware adds two additional recording options: H.264 FHD 25Mbps and 16Mbps FHD MP4 proxy recording.

Reviews about this item

Review Summary

Select a plan in the Add Protection section above and purchase with this product by clicking “Add to Cart”.

image-protection

TRUSTED PROTECTION PLANS, EXCEPTIONAL SERVICE.

Invest In Your Gear and Peace Of Mind!

Accidents happen where life happens. Protect your favorite Adorama products and purchase a protection plan to stay covered from accidental damage, mechanical or electrical failure, and more.

Repair or Replacement

Repair or Replacement

If we can’t fix it, we’ll replace it at no additional cost.

Accidental Damage

Accidental Damage

Protect your product from drops, spills, and more.

Peace of Mind

Peace of Mind

Enjoy your gear without fear. We have you covered!

Malfunction Protection

Malfunction Protection

When regular use of your product over time results in mechanical or electrical failure.

Zero Deductible

Zero Deductible

We will never charge you a deductible after the purchase of a plan.

Customer-Focused Support

Customer-Focused Support

Our claims process is simple & easy and our customer service team is happy to help.

Adorama Protect powered by Extend is available for purchase to customers in the United States. Not available for purchase Internationally or in U.S. Territories.

Canon XF605 Specifications

Imaging Sensor

Imaging Sensor

Jump to...
  • Standard Definition or High Definition

    4K Ultra High Definition

  • Imaging Sensor

    1.0" 4K UHD CMOS Sensor

  • Total Pixels

    Approx. 13.4 megapixels (4268x3148)

  • Effective Pixels

    Approx. 8.29 megapixels (3840x2160)

  • Power

    14.4 V DC (battery pack), 24 V DC (DC IN)

Recording/Codec

Jump to...
  • Video Recording System

    XF-AVC
    Compression: MPEG-4 AVC/H.264
    Color Sampling: 4:2:2 10-bit
    File Format: MXF

    Recording Modes:
    Resolution: 3840x2160 (YCC422 10-bit)
    260 Mbps Long GOP (59.94P/50.00P)
    410 Mbps Intra-frame (29.97P/25.00P/23.98P)
    160 Mbps Long GOP (29.97P/25.00P/23.98P)

  • Video Recording System (Contd.)

    Resolution: 1920x1080 (YCC422 10-bit)
    310 Mbps Intra-frame (59.94P/50.00P)
    160 Mbps Intra-frame (29.97P/25.00P/23.98P/59.94i/50.00i)
    50 Mbps Long GOP (59.94P/50.00P/29.97P/25.00P/23.98P/59.94i/50.00i)
    25 Mbps Long GOP (59.94i/50.00i)

    Resolution: 1280x720 (YCC422 10-bit)

  • Video Recording System (Contd..)

    MP4 Compression: MP4 (HEVC): H.265/HEVC, MP4 (H.264): MPEG-4 AVC/H.264

    Color Sampling:
    MP4 (HEVC): YCC422 10-bit/YCC420 10-bit
    MP4 (H.264): YCC420 8-bit
    File Format: MP4

  • Video Recording System (Contd...)

    Recording Modes:
    Resolution: 3840x2160 (YCC422 10-bit): 225 Mbps (59.94P/50.00P) / 135 Mbps (29.97P/25.00P/23.98P)
    Resolution: 1920x1080 (YCC422 10-bit): 50 Mbps (59.94P/50.00P/29.97P/25.00P/23.98P)
    Resolution: 1280x720 (YCC422 10-bit): 12 Mbps (59.94P/50.00P)
    Resolution: 3840x2160 (YCC420 10-bit): 170 Mbps (59.94P/50.00P) / 100 Mbps (29.97P/25.00P/23.98P)

  • Video Recording System (Contd....)

