Cartoni P70 Steering Pedestal with C20 Fluid Head, 2x Pan Bars, 100mm Adapter & Pump

SKU: CCP70SC01 MFR: KP7SC01
Earn VIP Reward Points

Key Features

  • Achieve smooth, professional shots with this Cartoni pedestal's precise fluid head.
  • Enjoy versatile camera support with a 100mm bowl, perfect for various setups.
  • Confidently use this durable pedestal, supporting cameras up to 71 lb (32kg).
  • Easily adjust your camera's position with the fluid head's 7-step counterbalance.
  • Capture dynamic shots with the pedestal's on-shot stroke of 45, enhancing stability.
  • Steer smoothly with this lightweight, portable pedestal, ideal for on-the-go filming.
See More Product Details
Ships from Manufacturer?
Free Shipping

See Options

1

Need help? Ask our experts.

Overview
Compare
Specs
Protection
Q&A

Questions & Answers

FAQ

What type of applications is the P70 Steering Pedestal with C20 Fluid Head suitable for?

The P70 Steering Pedestal with C20 Fluid Head is designed for both studio and OB applications. Its super-smooth drive makes it suitable for easy traveling and on-location shoots.

What safety features does the P70 Steering Pedestal have?

The P70 Steering Pedestal includes a safety air pressure valve to prevent the risk of air overpressure. This ensures safe operation while using the 'on-shot' column.

What camera weight can the C20 Fluid Head support?

The C20 Fluid Head is designed to operate with a wide range of cameras, supporting weights from 7 to 32 Kg (15 to 71 lbs).

What does the P70 Steering Pedestal package include?

The P70 Steering Pedestal package includes a removable foot bar, 4x500 gr. (4x1.1 lbs) counterweights, adjustable cable guards, and a manual air pump.

How many steps of drag does the C20 Fluid Head offer?

The C20 Fluid Head offers 7 precisely repeatable steps of drag, providing smooth and controlled movements for your camera.

Reviews about this item

Review Summary

Cartoni P70 + C20 Specifications

P70 Steering Pedestal

P70 Steering Pedestal

Jump to...
  • Maximum Pressure

    9.0 atm
    132.3 psi

  • On-Shot Stroke

    45

  • Doorway Tracking Width

    Minimum: 17.7" (45cm)
    Maximum: 31.9" (81cm)

  • Payload Capacity

    165.3 lb (75kg)

  • Wheel Diameter

    4.9" (12.5cm)

  • Height

    Minimum: 31.5" (80cm)
    Maximum: 49.2" (125cm)

  • Weight

    99.2 lb (45kg)

C20 Fluid Head

Jump to...
  • Payload Capacity

    Maximum: 71 lb (32kg)

  • Bowl Diameter

    100 mm

  • Fluid Drag

    7 steps + 0

  • Counterbalance

    7 steps + 0

  • Pan Range

    360 Degree

  • Tilt Range

    +/-65 Degree

  • Temperature Range

    -40 to 140 Degree F (-40 to 60 Degree C)

  • Weight

    14.3 lb (6.5kg)

About Cartoni P70 + C20

Be prepared for any shooting scenario with the P70 Steering Pedestal and C20 Fluid Head combo, a versatile and professional-grade piece of equipment from the renowned brand, Cartoni. This updated version of the popular P70 is a compact and portable steering system designed for both studio and OB applications. It offers a super-smooth drive for easy traveling, making it an ideal choice for on-location shoots.

The P70 Steering Pedestal is incredibly stable yet lightweight, capable of delivering exceptional performance with any camera or lens combination up to 75 Kg (165 lbs). Its air-filled, "on-shot" column is quick and safe to operate, compatible with Nitrogen or clean compressed air. This can be loaded using any compressor or a simple hand pump, ensuring ease of use. A safety air pressure valve is included to prevent the risk of air overpressure.

The innovative column design of the P70 provides outstanding stability and jerk-free control, allowing for smooth and precise movements. The sturdy P70 dolly is equipped with three sets of double 12.5 cm (4.9 in.) diameter heavy-duty wheels, individually lockable and cast with a bi-component polyurethane mix for enhanced steering. An advanced design chain ensures accurate traveling in crab position even "on shot". The system interfaces with all flat base, 4-bore hole Heads or any other bowl-based Head with an adapter.

The P70 Steering Pedestal also comes with a removable foot bar, 4x500 gr. (4x1.1 lbs) counterweights, adjustable cable guards, and a manual air pump, providing everything you need for a successful shoot.

Paired with the P70 is the C20 Fluid Head, designed to provide an extremely stable support for standard EFP configurations. It is ready to operate with a wide range of cameras weighing from 7 to 32 Kg (15 to 71 lbs). The C20S features three award-winning fluid damping modules, ensuring outstanding drag levels and extraordinary smoothness in both pan and tilt modes. Movements can be selected with 7 precisely repeatable steps of drag, while free wheeling is available by simply setting the drag selector ring into position "0". Counterbalance is activated by an easy grip selector in 7 progressive steps and "0". The C20S comes with a 100 mm bowl base, illuminated spirit level, and one telescopic pan bar. A 150 mm bowl base is also available as an option.

In summary, the P70 Steering Pedestal with C20 Fluid Head, 2x Pan Bars, 100mm Adapter & Pump is a durable, sturdy, and high-quality choice for professionals seeking versatility in their photography and videography equipment.

Cartoni P70 + C20 Features

  • Durable and versatile P70 Steering Pedestal with C20 Fluid Head for professional photography and videography
  • Stable & lightweight design, capable of supporting camera/lens combinations up to 75 Kg (165 lbs)
  • Innovative column design for jerk-free control, smooth movements, and enhanced steering
  • C20 Fluid Head provides stable support for standard EFP configurations, compatible with a wide range of cameras
  • Features three award-winning fluid damping modules for outstanding drag levels and smooth pan and tilt modes
  • Includes removable foot bar, counterweights, adjustable cable guards, and a manual air pump for comprehensive shooting setup

Warranty Information

This product has a limited warranty of 60 months for parts and 36 months for labor.

Key Features

  • Achieve smooth, professional shots with this Cartoni pedestal's precise fluid head.
  • Enjoy versatile camera support with a 100mm bowl, perfect for various setups.
  • Confidently use this durable pedestal, supporting cameras up to 71 lb (32kg).
  • Easily adjust your camera's position with the fluid head's 7-step counterbalance.
  • Capture dynamic shots with the pedestal's on-shot stroke of 45, enhancing stability.
  • Steer smoothly with this lightweight, portable pedestal, ideal for on-the-go filming.

What's in the box:

  • P70 Steering Pedestal
  • C20 Fluid Head
  • 2x Pan Bars
  • 100mm Adapter
  • Pump
  • Cartoni 5 Year Limited Warranty (3 Years + 2 Years with Registration) for Fluid Head
  • Cartoni 1 Year Limited Warranty for Other Kit Contents