    Resolution: 1920x1080 (YCC420 10-bit): 35 Mbps (59.94P/50.00P/29.97P/25.00P/23.98P)
    Resolution: 1280x720 (YCC420 10-bit): 9 Mbps (59.94P/50.00P), (2) MP4 (H.264): (YCC420 8-bit)
    Resolution: 3840x2160: 150 Mbps (59.94P/50.00P/29.97P/25.00P/23.98P)
    Resolution: 1920x1080: 35 Mbps (59.94P/50.00P/29.97P/25.00P/23.98P)
    Resolution: 1920x1080: 16 Mbps (59.94P/50.00P)
    Resolution: 1280x720: 8 Mbps (59.94P/50.00P)

  • Frame Rate

    60p, 30p, 24p

  • Recording Media

    SD card [x2] (SD/SDHC/SDXC)

  • Audio Recording System

    Linear PCM: 24-bit / 48 kHz / 4-channel (XF-AVC)
    Linear PCM: 16-bit / 48 kHz / 4-channel (MP4)
    MPEG-2 AAC LC 16-bit / 48 kHz / 2-channel (MP4)

  • Microphone

    Stereo (using electret condenser microphone)

Lens System

Jump to...
  • Lens

    Canon 15x Zoom, 8.3-124.5mm (35mm equivalent 25.5-382.5mm), f/2.8-4.5

  • Focusing System

    Dual Pixel CMOS AF w/Eye Detection

  • Minimum Focusing Distance

    10mm at wide end, 60cm across entire zooming range

  • Image Stabilization

    Optical system (lens shift) + electronic stabilization (Image rotation and camera movements in the yaw and pitch directions are electronically corrected.) Modes: Dynamic IS, Powered IS, Standard IS, IS Off

  • Filter Diameter

    58mm

Exposure and Metering

Jump to...
  • Manual Exposure

    Yes

  • Max Shutter Speed

    1/2000

  • Minimum Illumination

    Approx. 1.5 lux (with 1/30 sec. shutter speed, 29.997P)

Input/Output

Jump to...
  • Genlock Terminal

    Yes

  • Timecode Terminals

    Yes

  • USB Terminal

    Type-C, SuperSpeed USB (USB 3.2 gen 1x1) supported, PTP class supported, UVC Supported Type-A, USB HOST supported (max. voltage: 5V / max. output current: 900 mA)

  • Video Terminal

    HDMI connector, 12G-SDI terminal

  • Audio Terminal

    3.5mm stereo mini-jack, XLR 3-pin jack (two channels)

  • HDMI Terminal

    HDMI connector (Type A)

  • Headphone Terminal

    3.5mm stereo mini-jack

  • 12G-SDI Terminal

    Yes

  • Ethernet Terminal

    Ethernet connector (RJ-45) (supports 1000BASE-T and SRT protocol)

LCD Monitor/EVF

Jump to...
  • Viewfinder

    0.36" color OLED display, approx. 1.77 million dots, approx. 100% field of view

  • LCD Screen

    3.5" LCD, (Approx. 2.76 million dots)

Environment

Jump to...
  • Operating Temperature Range

    For Performance: Approx. 0-40 Degree C, 85% (relative humidity)
    For Operation: Approx. -5-45 Degree C, 60% (relative humidity)

Battery

Jump to...
  • Battery Info

    required, included

  • Battery Material

    lithium ion

  • Battery Type

    Non-universal

  • Battery Quantity

    1

Physical

Jump to...
  • Dimensions

    Approx. 6.6 x 6.8 x 13.1" (168 x 173 x 333mm) (Body only, excluding grip belt)
    Approx. 7.9 x 8.6 x 15.2" (200 x 219 x 385mm) (Including lens hood, eyecup and mic holder unit)

  • Weight

    Approx. 4.4 lbs (2.01kg)
    (including grip belt; excluding hood, mic holder unit, eyecup, battery)

  • UPC Code

    660685240896

About Canon XF605

Over the years, the XF605 4K UHD 10-Bit Professional Camcorder has emerged as a next-generation marvel in Canon's XF-series, offering unparalleled mobility, seamless connectivity, and superior 4K UHD HDR image quality. This refurbished model is equipped with Canon's acclaimed Dual Pixel CMOS AF, ensuring high-speed and high-precision focusing. It stands out as the first XF-series model to incorporate Eye Detection AF and iTR AF X head detection algorithm, enhancing face and head detection for more accurate and stable subject tracking.

The XF605 camcorder boasts a 4K L-series 15x Optical Zoom lens with 3-ring manual control, enabling it to shoot 10-bit 4:2:2 4K UHD footage in XF-AVC (Intra-frame and Long GOP) and MP4 formats. This is recorded to dual SD cards, facilitating easy post-production and quick delivery. The camcorder comes with multiple recording modes, including Frame, Interval, and Slow and Fast motion up to 120fps in FHD.

Designed with news gathering in mind, the XF605 integrates the CTM (Content Transfer Mobile) iPhone application, which allows for the exchange of proxy footage, audio, and metadata with a newsroom server through a phone connection in the field. This feature seamlessly integrates into newsroom assignment planning software.

For remote control of key camera features, the XF605 incorporates Canon's XC Protocol, an IP-based protocol that enables remote control of camera settings through IP network-connected devices. This includes the Canon RC-IP100 controller or other IP-enabled 3rd-party camera controllers.

The XF605 camcorder is also the first in the XF-series to feature USB Video Class, allowing it to be used as a webcam without the need for a 3rd Party HDMI to USB adapter. It features a 1.0-inch 4K UHD CMOS Sensor, capable of 4K UHD video capture at 60p and slow-motion recording up to 120fps in Full HD. This makes the camcorder a strong contender for professional productions and ENG applications.

The XF605 camcorder's 1.0-inch sensor allows for larger photosites compared to smaller-sized sensors, resulting in improved images with less noise in low-light situations. The larger sensor also exhibits a shallower depth of field at large apertures, providing greater depth of field control and creative options.

The camcorder's DIGIC DV 7 imaging engine further enhances the high sensitivity and low noise performance of the camcorder. The XF605 Professional Camcorder incorporates a Canon 4K video lens that leverages proprietary Canon optical technologies derived from years of experience in developing Cinema, Broadcast, and EF-series lenses.

The XF605 camcorder also incorporates a 5-axis Optical Image Stabilization (IS) system, featuring three modes of image stabilization: Standard, Dynamic, and Powered. For enhanced versatility and durability, the lens features a 9-blade iris, producing artistic and beautiful out-of-focus areas or "bokeh."

The XF605 Professional Camcorder supports 4K UHD 59.94p 4:2:2 10-bit recording to support natural and realistic 4K video production. Users can choose between MXF-based XF-AVC Intra-frame and Long GOP and versatile MP4 formats. The latest firmware (now available) adds two additional recording options: H.264 FHD 25Mbps and 16Mbps FHD MP4 proxy recording.

Canon's Dual Pixel CMOS AF technology uses every pixel on the imaging sensor to detect focus and to capture actual image information, offering users high precision focusing and exceptional image quality. The XF605 is the first XF-series camera to feature Eye Detection AF which further increases the accuracy of focus on human subjects. The XF605 is also the first XF-series camera to feature EOS iTR AF X, which includes a head detection algorithm developed with deep learning technology. In Face Detection mode, the AF works with this advanced algorithm to dramatically improve distance measuring and tracking reliability.

Canon XF605 Features

  • 1.0" 4K UHD CMOS Sensor
  • On-Screen Display (OSD) Time Stamp Recording
  • 15x Optical 4K UHD L Zoom Lens with 5-Axis Optical Image Stabilization
  • 5-Axis Optical Image Stabilization
  • 9-Blade Iris
  • Independent 3-Density ND Filter
  • 4K UHD 59.94P 4:2:2 10-bit Recording

Warranty Information

This product has a limited warranty of 3 months.

Product Documents

User Manual

Key Features

  • Capture stunning 4K UHD video with the Canon XF605 professional camcorder for crisp, clear footage.
  • Achieve smooth, stable shots using the advanced image stabilization, perfect for run-and-gun video.
  • Record high-quality audio with XLR inputs, ensuring pristine sound for professional video productions.
  • Utilize the 15x optical zoom lens to get closer to the action, ideal for documentaries and events.
  • Enjoy versatile connectivity with HDMI, 12G-SDI, and USB, streamlining your video workflow seamlessly.
  • Rely on the long-lasting battery for extended shoots; never miss a moment with this pro camcorder.

What's in the box:

  • Canon XF605 4K UHD 10-Bit Professional Camcorder
  • Lens Hood (with Lens Barrier)
  • Lens Cap
  • Microphone Holder Unit (with Screw)
  • AC Cable
  • Battery Charger (CG-A20)
  • Compact Power Adapter (CA-CP200 L)
  • Battery Pack (BP-A30)
  • Eyecup
  • Canon 90 Day Limited Warranty
